EIPR Series

Skorpion Wired and Wireless VPN Routers

Installation Guide

The EIPR Series provides routing between a wide-area-network (WAN) and a local-area-

network (LAN) — which features a four-port 10/100 Mbps Ethernet switch. The two models

are identical except for their USB port functions. The EIPR-E can act as a Wi-Fi access

point with the connection of a Wi-Fi adapter. The EIPR-V does the same, but the USB port

can also support a cellular adapter for wireless WAN communication (in which case the

wired WAN port is automatically deactivated). The EIPR-V also adds virtual private

network (VPN) firmware and a real-time clock — so that it can function as a VPN client.

Each port automatically negotiates with connected devices. Thus, the EIPR can provide

plug-and-play operation with no configuration unless required for advanced routing features

or when non-default operating parameters are required. In these cases, default behaviour

can be modified from a LAN port

via its built-in web server located at 192.168.92.1. By

default, its WAN port is assigned an IP address via the built-in DHCP client. An internal

DHCP server assigns IP addresses to LAN-connected devices. Through its WAN port, the

built-in DNS forwarder passes DNS requests from a LAN host to a remote DNS server.

. An internal half-wave rectifier allows sharing a common AC power source with other

half-wave devices. Voltage must deliver current commensurate with 9 VA power consumption.

Power conductors should be 16–22 AWG (solid) or 16–18 AWG (stranded). Common is

connected to 0 V. Chassis is isolated from 0 V. Inputs are reverse-polarity protected.

Table of Contents

Do you have a question about the EIPR series and is the answer not in the manual?

Page 1: Installation Guide
Skorpion Wired and Wireless VPN Routers Installation Guide The EIPR Series provides routing between a wide-area-network (WAN) and a local-area- network (LAN) — which features a four-port 10/100 Mbps Ethernet switch. The two models are identical except for their USB port functions. The EIPR-E can act as a Wi-Fi access point with the connection of a Wi-Fi adapter.
Page 2: Led Indicators
Specifications RJ-45 Pin Assignments Environmental Pin Function Operating Temp: 0°C to +60°C –40°C to +85°C Storage Temp: TD– Humidity: 10–95%, non-condensing DIN-rail Mounting TS-35 RD– (other pins are unused) Regulatory Compliance USB Pin Assignments CE Mark; CFR 47 Part 15, Class A UL508 Industrial Control Equipment Pin Function Functional...
Page 3 Wired Network Connections Auto-MDIX allows connections to other equipment with either crossover or straight-through cabling. Initial Access Setup. When first installing the EIPR, its default address could match that of a device on the Ethernet LAN and its DHCP server could interfere with your existing LAN devices.
Page 4 Reset Switch . The Reset Switch (located just below the Power LED) will restore factory default settings including the IP address, netmask and subnet settings. To reset the router to its default values, use a paperclip or similar tool to press the Settings Reset button for at least 3 seconds while the router is powered.
