  • Page 1 Instruction Manual...
  • Page 3 CAUTION: when programming the transceiver,read the factory initial data first,then rewrite the frequency and signialing etc.,otherwise errors may occur because of different frequency band etc. User Manual applied to : LP-301 UHF FM Transceiver VHF FM Transceiver LP-301 programming software:WPS-301...
  • Page 4 SAFeTY INFoRMATIoN FoR USeR transceiver is excellently designed with advanced technology. Please observe the following precautions to perform your obligation, prevent personal injury and ensure the safety of transceiver usage. Keep the transceiver and accessories away from children. Please do not try to open or modify the transceiver without permission, non-professionals process may also cause damage. Please use assorted battery and charger to avoid damage.
  • Page 5: Table Of Contents

    CoNTeNT UNPACKING ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 01 Supplied accessories chart ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 01 STANDARD ACCeSSoRIeS/oPTIoNAL ACCeSSoRIeS ������������������������������������������������������������������������������������������������������������������� 02 Standard accessories ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 02 Optional accessories ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 02 BATTeRY INFoRMATIoN ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 03 Charging Operation �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 03 Battery Charger Type ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 03 Notice for Charging Battery ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 03 How to Charge ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������...
  • Page 6 CoNTeNT Receiving ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 14 Transmitting ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 14 Side key [PF1] function introduction ��������������������������������������������������������������������������������������������������������������������������������������������������������������������� 15 Side key [PF2] function introduction ��������������������������������������������������������������������������������������������������������������������������������������������������������������������� 15 Scan function ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 17 Turn on/off radio function ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 17 Delete/Add FM Radio ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 18 FM radio scan ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 18 Frequency copy ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������...
  • Page 7 CoNTeNT High and low power setup ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 27 CTCSS/DCS encode setup ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 28 CTCSS/DCS decode setup ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 29 Offset frequency direction Setup �������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 29 Frequency Step size setup ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 30 Frequency reverse ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 30 Voice operated Transmission (VOX) Setup ����������������������������������������������������������������������������������������������������������������������������������������������������������� 31 VOX Level Setup �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������...
  • Page 8 CoNTeNT Starting Display Setup ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 45 Display Character Defined By user ���������������������������������������������������������������������������������������������������������������������������������������������������������������������� 46 PRoGRAMMING SoFTWARe STARTING(TAKeS WINDoW XP FoR eXAMPLe) ���������������������������������������������������������������������� 47 TeCHNICAL SPeCIFICATIoNS �������������������������������������������������������������������������������������������������������������������������������������������������������������������� 48 TRoUBLe SHooTING GUIDe eLIMINATIoN MeTHoD ����������������������������������������������������������������������������������������������������������������������� 49 ATTACHeD CHART 1 ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 50 CTCSS Frequency Chart �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������...
  • Page 9: Supplied Accessories Chart

    UNPACKING Please carefully unpack the transceiver.We recommend that you identify the items listed in the following table before discarding the packing material .If any items are missing or have been damaged during shipment ,pls contact with dealers immediately. Supplied accessories chart Item Number Quantity...
  • Page 10: Standard Accessories/Optional Accessories

    STANDARD ACCeSSoRIeS/oPTIoNAL ACCeSSoRIeS Standard accessories Antenna Battery Charger Belt clip AC adaptor (12V/500mA) VHF(135~175MHz) BT FR30 LI L CHG 30B LP-84M ADA 12V UHF(400~480MHz) etc� *1 Note:For the frequency band of Antenna ,please refer to label indicated in the bottom of the antenna Instruction Manual Warranty card certificate of quality...
  • Page 11: Battery Information

    BATTeRY INFoRMATIoN Charging operation The battery is not charged at the factory, please charge it before use. Charge the battery for the first time after purchase or extended storage (more than 2 months) may not bring the battery to its normal operating capacity. After repeating fully charge/ discharge cycle for two or three times, the operating capacity will reach the best performance.
  • Page 12: How To Charge

    BATTeRY INFoRMATIoN How to Charge Plug the AC adaptor into the AC outlet, and then plug the cable of the AC adaptor into the DC jack located on the back of the Charger. The Indicator lights orange (1s) and then goes out----waits to charge. Plug the battery or transceiver into the charger.
  • Page 13: Normal Charging Tips

