- Page 1 IOM095GVAE4112 8410 Wireless Field Transceiver Transmitter and receiver for wireless RS-232 and RS-485 data communications Automation Solutions for oil & gas, defense and aviation applications...
- Page 3 Phone: (770) 447-9202 Fax: (770) 662-8939 Trademarks Acknowledged Varec, Inc. recognizes all other trademarks. Trademarks of other products mentioned in this manual are held by the companies producing them. FuelsManager®, TankView®, TacFuels®, Varec®, and FuelsManager IntoPlane® are registered trademarks of Varec, Inc.
- Page 4 In no event shall Varec, Inc. or its suppliers be liable for any damages whatsoever including direct, indirect, incidental, consequential, loss of business profits or special damages, even if Varec, Inc. or its suppliers have been advised of the possibility of such damages.
-
Page 5: Safety Precautions
Read this manual carefully and make sure you understand its contents before using this product. Follow all instructions and safety guidelines presented in this manual when using this product. If the user does not follow these instructions properly, Varec cannot guarantee the safety of the system. - Page 6 This device must be operated as supplied by Varec, Inc. Any changes or modifications made to the device without the express written approval of Varec, Inc. may void the user’s authority to operate the device.
-
Page 7: Table Of Contents
........25 6.2.1 Point-to-Point operation LEDs Varec, Inc. - Page 8 Contents Factory Default Settings ........27 Specifications .
-
Page 9: Introduction
The 8410 WFT and the 8420 WBT provide wireless links between a variety of instruments and devices. The units can be configured to provide wireless communications with most RS-232 and RS-485 serial devices including the Varec 4590 TSM, Varec 2900 FTT, and Varec 8130 RTU. -
Page 10: Function And System Design
Introduction Function and System Design The 8410 WFT provides wireless 900 MHz RS-232 and RS-485 data communications. Point-to-MultiPoint Repeater Slave Slave Slave Master t r e A t l r g i t a ) 8130 RTU FuelsManager 8300 TGI Software Loop Communcations e.g. -
Page 11: Internal System Design
D. O-Ring E. Housing All standard electronics for the 8410 WFT are contained on the circuit board (C). This includes power, field communications, a 3-wire temperature input, and a 24V DC out. Figure 1-2: 8410 WFT System Components Varec, Inc. -
Page 12: Understanding Data Communication Configurations
Introduction Understanding Data Communication Configurations The 8410 WFT’s versatility allows the user to establish data communication links using a variety of configurations. This makes it possible to extend the range of the 8410 WFT and operate in a number of applications. This section describes the two main categories of communication configurations: Point-to-Point and Point-to-Multipoint. -
Page 13: Point-To-Multipoint Systems
Figure 1-6 depicts a standard point-to-multipoint system. In this example, any data sent from the master is broadcasted to all three slaves, one of which receives it through a multipoint repeater. The data is in turn sent out of the RS-232 or RS-485 port of each of the three slaves. 8410... -
Page 14: Choosing Point-To-Point Or Point-To-Multipoint Operation
However, if each slave will be transmitting data more frequently, the system will be closer to capacity and fewer slaves should be linked to the master. For examples and additional information on data communication links, please consult Varec, Inc. Installation and Operations Manual... -
Page 15: Preparing For Installation
To have the correct field connections at the field device ready to connect to the 8410 WFT, such as power and communications. To be in compliance with the safety guidelines described in Section 2.2, "General Safety Guidelines" on page 8. Varec, Inc. -
Page 16: General Safety Guidelines
When in doubt about the safety of an area, the user should check with the local safety authorities. Always observe equipment labels and warning signs posted in the area. Unpacking Varec 8410 Wireless Field Transceivers are shipped fully assembled and ready for installation. To unpack the 8410 WFT: Place the shipping container on a secure bench. -
Page 17: Installation Overview
Wireless Field Transceiver Installation Overview To install the transceiver, follow the pre-site preparation steps shown in the following flowchart: Antenna Site Configure Site Study Selection Identification Radios Equipment Installation Figure 2-2: 8410 WFT Installation Sequence Varec, Inc. -
Page 18: Installation Checklist
There are several important antenna characteristics that should be considered when choosing an antenna for your application: • Antenna radiation patterns/antenna type • Power gain • Directivity • Polarization Consult with Varec, Inc. to choose the proper antennas for each 8410 WFT and 8420 WBT location. Installation and Operations Manual... -
Page 19: Configuring Radios
• There are no major bends in the RF cables • All RF connections are secure and waterproof 2.5.6 Surge protection Caution Surges caused by near or direct lightning strikes can severely damage the equipment. Varec recommends installing surge protection on any exterior antenna or antenna cables. Varec, Inc. - Page 20 Preparing for Installation Installation and Operations Manual...
-
Page 21: Mounting
! Warning Before attempting installation of the 8410 WFT, review the General Safety Guidelines described in Chapter 2. Installation and maintenance personnel should become familiar with any hazards present as well as any agency requirements before working with any equipment. Varec, Inc. - Page 22 Mounting Installation and Operations Manual...
