ABT DUAL-BEAM ACTIVE PHOTOELECTRIC INTRUDER
DETECTOR WITH DIGITAL FREQUENCY CONVERSION
Installation GUIDE
Advertisement
Table of Contents
Related Manuals for Alean ABT-20
Summary of Contents for Alean ABT-20
- Page 1 ABT DUAL-BEAM ACTIVE PHOTOELECTRIC INTRUDER DETECTOR WITH DIGITAL FREQUENCY CONVERSION INSTALLATION GUIDE...
- Page 2 Model: ABT-20 (Outdoor 20m, Indoor 60m) ABT-30 (Outdoor 30m, Indoor 90m) ABT-40 (Outdoor 40m, Indoor 120m) ABT-60 (Outdoor 60m, Indoor 180m) ABT-80 (Outdoor 80m, Indoor 240m) ABT-100 (Outdoor 100m, Indoor 300m) Wiring terminal Response time Tamper switch Adjustment knob Indicator...
- Page 3 Multi sensors may be used for long-distance guarding. Please install according to the below diagram to avoid interference between beams. Adjustable angle: horizontal 90 vertical 10 Direct sunlight, lamplig Horizontal 180 ( 90 ) 50mm 0.6m ABT-20 ABT-30 0.7m ABT-40 1.0m ABT-60 1.5m ABT-80 1.8m...
- Page 4 1.Remove the cover Installation of fixed bracket 1.Drill a hole on the bracket and extend out the cable from it. 2.Attach the paper stencil onto the location where the equipment is to be mounted, and drill the holes in the positions on its mark. 2.Remove the cover.
- Page 5 1.Remove the cover and connect power. 2.Observe the collimation effect at a distance of 5cm from the viewfinder. 3.Adjust the vertical adjustment screw and the horizontal angle adjusting wheel in order that the image of opposite detector falls into the central part of the viewing hole.
- Page 6 (1.2m/s):3 (0.7m/s):4 (0.4m/s):5 Transmitting The 2 indicators of green LED light up GOOD LEVEL indicators light up The red ALARM indicator light up...
- Page 7 The LED of the transmitter doesn't light up Power open circuit The LED of the receiver doesn't light up Power f open circuit The LED of the receiver doesn't light up when the ABT-20 ABT-30 ABT-40 ABT-60 ABT-80 ABT-100 100m...
- Page 8 Recommended installation T-100 100 120mm T-200 200 120mm I-100 Installation bracket 100mm I-200 200mm 80 75mm Dimensions The product has got the 3C and CE approval already and is now applying for the UL approval. Copyright : Shenzhen Meian Technology Co.,Ltd.