    BATTeRY INFoRMATIoN LED indicator: Self-Examine STATuS No Battery Pre-charging Charge Normally Fully Charged Trouble When Power on Orange (for 1 Red Light Twinkles Red twinkles None Green second) for 5 Minutes for a long time NoTe:Trouble means battery heating,batteru-circuit or charger short-circuit. Normal Charging Tips Self- examination: When charging, orange light twinkles for 1 second and goes out, which means the charger has passed its self-examination and it can charge the battery normally.
  • Page 14: Preparation

    PRePARATIoN Installing / Removing the Li-ion Battery Match the two grooves of the battery pack with the corresponding guides on the back of the transceiver, and then push it. Press the battery pack until the release latch on the top of the transceiver locks.
  • Page 15: Installing / Removing The Belt Clip

    PRePARATIoN Installing / Removing the Belt Clip Installing the Belt Clip: Place the belt clip to the corresponding grooves on the back of the transceiver, and then clockwise screw it. Removing the Belt Clip: Anticlockwise turn the screws to remove the belt clip.
  • Page 16: Getting Acquainted

    GeTTING ACQUAINTeD LCD Display On LCD display screen,you will see various icons which stand for the selected functions and sometimes you may forget the meaning of them.Here you will find the following table extremely useful. Frequency Reverse Priority Scan Offset Frequency VOX Function Narrow Band CTCSS /DCS...
  • Page 17: Front Panel

    GeTTING ACQUAINTeD Front Panel Antenna Frequency Switch Power/Volume Switch Jacklight Speaker Microphone Numeric keys...
  • Page 18: Side Panel

    GeTTING ACQUAINTeD Side Panel PTT key Speaker/Microphone Reading/Writing Programming Software Jack PF1 key:squelch off Belt Clip PF2 key:high/low power switch Battery Left Panel Right Panel...
  • Page 19: Basic Operation

    BASIC oPeRATIoN Turn on/off Transciver under power-off state ,please turn (PoWeR)/(VoLUMe) clockwise until beeping and current signal display on LCD,indicate turn on the transceiver. under power-on state ,please turn (PoWeR)/(VoLUMe) anticlockwise until beeping "KADA" indicate turn off the transceiver. Adjusting Volume under power-on state turn (PoWeR)/(VoLUMe) to adjust volume .Colockwise-up anticolockwise- down;You could press the programmed as squelch off key to monitor the current volume.
  • Page 20: Operating Mode Switch

    BASIC oPeRATIoNS operating mode switch In standby state,press Key to exchange between frequency mode(VFo) with channel mode. Channel selection Under channel mode/FM mode, turn band switch or press key/ key could get the channel you want:turn band switch clockwise or press key turn to down channel.Anticlockwise or press key turn to up channel.
  • Page 21: Frequency Adjustment

    BASIC oPeRATIoNS Frequency adjustment Under VFO mode,turn band switch or press key/ key could get the frequency you want:turn band switch clockwise or press key increase the frequcncy.Anticlockwise or press key decrease frequency.Every trun /press can add or reduce stepping value.This product have 5k、6.25k、10k、12.5k and 25k in total 5 for option. Frequency input by keypad Under Main Channel frequency mode or FM radio frequency mode, this function is valid.
  • Page 22: Squelch Off /Momentary Squelch Off

    BASIC oPeRATIoNS Squelch off /Momentary Squelch off While side key [PF1] is setup for Squelch Off Momentary / Squelch Off function.You can monitor the weaker signal that is hard to hear by pressing this key. Squelch Off Momentary: Pressing and holding [ PF1] key, squelch circuit is not mute, release this key to make squelch circuit turn to mute.
  • Page 23: Side Key [Pf1] Function Introduction

    BASIC oPeRATIoNS Side key [PF1] function introduction Squelch Off: Press [PF1] and hold(over 2.5 seconds),the silent circuit not squelch,and then release ,the circuit will keep on not slience ,and press [PF1],the circuit will keep silence. Squelch Off Momentary: press [PF1]key (Don't hold long time or it will come into squelch off ),the squelch will not working and can hear background voice,relsase the squelch is on.
  • Page 24: Basic Operations

    BASIC oPeRATIoNS (2) Receiving frequency setup: press [PF2] key and hold to starting up and enter the setup mode. Turn band switch or press key/ key and choose "2" funtion key ,LED on "R-FReQ"; press key goes into function setup ,arrow turn to set items,LCD show“——————”; Input frequency by numeric key.Just write in both start and end frequency;...
  • Page 25: Scan Function

