- Page 1 User Manual ·...
-
Page 2: Table Of Contents
User Manual Contents CONTENTS .................................. 1 SAFETY INSTRUCTION .............................. 4 CHAPTER 1 FEATURES AND FUNCTIONS ........................ 1 CHAPTER 2: OVERVIEW .............................. 2 ................................... 2 RONT ANEL 2.1.1 4/8/16 CH DVR Front Panel .......................... 2 2.1.2 4/9/16 CH DVR Front Panel .......................... 4 2.1.3 4/8/16 CH DVR Front Panel .......................... 5 ... - Page 3 User Manual 5.3.3.5.2 back-up file based on time ............................ 23 5.3.3.5.3 Play backup file ................................ 23 5.2.3.6 Log Search .................................... 25 5.2.4 Network .................................. 25 5.2.4.1 Network set ..................................... 25 5.2.4.2 Mobile Set .................................... 26 5.2.4.3 Router’s Port Forwarding ................................. 27 5.2.4.4 Sub stream .................................... 27 5.2.4.5 Email set .................................... 27 5.2.4.6 DDNS Set .................................... 28 5.2.5 Alarm .................................. 28 ...
- Page 4 User Manual 6.3.3.3 Network Parameters ................................ 42 6.3.3.4 Alarm Set .................................... 43 6.3.3.5 Device ...................................... 44 6.3.3.6 System ...................................... 44 6.3.3.7 Advanced .................................... 45 6.3.4 Local setting ................................ 46 6.3.5 Logout .................................. 47 CHAPTER 7: APPENDIX .............................. 4 8 .............................. 48 PERATION UNCTION ABLE ................................ 49 ...
-
Page 5: Safety Instruction
User Manual Safety Instruction 1. Read Instruction All the safety and operating instruction should be read before the equipment is operated. 2. Power sources This equipment should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power, please consult your equipment dealer. -
Page 6: Chapter 1 Features And Functions
User Manual Chapter 1 Features and Functions Function Brief and Description Double video output; with monitor, VGA virtual output port or HDMI Output; Real time Support net-viewer and MP live surveillance and also support zoom in/out, monitoring auto sequence and PIP display. H.264 video compression format;... -
Page 7: Chapter 2: Overview
User Manual Chapter 2: Overview 2.1 Front Panel Reminder: DVR is the abbreviation of Digital Video Recorder Equipment. 2.1.1 4/8/16 CH DVR Front Panel HV-04TS/HV-08TS/HV-16TS Key title Item Remark Function & Description or Indicator Connect to USB2.0 port USB Port... - Page 8 User Manual HV-04OU/HV-08OU/HV-16OU Item Key title or Indicator Remark Function & Description If the “Green” indicator is on the system is getting power Power Indicator normally. IR Receiver Receives IR signal from Remote Controller When the “Red” indicator flashes it means the hard drive is HDD Indicator being read or written to.
