displayed value to 3 times. If no change is made for 0,5 sec. or longer or the MODE
button is pressed the relative settings become active. The display will only show the
values presently being viewed or changed. After 30 sec. of no alterations or if the
MODE button is pressed the display returns to show "GDMX".
IN PRES (preset mode), the channel assignment is as follows:
CH1 = 000-255: Color presets ST1....ST25 as in Static Color Mode [If CH3 < 050]
CH1 = 000-127: Fade presets FP0...FP7 as in Switch Pattern Mode [If CH3 ≥ 050]
CH1 = 128-255: Fade presets SP0...SP8 as in Fade Pattern Mode [If CH3 ≥ 050]
CH2 = 000-255: Master Dimmer 0-100%
CH3 = 000-049: Color preset mode selection (color by CH1)
CH3 = 050-255: Pattern preset mode selection and speed setting (pattern by CH1)
CH4 = 000-049 Strobe off
CH4 = 050-255 Strobe with adjustable speed (050=slow / 255=max. speed)
NOTE: Whenever a DMX signal is received, the "D" tab in the display is lit – this is valid
for all DMX-related modes.
The DMX channel setting is global – if you change the control mode/channel scheme
later, the DMX start address will remain valid, but the number of consumed channels
may change.
DO NOT try to leave the control mode/channel scheme choice by pressing the left/right
arrow buttons; this would change the control mode/channel scheme to the next
subsequent choice. Always leave this mode by either pressing the MODE button or by
simply waiting until the display returns to show "GDMX.
■ COLOR BALANCE
In this Mode you can define your individual fixture's Color Balance by setting a
maximum brightness for each LED colour giving you the individual color balance you
desire. Press the MODE button until the display shows "CBAL". Use the left/right arrow
buttons to select any of the following options: „Rxxx", „Gxxx", „Bxxx", „Axxx" and „Wxxx"
with „xxx" being values between 200 and 255. Value settings below 200 are disabled to
avoid unwanted output reduction of the fixture. If you want to change the maximum
output of the colour being displayed use the +/- buttons to do so. For control purposes
all LED's are lit with their chosen maximum value. All changes made become effective
immediately. If pressing the MODE button during editing a color level, the display
returns to 'CBAL'.
Note: Any settings made in this mode will influence the overall color balance of the
fixture (in all available operation modes – also DMX). To make sure that several fixtures
