Platinum Line Component System

CS 275.28 Platinum

CS 275.28 Platinum active

Please read installation manual carefully before beginning installation!

RAC GmbH & Co. KG - P.O. Box 1225 - 74899 Bad Rappenau - Germany

Installation Manual for

Telephone +49-7066 / 9006 0 - Telefax +49-7066 / 9006 50

http://www.rainbow-audio.de

2-Way Component System

180 Watt

Part No. 231444

180 Watt

Part No. 231445

Table of Contents

Need help?

Do you have a question about the CS 275.28 Platinum and is the answer not in the manual?

Questions and answers

Summary of Contents for Rainbow CS 275.28 Platinum

Page 1 Platinum Line Component System CS 275.28 Platinum 2-Way Component System 180 Watt Part No. 231444 CS 275.28 Platinum active 2-Way Component System 180 Watt Part No. 231445 Please read installation manual carefully before beginning installation! RAC GmbH & Co. KG - P.O. Box 1225 - 74899 Bad Rappenau - Germany Telephone +49-7066 / 9006 0 - Telefax +49-7066 / 9006 50 http://www.rainbow-audio.de...
Page 2: Important Safety Instructions
Use of sound components can impair your ability to hear necessary traffic sounds and may constitute a hazard while driving your automobile. Rainbow® accepts no liability for hearing loss, bodily injury or property damage as a result of use or misuse of this product.
Page 3: Table Of Contents
Attaching the Crossover Dear valued customer, We congratulate you on your purchase of our superior product and thank you for placing your trust in Rainbow®. We have put together this installation manual with great consideration of different mechanical and acoustical auto features.
Page 4: Contents And Detail Of Parts
For the purpose of technical safety, the loudspeaker should only be attached with the included self-tapping screws. We accept no liability for use of alternative methods of attachment. Contents and Detail of Parts Fastening for Woofer: grill 175 mm ∅ metal, grey with Rainbow logo 2 pieces woofer 175 mm ∅ 2 pieces 8 pieces self-tapping screw 4.0 x 30 V2A stainless steel Pan Head...
Page 5: Technical Data
Technical Data System CS 275.28 Platinum Peak power handling 180 W Power rating 120 W Sensitivity 90 dB 1W/1m Frequency response 35– 26.000 Hz 4 Ω Impedance Crossover 2-Way Slope 2 x 24 dB / Octave Crossover frequency 2.200 Hz...
Page 6: Positioning The Loudspeaker
24 dB coupling of the individual loudspeakers. Positioning the Loudspeaker Rainbow loudspeakers may be installed in your vehicle in a variety of places. In determining the installation location the following information should be considered: •...
Page 7 Standard installation in undefined door volumes This form of installation is unsatisfactory and should only be used as a provisional arrangement, since it does not allow optimum Qts-factor. Moreover, holes in the door or leakage in the cladding may cause parasitic reflexions and impair the reproduction at low frequencies.
Page 8 Door Installation: In order to achieve optimal frontstaging, the tweeters should not be placed too deeply in the door area. They should be installed, for instance, at shoulder height and as far forward as possible, in the vicinity of the instrument panel. Suitable installation positions here are the side view mirror area and the upper door lining. Placing the tweeters on diagonal spacer rings (about 20°) can be tonally advantageous, if thereby the arrangement is done in such a way that the left tweeter radiates to the right door and/or right seat and the right tweeter radiates sound toward the left door and/or the left seat.
Page 9: Installing And Attaching The Woofer
Installing and Attaching the Woofer Note: Do not attach via or puncture the membrane. Do not damage the membrane with a screwdriver or other sharp tool. • After selecting the installation location, attach the installation template at the designated location, e.g. with double-sided tape, amd mark the necessary drill holes and the space for the woofer.
Page 10: Installing And Attaching The Tweeter
Installing and Attaching the Tweeter Installation Location: Door Installation (front/rear), rear installation, side view mirror area installation, instrument panel installation, and rear windshield deck installation • Fix the installation template of the tweeters at the selected location with tape and, along the indicated line, carefully cut and smooth edges.
Page 11: Cable Preparation
Cable Preparation Shorten tweeter cable (e.g. AIV Silverado with at least 1 mm²) to the appropriate length and strip both ends. Insert the red conduit cover (+) over the appropriately marked conductor and the black cover (-) over the remaining conductor.
Page 12: Connecting The Crossover
around at least 6 dB quieter than on the front passenger side. For optimal positioning, a professional dealer, who can more accurately position the frequency response using specific measuring instruments, should be contacted. Note: It is important that all loudspeakers are correctly attached before start-up of the crossovers. If the crossovers are set into operation without the loudspeakers being hooked up, a very high current is produced on the unloaded LC-filters, which can, under the circumstances, destroy the coils! The jumpers of the crossovers must always be placed on the specified pins, according to the instructions.
Page 13 Connection of Woofer: Attach prepared loudspeaker cable (at least 2.5 mm²) at the screw connections „Woofer out” of the crossover (see fig. 9, No. 5), whereby the marked wire is connected with the positive terminal “+” and the unmarked wire with the minus connection “-“.
Page 14 Jumper position on crossover switchboard (see figure x, No.1 / bold is default position): • J3: A-B = Close = Tweeter SPL-Level -12dB „Reference“ frequency reponse gliding -2dB per octave Recommended with installation of the tweeters directly in the listening axis and/or ear proximity, e.g., A- or B-pillar, front instrument panel area with strong windshield reflection, or rear installation in direct proximity of the back window •...
Page 15 • J2: A-B = Close = 24dB high pass B-C = Close = 18dB high pass with phase correction J2 should be in A-B position if woofer and tweeter are on axis J2 should be in B-C position if woofer and tweeter are out off axis (e.g.
Page 16 Warranty With this user warranty Rainbow provides a 5 year warranty against defective material and workmanship for the Platinum Line CS 275.28 beginning with the acquisition of the product by the authorized dealer, is entitled only to the direct first buyer, and is non-transferable.
