Installation Manual
AI-HUB-03-x
Data Interface Switch Module
Document # 540316
a DeCrane Aircraft Company
7300 Industry Drive, North Little Rock, AR 72117
Phone: 501-955-2929 Fax: 501-955-2988
www.audiointl.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AI-HUB-03-x and is the answer not in the manual?

Questions and answers

Summary of Contents for Audio international AI-HUB-03-x

  • Page 1 Installation Manual AI-HUB-03-x Data Interface Switch Module Document # 540316 a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
  • Page 2: Document Revision History

    Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. Document # 540316, Rev IR, 03/2006...
  • Page 3: Table Of Contents

    Audio International, Inc. AI-HUB-03-x Installation Manual Table of Contents Section Description Page General Information …………………………………………….. Introduction ………………………………………………………… Purpose of the Equipment ……………………………………….. Optional Equipment ………………………………………………. Application ………………………………………………………... Introduction ………………………………………………………… Multiple Switching Options ..……………………………………… Block Diagram – Typical Application ……………………………. Installation …………………………………………………………...
  • Page 4: General Information

    General Information Introduction This manual contains information for the proper installation of the Audio International, Inc. (AI) Data Interface Module, Model No: AI-HUB-03-x. The “-x” suffix designates the type of connector utilized; “-1” = Positronic and “-2” = D-Subminiature. Also included are physical and electrical characteristics of the unit.
  • Page 5: Application

    The port is operating in half- duplex mode Multiple Switching Options 2.2.1 The AI-HUB-03-x may be used as a switch to segment a network into multiple connected pieces, increasing overall bandwidth and throughput. 2.2.3 Ethernet specifications limit the length of cable between hubs and PCs to 100 meters for a total of 200 meters.
  • Page 6: Block Diagram - Typical Application

    Audio International, Inc. AI-HUB-03-x Installation Manual Block Diagram – Typical Application Document # 540316, Rev IR, 03/2006 Page 5 of 12...
  • Page 7: Installation

    • Environmental conditions (temperature, humidity, etc.) • Length of cable runs 3.1.2 The AI-HUB-03-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation.
  • Page 8: Wiring Requirements

    Audio International, Inc. AI-HUB-03-x Installation Manual 3.3.4 A one (1) inch air space, MINIMUM, is required on top of the unit for internal cooling fan air circulation. 3.3.5 DO NOT install near heat sources such as direct sunlight, warm air exhausts, or heaters.
  • Page 9: Physical Characteristics

    Audio International, Inc. AI-HUB-03-x Installation Manual 3.4.2 Power Wires Audio International recommends the chassis be electrically bonded to the airframe structure by a conductive mounting point with <0.1 Ω resistance using <50 Ω impedance cable. Aluminum wool, nylon webbing impregnated with aluminum oxide abrasive or fiber bristle brushes are the approved tools for removing anodized surfaces at mounting point where the bonding wire is attached.
  • Page 10: Mating Connector Information

    Introduction, for the LEDs and their activity. Instructions for Continued Airworthiness Airworthiness Limitations No periodic scheduled maintenance or calibration is required for continued airworthiness of the AI-Hub-03-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility.
  • Page 11: General Troubleshooting Procedures

    Audio International, Inc. AI-HUB-03-x Installation Manual General Troubleshooting Procedures Many problems can be isolated with the following general techniques: • To verify power to the unit, recheck +28 VDC power is applied to the proper pins on the unit. Use a voltmeter to verify correct level.
  • Page 12: Specifications

    (l x w x h) 15.9 cm x 26.5 cm x 3.8 cm Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the AI-HUB-03-x. Document # 540316, Rev IR, 03/2006 Page 11 of 12...
  • Page 13 Audio International, Inc. AI-HUB-03-x Installation Manual Document # 540316, Rev IR, 03/2006 Page 12 of 12...