    BASIC oPeRATIoNS (4)Copy wired press [PF2] key can come into setup mode; Turn band switch or press key/ key and choose "4" function key ,"CLoNe" on LCD; Press [PTT] key can come into copy wired state. NoTe:if use this function the DATA of 2 sets walkie talkie need to connect through copy wired. Scan function In standby state,press key/...
  • Page 26: Delete/Add Fm Radio

    BASIC oPeRATIoNS Delete/Add FM Radio In standby state,press key and hold until "MoDe" show on LCD. Turn band switch and Delete/Add FM Radio: UHF/FM:Add FM Radio UHF: Delete FM Radio Press [PTT] key/ key to confirm and exit. FM radio scan Under FM mode,press key/ Key and hold until beeping "DU"...
  • Page 27: Shortcut Function Setup

    SHoRTCUT FUNCTIoN SeTUP editing Channels Walkie talkie under VFO mode/FM radio VFO mode,input the frequency you want and then do relevant setup; After press show on LCD,then press key,the LCD display the channel NO. icon; Turn channel switch or press key/ key,to choose the momery channel NO.you want;...
  • Page 28: Squelch Levels Setup

    SHoRTCUT FUNCTIoN SeTUP Turn channel switch or press key/ key,to choose the offset frequency channel NO.you want ; Press [PTT] key and then press key until transceiver voice beeping of "Du",namely,the offset frequency channel mode is being "+"icon display on LCD :namely transmiting frequency is higher than receiving "-"icon display on LCD :namely transmiting frequency is lower than receiving Squelch levels setup The function is for seting the receiving radio signal.When signal reach certain value you could hear the sender calling ,if not the...
  • Page 29: Ctcss/Dcs Encode Setup

    SHoRTCUT FUNCTIoN SeTUP CTCSS/DCS encode Setup In standby state,press key , display on LCD and then press key ,"TX-Co" display on LCD; Press key to choose CTCSS ,DCS or OFF .When DCS signaling is selected ,press choose DCS positive or inverse code; Turn channel switch or press key to choose the desired CTCSS/DCS encode singaling...
  • Page 30: Frequency Step Size Setup

    SHoRTCUT FUNCTIoN SeTUP Frequency Step size setup Only under frequency mode,frequency setp size is valid. frequency input or scan will be connected with the frequency setp size. .In standby state,press key , display on LCD and then press key."STeP" display on LCD; Turn channel switch or press key to choose the desired frequency.
  • Page 31: Frequency Reverse

    SHoRTCUT FUNCTIoN SeTUP In standby state,press key , display on LCD and then press key the VOX function to be on/off; " VoX" display on LCD.Namely ,the VOX function is on; " VoX" disappear on LCD.Namely ,the VOX function is off . Frequency reverse When the frequency reversion function.The transmitting frequency and receiving frequency are interchanged, namely, receiving frequency switches to transmitting frequency while transmitting frequency switches to receiving frequency.
  • Page 32: Dtmf Code Transmitting

    SHoRTCUT FUNCTIoN SeTUP DTMF Code Transmitting Press and hold [PTT] key, then enter the desired number by key; DTMF code transmitting In standby state,press key , display on LCD and then press key display the desired group and DTMF data; A�...
  • Page 33: Channels Scan Skip

    SHoRTCUT FUNCTIoN SeTUP When wakening, “WAKeN” is showed on LCD. NoTe: Remotely stun code should be edited in the programming software.14digits are the maximum. ATTeNTIoN: When remotely kill or remotely stun is wakened, transceiver returns to normal operation. Channels scan skip under Channel mode, after pressing display on LCD and then press key to set...
  • Page 34: Switch Between Vfo And Frequency +Channel Mode

    SHoRTCUT FUNCTIoN SeTUP NoTe Frequency scan is of all bangs scan.When scanning ,it can uo as your setpping setting When channel scanning,the skipped channel is not in the line of scan.Scan up as per channel no. (please refer to channel scan skip) Frequency/ channel scan direction by pressing key .When finding a matching carrier wave and signaling.The transceiver will be stop and then going on scan.(please refer to channel scan skip)
  • Page 35: Function Menu Setup

    FUNCTIoN MeNU SeTUP After pressing key, the LCD displays and then press key to enter function menu; Turn band switch or press key to choose the desired function to be set; Press key to enter into function menu setup,the setup value display on LCD; Turn band switch Press key to choose the desired contents to be set;...
  • Page 36: Ctcss/Dcs Encode Setup