-
Page 9: 4/9/16 Ch Dvr Front Panel
User Manual 2.1.2 4/9/16 CH DVR Front Panel HI-9904EN / HI-9909EN / HI-9916EN Marks Function Item Key title /Indicator If the “Green” indicator is on the system is getting power Power indicator normally. Start manual record Play PLAY Convert to play status When the “Red”... -
Page 10: 4/8/16 Ch Dvr Front Panel
User Manual 2.1.3 4/8/16 CH DVR Front Panel HI-1004/HI-1008/HI-1016 Key title Rema Item Function & Description Indicator If the “Red” indicator is on the system is getting power Power Indicator normally. When the “ Green” indicator flashes it means the hard HDD Indicator drive is being read or written to. -
Page 11: Ch Dvr Front Panel
User Manual 2.1.4 32 CH DVR Front Panel Marks Item Function Receives IR signal from Remote Control Select OK to operate ENTER 3\4\5\6 Move up\down\left\right Number key; Single Channel display 0~16 POWER indicator HDD indicator READY Ready indicator STATUS Status indicator RECORD HDD video indicator... -
Page 12: Rear Panel
User Manual 2.2 Rear Panel 2.2.1 OU Series/TS Series DVR Rear Panel HV-04TS/HV-08TS/HV-16TS / HV-04OU/HV-08OU/HV-16OU Item Physical port Connection method Connect CH1-4/8/16 (Virtual) video input BNC interface Video input Video output (BNC interface) Video output 1/4CH audio input (RCA interface... -
Page 13: Hi-9904En/Hi-9909En/Hi-9916En Dvr Rear Panel
User Manual 2.2.2 HI-9904EN/HI-9909EN/HI-9916EN DVR Rear Panel HI-9904EN Item Physical port Connection method Audio input Connect CH1-4 audio signal input (BNC interface) Loop output CH1-4 Loop output (BNC interface) Video input Connect CH1-4 (Virtual) video input BNC interface Audio output 1CH Audio output (BNC interface) Video output 1CH Video output (BNC interface) -
Page 14: Hi-1004/Hi-1008/Hi-1016 Dvr Rear Panel
User Manual HI-9916EN Item Physical port Connection method Video input Connect CH1-16 (Virtual) video input BNC interface Video output (UP) Main video output; (Down) Spot output (BNC interface) Audio output 2CH Audio output (RCA interface) Loop Out Connect (CH1~CH16) Loop Output IR-EXT IR-EXT Output Audio input... -
Page 15: 32Ch Dvr Rear Panel
User Manual Item Physical port Connection method Connect CH1-4/8/16 (Virtual) video input BNC interface Video input Video output (BNC interface) Video output 1/4CH audio input (RCA interface Audio Input HDMI Output HDMI Connect LAN, Ethernet (RJ45 interface) Ethernet: Port Connect USB/USB mouse USB Port Connect power supply - DC12V 2A/5A Power Port... -
Page 16: 4/8/9/16-Ch Remote Controller
User Manual RS485/Sensor/Alarm port functions: Alarm input: Connect [-] port of your sensor to G (GND) pin, and [+] port to channel input according to the alarm device you purchased. Alarm output: Connect to the two ports marked with “out” PTZ Port Connect your camera to RS-485A and RS485B accordingly. -
Page 17: 16/32-Ch Remote Controller
User Manual 2.4 16/32-CH Remote Controller Key Title Key Function Press the button to enter into manual record. SEARCH Press the button to enter into record search menu Enter into Quad display 2×2 3×3 Enter into 9-split display Enter into 16-split display 4×4 AUTO Enter into dwell time display... - Page 18 User Manual Mouse Operation Except using buttons of front panel or remote controller, you also can use mouse to perform system operation. TYPE Function In menu lock mode, Enter into pop-up menu and clicking any sub menu to pop up Log-in window; on menu unlock mode, enter into pop-up menu, and then clicking left key to enter into any sub menu directly.
-
Page 19: Chapter 3 Dvr Connection
User Manual Chapter 3 DVR CONNECTION 3.1 HDD Installation Caution： Please do not Install or take out hard drive when DVR is running! HDD Installation: (1) Cut power firstly, and then remove screws and open DVR upper cover carefully; (2) Insert Power Cord and data cable into Pin of hard drive securely; (3) Remove the screws on the HDD bracket;... -
Page 20: Live Interface
User Manual 4.2 Live Interface After finishing initialization the system will enter into <Live> screen. Picture 4-2 is the 16-split display defaulted by system, which is showing no video input status. Once there are video inputs, the screen will display live images from the cameras. In Live mode, if you use the mouse to double-click the live image of any channel, the image will be maximized to full screen, by double-clicking again, image will be come back to... -
Page 21: Main Menu Guide
User Manual 5.1 Main Menu Guide Live set Display Output Set Privacy Zone Record Parameters Record Schedule Main Stream Record Search Clip Set Record Playback Search Backup Event Search Log search Network Set Sub stream Main Menu Email Set Network Mobile Set DDNS Set Motion Detection... -
Page 22: Main Menu
User Manual 5.2 Main Menu On <Live> mode, click [Menu] button on the front panel or Remote controller to enter into Main menu interface shown as Picture 5-2. And also you can click [ ] icon to enter the main menu screen. - Page 23 User Manual Go to [Main menuDisplayOutput] Click [Live] to pop up the interface to enter into the output set interface shown as Picture 5-6. Now you could shown as Picture 5-5. perform channel sequence setting. Picture 5-6 Picture 5-5 Click [Spot output] option and set relative Click [Spot sequence] to enter into the parameters shown as Picture 5-7.
