Summary of Contents for Stairville EarthQuake DMX512
-
Page 1: User Guide
EARTHQUAKE User Guide Please read these instructions carefully before use... - Page 2 INDEX A. GENERAL INSTRUCTIONS B. MAIN FEATURES C. LAMP D. HOW TO CONTROL THE UNIT -----(1) By universal DMX controller -----(2) Preprogrammed function -----(3) By easy controller E. FIXTURE CLEANING...
-
Page 3: General Instructions
A. GENERAL INSTRUCTIONS Please read the enclosed instructions carefully as they include important points about safety for the installation, usage and maintenance of the unit. Please keep this booklet with the unit for future consultation. If you sell the unit to another user, be sure that the new user also receives this instruction booklet thus giving them the necessary information about the use and general warnings regarding the unit. -
Page 4: Main Features
B. MAIN FEATURES MAIN FEATURES • Voltage AC 120V 60Hz or 230/240/250V 50/60Hz • Bulb ELC 24V 250W • The unit is a DMX512 scanner. It features full DMX512 control, 14 gobos plus open and 14 colors plus white, accurate focusable optics system and stepper motor with blackout feature. -
Page 5: How To Control The Unit
D. HOW TO CONTROL THE UNIT ( 1 ) By universal DMX controller The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. A DMX512 system requires a controller, lighting equipment and cable. These are connected together in a “daisy chain”... - Page 6 ( 2 ) Preprogram functions The unit can be linked together as master/slave in daisy chain in linkage as many units as required and run by built in preprogrammed chase sequences triggered by music. Not need to set the dipswitches in master/slave mode. 2-light show Dipswitch 10 “off”...
- Page 7 DMX512 CONFIGURATION Channel 1 Channel 2 Channel 3 Channel 4 Shutter Gobos/Colors Rotation Zoom 255 Fastest speed 255 Fastest speed 246-255 Stop 255 Fastest speed Zoom in/out (continue) 160 Slowest speed Rainbow Effect 128 Slowest speed 159 Zoom out max. 120-127 Gobo 14 / Yellow Gobo Shaking 112-119 Gobo 13 / Red...
-
Page 8: Fixture Cleaning
E. FIXTURE CLEANING FIXTURE CLEANING The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit’s optics. -
Page 9: Technical Specifications
Technical Specifications Power AC 120V 60Hz AC 230-250V 50/60Hz Fuse 20mm Glass T6.3A Fast Blow 20mm Glass T5A Fast Blow Lamps ELC 24V 250W Dimension 338mm x 320mm x 216 mm Weight 9 kg / 19.8 lbs...