    FUNCTIoN MeNU SeTUP Press key to enter into function menu setup,the setup value display on LCD; Turn band switch Press key to choose the desired power; HIGH :namely transmiting frequency is high LoW :namely transmiting frequency is low press key to return to upward menu. Press [PTT] or key to confirm and exit.
  • Page 37: Ctcss/Dcs Decode Setup

    FUNCTIoN MeNU SeTUP CTCSS/DCS decode setup If enable this function,you can't hear the other party's calling at the same frequency. After pressing key , the top left corner of LCD displays and then press key to enter into function menu.; Turn band switch or press key to choose No.4 function item.
  • Page 38: Frequency Step Size Setup

    FUNCTIoN MeNU SeTUP "+"icon display on LCD : namely transmiting frequency is higher than receiving.When reverse frequency is opened,the receiving frequency is higher than transmiting . "-"icon display on LCD : namely transmiting frequency is lower than receiving.When reverse frequency is opened,the receiving frequency is lower than transmiting . Nothing show : the Offset frequency direction is closed .
  • Page 39: Voice Operated Transmission (Vox) Setup

    FUNCTIoN MeNU SeTUP frequency. If CTCSS / DCS signaling is set, it will also interchange. After pressing key , the top left corner of LCD displays and then press key to enter into function menu; Turn band switch or press key to choose No.7 function item.
  • Page 40: Vox Level Setup

    FUNCTIoN MeNU SeTUP VoX Level Setup The function is for seting the receiving radio voice.When the level is higher the voice is much big,opposite the voice will much small. 1.After pressing key , the top left corner of LCD displays and then press key to enter into function menu;...
  • Page 41: Non-Signaling Tail Tone Elimination

    FUNCTIoN MeNU SeTUP Non-signaling Tail Tone elimination After pressing key , the top left corner of LCD displays and then press key to enter into function menu; Turn band switch or press key to choose No.11 function item. It shows “RoG-T” on LCD; Press key to enter into function menu setup,the setup value display on LCD;...
  • Page 42: Frequency Reverse Setup

    FUNCTIoN MeNU SeTUP Frequency Reverse Setup This function works to wake up repeater. Press [PTT] and then press [PF1] to send the desired offset frequency . After pressing key , the top left corner of LCD displays and then press key to enter into function menu;...
  • Page 43: Vox Beep Setup

    FUNCTIoN MeNU SeTUP 240MIN:after 240 mins automatic shutdown press key to return to upward menu. Press [PTT] or key to confirm and exit. Vox Beep Setup After pressing key ,the LCD display and then press key to enter into function menu; Turn band switch or Press key to choose NO.15 function item .It shows “KeY BP”...
  • Page 44: Fm Radio Return Time Setup

    FUNCTIoN MeNU SeTUP oFF:Normally close Press key to come back into function menu setup,press [PTT]/ key to confirm and exit the function menu setup . FM Radio Return Time setup This function works to setup the time after receiving or tramitting to return FM radio. (only when open the FM radio the function is value) After pressing key ,the LCD display...
  • Page 45: Scan Dwell Time Setup

    FUNCTIoN MeNU SeTUP Turn band switch or Press key to choose NO.18 function item .It shows “SAVe” on LCD; Press key to enter into function menu setup,the current setup value show on LCD; Turn channel switch or press key to choose the desired setup; oFF: Battery saving is disabled 1:2: The ratio between normal working state and battery saving mode as 1:2 1:3: The ratio between normal working state and battery saving mode as 1:3...
  • Page 46: Time-Out-Timer

    FUNCTIoN MeNU SeTUP Time-out-Timer The purpose of Time-out-timer is to restrict transceiver for continuous long-term transmission. When the continuous transmission time is beyond the due time, transceiver is forced to stop transmitting and make a sound of beeping. After pressing key ,the LCD display and then press key to enter into function menu;...
  • Page 47: Dtmf Group Code Setup

    FUNCTIoN MeNU SeTUP Turn band switch or press key to choose the desired Offset Frequency ; Frequency range:0-19.995MHZ; Press key to come back into function menu setup,press [PTT]/ key to confirm and exit the function menu setup. DTMF Group Code Setup After pressing key ,the LCD display and then press...
  • Page 48: Dtmf Turn Off Time Setup

    FUNCTIoN MeNU SeTUP DTMF Turn off Time setup After pressing key ,the LCD display and then press key to enter into function menu; Turn band switch or Press key to choose NO.24 function item .It shows “DTMF S” on LCD; Press key to enter into function menu setup,the current setup value show on LCD;...
  • Page 49: Busy Channel Lock

