SCCP10-050
PWM Charge Controller/Load Manager
Owner's Manual
NOTE:
Follow instructions in order.
Charge batteries at least once a week.
Use reducers to connect larger wires
Do not disconnect
Do not
Do not
Do not
battery while PV is active
to terminals.
open
drop
get wet
Mount on wall with 4 screws
Clearance and orientation
Install battery wires
15 cm
(6")
15 cm
(6")
15 cm (6") clearance
No Battery here
= 12/24 volts only
Install load wires
Install PV wires
0.5 amps ≤
≤ 10 amps
≤ 10 amps
No PV here
For more information on this product, visit www.smartharvestbyoutback.com
1
Advertisement
Table of Contents
Summary of Contents for Smartharvest SCCP10-050
- Page 1 SCCP10-050 PWM Charge Controller/Load Manager Owner’s Manual NOTE: Follow instructions in order. Charge batteries at least once a week. Use reducers to connect larger wires Do not disconnect Do not Do not Do not battery while PV is active to terminals.
- Page 2 SCCP10-050 Owner’s Manual Load & Battery Type Selection Indicators (blink RED (Warning) (on) flash) (blink YELLOW (Battery) (on) flash) Jumper (on) GREEN (PV) Present Normal VRLA Battery Removed Night Light/Dusk to Dawn Flooded Battery Jumper inserted at factory at both 1 and 2.
- Page 3 SCCP10-050 Owner’s Manual Symbols Caution: Shock Hazard Caution: Hot Surface Caution: Equipment Damage When disposing, keep this product separate from household waste; Double or Reinforced Insulation Refer to Operating Instructions recycle this product Features LED Indicators Users Selection Jumpers PV Input...
- Page 4 SCCP10-050 Owner’s Manual Specifications Section Name 12 Vdc 24 Vdc Section Name 12 Vdc 24 Vdc Controller Type Minimum Load Size 0.5 Adc Wattage (maximum) 120W 240 W Maximum Output Current 10 Adc Loads 5 min for Load > 100%, Max 50 Vdc Overload Time (Loads >...
