4G Systems XSBox MOVE Quick Start Manual

XSBox MOVE
®
1

Insert the Battery

Skip this step if you are planning a stationary use of
the device without battery.
Set the power switch to OFF
and insert the battery as
shown.
4

Connect power supply

When using the battery, it should be fully charged
once for at least 3-4 hours before using the device
for the first time. This ensures maximum lifetime of
the Li-Ion battery cells.
Afterwards power up the
XSBox MOVE
® by setting the
power switch to the ON position.
It takes some seconds before the device is ready and
you may continue configuration.
7

Running the wizard

The easiest way to configure the
using the wizard. Select the wizard checkbox and click
on enter.
On the next screen you will be shown an overview of
the following configuration steps.
2
Quick Start Guide
5
The default Wi-Fi settings are: SSID "default", chan-
nel 11, no encryption.
Open a web browser (e.g. Internet Explorer, Firefox,
Safari etc.) and type in the default IP address
http://192.168.123.254 of the
Note:
be configured to retrieve its IP address via DHCP or
have an IP address within the same subnet as the
XSBox
8
First thing suggested to be done is to change the default
XSBox MOVE
® is
password "admin" to a more complex and secret one.
Type in the current password "admin" and choose a new one
which must be entered twice. Afterwards click on "Next".
9
Try to automatically detect your timezone using the
button or select one from the dropdown list manually.
Click on "Next".

Connect 3G USB-Modem

Establish a connection

XSBox
The network adapter of your computer must
MOVE.
®

Choosing a new password

Selecting the local timezone

3
Skip this step to use the device with Wi-Fi only.
Connect the RJ-45 cable to the "Ethernet" jack of the
XSBox MOVE
®
your network switch or directly to
your computer.
6
After being connected to the
first screen you will see is the status page where you
can log into the configuration interface.
MOVE.
®
Enter the default password "admin" to the field
"System Password" and click the "Login" button.
10

Selecting WAN type

Now you must select the appropriate method to
connect to the internet. In this example, we will
connect using a 3G USB modem and therefore will
select "3G USB Modem". Click "Next".

Setup a LAN link

and the other end to a free port of

Logging in

XSBox MOVE
® , the