    FUNCTIoN MeNU SeTUP Busy Channel Lock Enable BCL, carrier wave lockout, transmitting is prohibited when current channel receives a matching carrier wave. BCLO is to disable transmitting while RX signal is received. Once the channel is busy and you press [PTT], the radio will beep as warning and get back to receiving.
  • Page 50: Editing Channel Name

    FUNCTIoN MeNU SeTUP FReQ: in storage mode display Channel+Name Tag mode ; NAMe: in storage mode if the current channel mode has edit the name ,display the channel name tag + channel NO. CH: The product only could work in channel mode Press key to come back into function menu setup,press [PTT]/ key to confirm and exit the function menu setup.
  • Page 51: Signaling Relations Setup

    FUNCTIoN MeNU SeTUP Press key to enter into function menu setup,the current setup value show on LCD; Turn band switch or press key to choose the desired setup; DTMF:turn on the optional signal oFF:turn off the optional signal Press key to come back into function menu setup,press [PTT]/ key to confirm and exit the function menu setup.
  • Page 52: Function Icon Dwell Time Setup

    FUNCTIoN MeNU SeTUP After pressing key ,the LCD display and then press key to enter into function menu; Press key to choose NO.31 function item .It shows “W/N” on LCD; Press key to enter into function menu setup,the current setup value show on LCD; Turn channel switch or press key to choose the desired setup;...
  • Page 53: Current Battery Voltage Enquiry

    FUNCTIoN MeNU SeTUP ALWAYS:the function icon always display on the LCD. Press key to come back into function menu setup,press [PTT]/ key to confirm and exit the function menu setup. Current Battery Voltage enquiry After pressing key ,the LCD display and then press key to enter into function menu;...
  • Page 54: Display Character Defined By User

    FUNCTIoN MeNU SeTUP Press key or press [PTT]/ key to confirm and exit the function menu setup. Display Character Defined By User After pressing key ,the LCD display and then press key to enter into function menu; Press key to choose NO.35 function item .It shows “BTNAMe” on LCD; Press key to enter into function menu setup,the current setup value show on LCD;...
  • Page 55: Programming Software Starting(Takes Window Xp For Example)

    PRoGRAMMING SoFTWARe STARTING (TAKeS WINDoW XP FoR eXAMPLe) 1.Double click “WPS-301 setup.exe” and then go on installing as computer command. 2.Click “START” menu, choose “USB To Comport” in the WPS-301 entry from “ALL PROGRAMS” and click it. Please install USB To Comport drive program as computer command.
  • Page 56: Technical Specifications

    TeCHNICAL SPeCIFICATIoNS General Intermodulation ≥60dB ≥60dB +1~-3dB +1~-3dB VHF:136-174MHz Audio Response Frequency Rang (0�3~3KHz) (0�3~2�55KHz) UHF:400-480MHz (EX 400-520MHz) Hum & Noise ≥50dB ≥45dB Channel Capacity 200 channels Audio Distortion ≤5% Channel Spacing 25KHz (Wide Band) 12�5KHz (Narrow Band) Audio Power Output 500mW( at 10% ) Phase-locked Step 5KHz, 6�25KHz,10KHz,12�5KHz,25KHz Operating Voltage 7�4V DC ±15% Transmitting Part...
  • Page 57: Trouble Shooting Guide Elimination Method

    TRoUBLe SHooTING GUIDe eLIMINATIoN MeTHoD Problem Corrective Action The battery may be exhausting. Recharge or replace the battery. The battery may not be installed correctly. Remove the battery and install it again. No power The power switch is broken; send it to local dealers to repair. Battery touch is broken;...
  • Page 58: Attached Chart 1

    ATTACHeD CHART 1 CTCSS Frequency Chart 62�5 94�8 136�5 177�3 218�1 67�0 97�4 141�3 179�9 225�7 69�3 100�0 146�2 183�5 229�1 71�9 103�5 151�4 186�2 233�6 74�4 107�2 156�7 189�9 241�8 77�0 110�9 159�8 192�8 250�3 79�7 114�8 162�2 196�6 254�1 82�5 118�8...
  • Page 59: Attached Chart 2

    ATTACHeD CHART 2 DCS Frequency Chart NoTe: 1� "N" stands for positive code� "I" stands for inverted code� 230 groups of DCS in total� 2� Overstriking marks are non-standard DCS...