-
Page 23: Wiring
110/220 VAC RTD Feedthrough IN RTD Feedthrough OUT Serial Communications RS-232/RS-485 24VDC OUT RS-232/RS-485 Switch AC Voltage Selector Radio Setup Button Puts radio in setup mode Table 4-1: AC Wiring Headers and Switches Figure 4-1 on page 16 shows the wiring diagram for the AC version of the 8410 WFT. - Page 24 Wiring Antenna Connector Figure 4-1: 8410 WFT Wiring — AC Version Installation and Operations Manual...
-
Page 25: Connector Assignments For The Ac Version
AC IN Neutral Earth RTD OUT RTD IN RS-232/RS-485 VDC+ 24V DC Out VDC- For RS-232 - Set SW 1 to 232 RS-232 For 2-Wire RS-485 - Set SW 1 to 485 RS-485 Up Position RS-232 Down Position RS-485 Table 4-2:... -
Page 26: 8410 Wft Connectors, Switches, And Low Voltage Wiring Diagram
Voltage In 30-65 VAC / 6-90 VDC RTD Feedthrough IN RTD Feedthrough OUT Serial Communications RS-232/RS-485 24VDC OUT RS-232/RS-485 Switch Radio Setup Button Puts radio in setup mode SW6 and SW7 Voltage Selector Selects AC/DC and high/low DC voltage. Table 4-3: DC Wiring Connectors and Switches Figure 4-2 shows the wiring diagram for the low voltage version of the 8410 WFT. -
Page 27: Connector Assignments For The Low Voltage Version
Surge GND Earth RTD In RTD Out RS-232/RS-485 VDC+ 24V DC Out VDC- For RS-232 - Set SW 1 to 232 RS-232 For 2-Wire RS-485 - Set SW 1 to 485 RS-485 Up Position RS-232 Down Position RS-485 Table 4-4:... - Page 28 Wiring Installation and Operations Manual...
-
Page 29: Setting Up The Transceiver Using Tool Suite
Depending on the radio type, a radio may be configured via EZ Config, HyperTerminal, or FreeWave Tool Suite. The following link will allow the user to gain access to the FreeWave Tool Suite, which describes, in detail, how to configure radios and run diagnostics: http://www.freewave.com Varec, Inc. - Page 30 Setting Up the Transceiver Using Tool Suite Installation and Operations Manual...
-
Page 31: Led Operations
Setting switch SW3 in the up position (TERM), terminates the RS-485 network at the 8410 WFT using a 100 ohm resistor. This switch is normally set in the UNTERM position. When using RS-232 communication, set SW1 to RS-232 (up). When using RS-485 communications, set SW1 to RS-485 (down). -
Page 32: Point-To-Multipoint Operation Leds
LED Operations 6.1.1 Point-to-Multipoint operation LEDs Table 6-1 lists the point-to-multipoint operation LEDs for the 8410 WFT. Master Slave Repeater Condition Carrier Transmit Clear to Carrier Transmit Clear to Carrier Transmit Clear to Detect (CD) (TX) Send (CTS) Detect (CD) (TX) Send (CTS) Detect (CD) -
Page 33: Led Operations On A Point-To-Point System
Mode 6 - Waiting for Solid red Blinking Solid red Blinking ATD Command bright bright Setup Mode Solid green Solid green Solid green Solid green Solid green Solid green Solid green Solid green Solid green Table 6-2: Point-to-Point Operation LEDs Varec, Inc. - Page 34 LED Operations Installation and Operations Manual...
-
Page 35: Factory Default Settings
Set Baud Rate Default Point-to-Point Slave Set Baud Rate Default Baud Rate 115200 (A) Data Parity (B) Modbus RTU (C) RS-232/RS-485 (D) Setup Port (E) Turn Off Delay/ On Delay (F) Flow Control Table 7-2: Baud Rate Setting Varec, Inc. - Page 36 Factory Default Settings Radio Parameters Default (0) FREQ KEY (0) HOP TABLE VERSION (1) HOP TABLE SIZE (2) HOP FREQ OFFSET (3) Frequency Zone All 1’s (Enabled) (4) Government Rules (1) MAX PACKET SIZE (2) MIN PACKET SIZE (3) XMT RATE (4) RF DATA RATE (5) RF XMT POWER (6) SLAVE SECURITY...
-
Page 37: Specifications
Wireless Field Transceiver Specifications General Item Specification Data Port RS-232 and RS-485 Dimensions See Figure 2-1 on page 7 for details Power • 110/120 VAC (AC Version) • 30 - 65 VAC and 6 - 90 VDC (Low Voltage Version) Antenna •... -
Page 38: Data Transmission
Substitution, dynamic key Max Link throughput Kbaud standard speed, 38.4 Kbaud low speed Data interface RS-232/RS-485 1200 Baud to 230.4k Baud, async, full duplex TTL (RF board-level only) Table 8-4: Data Transmission Note * At 100% receive success rate. RF data rate setting of 2. -
Page 39: Ordering Information
Wireless Field Transceiver Ordering Information To order the 8410 Wireless Field Transceiver, use Varec model number N8410. Order Codes Figure 9-1 lists the order codes and their descriptions when ordering the 8410 WFT. Power Supply 110/220 VAC 50/60Hz 6 – 90 VDC and 30 – 65 VAC... - Page 40 Ordering Information Installation and Operations Manual...