-
Page 24: Privacy Zone
User Manual 5.2.1.3 Privacy Zone The function Allow you setup privacy zone parameters according to Picture 5-12. Each channel could set up to four privacy zones, and please follow below steps to set: 1. Select the area no (Area 1 ~ Area 4); 2. -
Page 25: Main Stream
User Manual After you complete the schedule you activate it by clicking the [Apply] button. You can also click on the Default button to use the system defaults. Explanation: Under the <record> menu and <search> menu, original color stands for no record, “Red” stands for alarm record, “yellow”... -
Page 26: Channel Select
User Manual 5.2.3.2 Channel Select Then tick-select the channel you want to playback; Click [Main MenuSearchRecord search] and click [Play] button to enter into the playback to enter into the interface shown as Picture mode shown as Picture 5-19 5-18 Picture 5-18 Picture 5-19 5.2.3.3 Time Axis setup, file clip and zoom in/out... -
Page 27: Event Search
User Manual Record Clip and backup function and Zoom in/out function Picture 5-19B-2 Picture 5-19C Clip and backup: When one channel is playing-back, the [ ] icon will appear in the [Play control] bar shown as Picture 5-19B-1. Click the icon to start video clip function, click it again to end the function and pop up the dialog shown as Picture 5-19B-2. -
Page 28: Back-Up File Based On Time
User Manual Select DVD as backup In the [File List] mode, if you Select USB as backup device device and click [Apply] button, wish to backup records, please and click [Apply] button, and and then enter into the window tick-select the BAK check-boxes then enter into the window shown as Picture 5-23. - Page 29 User Manual Picture 5-25 Picture 5-26 Play button: click the icon to playback the backup record; Pause button: click the icon to pause the backup record; Stop button: click the icon to stop the backup record; Next: Click the icon to play next record; Prev.: Click the icon to play previous record FF button: click the icon to fast forward the backup record at x2, x4, x8 and/or x16 speed.
-
Page 30: Log Search
User Manual 5.2.3.6 Log Search Herein allow you preview the log information you Go to [Main menuSearchLog] option to have searched. And click [Backup] to export all enter into the Log search interface shown as the log information which is listed. For other Picture 5-28. -
Page 31: Mobile Set
User Manual Friendly Reminder: All the parameters you set are available only when you click [Apply] and after system are restarted. User need to change MAC address when there are multiple DVRs at the same local area network. Details please refer to section 5.6.2.5 -System Information. When selecting Static from the Type, user can directly input IP address, Subnet Mask, Gateway and DNS shown as below picture 5-32. -
Page 32: Router's Port Forwarding
User Manual Configure network parameters, details please refer to section 5.2.4.1. Configure mobile port no (such as 19011); and the port need forward to router. Details please refer to Section 5.2.4.3. Save the parameters and exit Main Menu; System auto restart; User name and password of mobile is consistent with DVR 5.2.4.3 Router’s Port Forwarding Port forwarding is required when you want to access the DVR connected to the router from outside of the... -
Page 33: Ddns Set
User Manual SMTP Port: indicate one kind of mail transmittal port opened by Simple Message Transfer Protocol (SMTP). The port number for most mails is 25 except such as Gmail server (Port No.: 465). SMTP server: indicates server address you used. ... -
Page 34: Alarm Set
User Manual Latch time: you can set how long the buzzer will sound when object move is detected (10s, 30s, 40s, 60s); Show Message: You can set show message on the screen when motion alarm is detected. Buzzer time: you can set how long the buzzer will sound when motion is detected (off, 10s, 30s, 40s, 60s);... -
Page 35: Device
User Manual Post Recording: you can set how long alarm record will last when alarm ends (30s, 1minute，2minutes， 5minutes); Copy: allow you copy all the setting of one channel to other ones. Alarm Type Function Sends alarm when DVR can’t receive video signal (such as camera damage, cable broken or Video Loss damaged or power supply malfunction). -
Page 36: Ptz Set
User Manual 5.2.6.2 PTZ Set Click [Main MenuDevicePTZ] to enter into the below window shown as Picture 5-47. You could select the channel you desire to control and set PTZ protocol (Pelco-D or Pelco-P), Baud Rate (1200, 2400, 4800, 9600), Data bit (8, 7, 6, 5), Stop bit (1, 2), Parity Check (None, Odd, Even, Mark, Space), Address Code and Cruise status respectively. -
Page 37: Users
User Manual Picture 5-51 Picture 5-50 Note: The above [NTP function] change will be available only when system connected to internet. And When NTP function is set to “Enable”, system will calibrate the time at every 00:07:50 and every start-up. 5.2.7.2 Users Click [Main MenuSystemusers] option and then enter into the interface shown as Picture 5-51 Picture 5-53... -
Page 38: Information
User Manual 5.2.7.3 Information Click [Main MenuSystemInfo] and then enter into the interface shown as Picture 5-55. Now user can check the current Device name, Device ID, Device type, Device S/N, MAC address, IE version, Software version, Panel version etc. Picture 5-55 5.2.8 Advanced 5.2.8.1 Maintain... -
Page 39: Menu Lock
User Manual 5.3 Menu Lock Considering a system safety feature you can click [ ] icon to lock system interface when leaving the DVR. If you want to login to the DVR again, you would input device code and password to unlock the interface shown as Picture 5-59 Friendly Reminder: Administrator has full authority over Main Menu operations and has an authority to... -
Page 40: Pip Mode
User Manual 5.6 PIP Mode You can display a Picture-in-Picture in live mode. PIP has two display modes, including 1X1 display mode and 1X2 display mode. 1x1 display mode 1x2 display mode 5.7Record search You could enter into [Record Search] menu from Pop-up menu conveniently and quickly and search/playback the record histories. -
Page 41: Chapter 6: Web Application Manager
User Manual Chapter 6: Web Application Manager 6.1 ActiveX control download and installation Open your web browser and input the IP address and web port of DVR, such as http://172.18.6.202:8080/ . If your computer is connected to internet, it will download and install “ActiveX” Plug-in automatically. -
Page 42: Web Application Manager Log-In
User Manual 6.2 Web Application Manager Log-in After ActiveX controls installation, please input user name, password and client port; and select <Main stream> or <sub stream>, and then allow you tick-select <Open All Channels Preview>; Now you click [Log-in] button, and then you are allowed to access a remote DVR and monitor live video images using Web browser anytime from virtually anywhere. -
Page 43: Ptz Control
User Manual Or click the right key of mouse on each <Live> window to pop up the interface shown as Picture 6-4. Show bit rate: Right-click the Preview window and tick-select the option to show current bit rate; Allow you open all the <live> channels Allow you close all the <live>... -
Page 44: Playback
User Manual 6.3.2 Playback Click [ ] icon to enter into <playback> interface shown Picture 6-7. Picture 6-7 6.3.2.1 Record search Firstly, select one day you want to check and tick-select <synchronous Playback> and the channels you desire to playback shown as Picture 6-8 Picture 6-8 Secondly, select record type (Normal record, Alarm record and All) and then click <... -
Page 45: Playback Control
User Manual Thirdly, Click [ ] icon to start record playback. When mouse curse is moving on the time axis, the current time will appear in the screen. Click [ ] icon to zoom in/out the time bar display ratio shown as Picture 6-9. 6.3.2.2 Playback control Below Picture 6-10 is playback control bar Picture 6-10... -
Page 46: Configuration
User Manual Record file download Click [ ] icon to enter into the below interface shown as Picture 6-12. Picture 6-12 Tick-select the record file you want to download and click [Start download] System will download the record file in turn and save to local PC. 6.3.3 Configuration 6.3.3.1 Display Configuration Unfold [Display] option to find its sub-options: Live and Privacy zone... -
Page 47: Record
User Manual 6.3.3.2 Record Click <Record> option to unfold its sub-options: Record parameter, Schedule and Main stream. Picture 6-15 Picture 6-16 Record Parameters: Under [Record parameters] option, allow you set channel, record enable, pack time and Pre-record status shown as Picture 6-15; Schedule: Detailed parameters please refer to DVR local setting (shown as Picture 6-16). -
Page 48: Alarm Set
User Manual 2 Sub stream (shown as Picture 6-21): Relative parameters should be consistent with DVR local setting. Picture 6-21 3 Email setting: Click [Email setting] option to allow you set alarm email configuration parameters shown as Picture 6-22. Detailed parameters should be consistent with DVR local setting. Picture 6-22 Mobile Setting 4 DDNS Setting... -
Page 49: Device
User Manual Picture 6-24 6.3.3.5 Device Click <Device> to unfold its sub-options: HDD and PTZ. 1 HDD: Allow you check out HDD status and overwritten time shown as Picture 6-27. Detail setting should be consistent with DVR local setting. Picture 6-27 2 PTZ: Configuration (shown as Picture 6-28): Details setting should be consistent with DVR local setting. -
Page 50: Advanced
User Manual 2 Users: Allow you configure user name and password shown as Picture 6-30. Details setting should be consistent with DVR local setting. Picture 6-30 3 Information: Allow you check out device name, number, type, MAC address, software version, IE version and hardware version shown as Picture 6-31. -
Page 51: Local Setting
User Manual Click <Start update>, now processing bar will display current upgrade status shown as Picture 6-34. Picture 6-34 2 Load Default: allow you recover defaulted parameters of DVR remotely shown as Picture 6-35. Details setting should be consistent with DVR local setting. Picture 6-35 3 Events: Allow you configure abnormal type, buzzer output time, and alarm email and show message shown as Picture 6-36. -
Page 52: Logout
User Manual download path of remote file, Snapshot path, File type (H.264 and AVI) and Internal shown as Picture 6-38. Picture 6-38 6.3.5 Logout Click the [ ] icon to return back the log-in interface. -
Page 53: Chapter 7: Appendix
User Manual Chapter 7: Appendix 7.1 Operation Function Table Type Title Description Page Time setting Set system date/time, display format and day-light saving time Set system language Language select Set CH title and position; adjust image color parameter Channel value; set CH display to ON / Off and time display/recording setting time overlaying to On/Off. -
Page 54: Record Alarm Setting
User Manual Remote heck local record history via network playback PTZ control Remotely control PTZ camera, position, focus, zoom and iris etc. parameter Set local CH display, record, alarm, PTZ control set of DVR parameter value via network remotely Network Backup record file via network download Check device ID, software version and MAC... -
Page 55: Mail Box Server List
User Manual 7.3 Mail box server List Web site Sender server 25 Receiver server 110 Mail box @163.com smtp.163.com pop3.163.com @vip.163.com smtp.vip.163.com pop.vip.163.com @188.com smtp.188.com pop.188.com www.163.com @126.com smtp.126.com pop3.126.com @netease.com smtp.netease.com pop.netease.com @yeah.net smtp.yeah.net pop.netease.com www.qq.com @qq.com smtp.qq.com pop.qq.com 163.net smtp.163vip.net popx.163vip.net... -
Page 56: Usage Maintenance
User Manual Q: “Record” Can not work normally, how to deal with? A: Check if the current screen is in Play mode, pressing [Stop] button to exit the Play mode and then you can enter into the [Record] function. Q: Why the Remote Controller can’t work normally? A: Check if the battery is power off;... - Page 57 User Manual HV-16TS HI-9904EN HI-9909EN...
-
Page 58: Accessories
User Manual HI-9916EN 32CH 7.7 Accessories 1. 4/8/16 CH Accessories 4/8/16CH Power Adapter User Manual USB Mouse 4/8/16/32CH Remote Controller Software CD... - Page 59 Th e m at er i al i n t h i s d o cu m e n t i s t h e i n t e l l ec t u al p r o p e r t y o f ou r d e p ar t m en t .
