Minuteman SNMP-32 Series User Manual

Web-based monitoring snmp card
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SNMP-32 Series
(Web-based monitoring SNMP card)
User's Manual
34000241 Rev1

Advertisement

Table of Contents
loading

Summary of Contents for Minuteman SNMP-32 Series

  • Page 1 SNMP-32 Series (Web-based monitoring SNMP card) User’s Manual 34000241 Rev1...

  • Page 2: Table Of Contents

    Table of Contents Notice... 3 1. Introduction ... 4 1-1. Features ... 4 1-2. Package Contents ... 5 1-3. Applications... 6 2. Installation Procedure... 7 3. Setup Procedure... 8 4. Web Management Interface... 10 4-1. Main Menu ... 10 4-2. Information: System Status...

  • Page 3: Notice

    Notice This equipment has been tested and found to comply with the limits for a “Class A” digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Introduction

    1. Introduction A UPS can be configured with either an internal or an external SNMP-32 card; this SNMP-32 card is then connected to the network. The SNMP-32 card contains a MIB agent. messages to the Network Management Station (NMS). Unsolicited messages are defined by the MIB and are built into the agent for critical items such as AC power failure and low battery detection.

  • Page 5: Package Contents

    Ethernet port — The connection for the LAN LAN Port LEDs — See the LAN Port LED Table below Modem port — The connection for an External Modem ENV port — The connection for a Temperature/Humidity Probe Status LEDs — See the LED Table below Yellow Flashing Solid ON...

  • Page 6: Applications

    External SNMP-32 card Package Contents (SNMP-32L Only) The external adaptor is used to connect the SNMP-32L card to the UPS, when the UPS does not have an option slot. The contents of the package are: External Adaptor Box Power Adaptor DB9 Male-to-Female Serial Cable SNMP-32 Card 1-3.

  • Page 7: Installation Procedure

    2. Installation Procedure This section will guide you through installing the Internal and the External SNMP-32 card. Internal SNMP-32 card NOTE: The SNMP-32 cards are designed to be Hot Swappable, but there is a remote chance that when Hot-Swapping the SNMP-32 card that the UPS will shutdown. MINUTEMAN recommends following steps 1 through 9 when installing the SNMP-32 card, but to hot-swap, skip to step number 3 and omit steps 7, 8.

  • Page 8: Setup Procedure

    Setup-Procedure This section will guide you through the Setup-Procedure of the SNMP-32 Card. NOTE: The minimum requirement to operate the SNMP-32 Card is to setup the IP Address. The SNMP Utility supports most Windows Operating Systems (98, 2000, XP). 1. Load the SNMP Utility CD into the CD-ROM drive, and then open the ‘Install SNMP Utility’. 2.
  • Page 9 6. Enter the IP address; the subnet mask and the gateway, then click OK or use DHCP or use BOOTP (Fig. 8). Fig. 8-SNMP Utility: Set IP address for SNMP-32 card 7. There are two Security features for the SNMP-32 card (Fig. 9): A.

  • Page 10: Web Management Interface

    4. Web Management Interface Once the SNMP-32 card installation and set-up procedure is complete, you are now able to monitor and control the SNMP-32 card via a Web Browser. 1. Open a Web Brower (Netscape, Internet Explore, Opera, Mozilla). 2. Enter the SNMP-32 card’s IP Address. 3.

  • Page 11: Information: System Status

    4-2. Information: System Status This screen shows the SNMP-32 card’s System Information and Network setting (Fig. 12). The information shown is provided by SNMP-32 card or it is the user settings from the SNMP Utility Configuration pages. 1. System Information: This section shows the System Information.

  • Page 12: Configuration: Snmp

    6. Secondary DNS Server IP: This section is to set the Secondary DNS Server IP address. SNMP-32 card will use the Secondary DNS Server IP address when the Primary DNS Server IP address is not working. 7. Ethernet Connection Type: This section is to set communication speed of the SNMP-32 card.
  • Page 13 3. Trap Notification A. Receiver IP Address: This section is to set the receivers IP address for receiving traps sent by SNMP-32 card. It is valid for up to eight IP Addresses. B. Community: This section is to set a Community name for NMS. The community name has to be the same as the setting in NMS.

  • Page 14: Configuration: Email

    4-5. Configuration: Email This screen is for setting up email notifications (Fig. 16). The email can be set-up for specific email receivers when a specified event occurs. 1. Email Setting: This section is to set the SNMP-32 card’s email Server. A.

  • Page 15: Configuration: Ppp

    4-6. Configuration: PPP This screen is to set the PPP dial-up information for the external modem (Fig. 17). 4-7. Configuration: Web/Telnet This screen is to set-up the User Account information for Web/Telnet (Fig. 18). 1. User Account A. User Name: This section is to set a user name for the SNMP-32 card’s Web pages.

  • Page 16: Configuration: System Time

    4-8. Configuration: System Time This screen is to set the SNMP-32 card’s system time (Fig. 19). 1. Internet Time Setting A. Time Between Automatic Updates: This section is to set a time interval between automatic updates. B. Primary Time Server: This section is to set a Primary Time Server for the SNMP-32 card.
  • Page 17 ENV Event List: • Environmental Temperature Overrun • Environmental Temperature Underrun • Environmental Humidity Overrun • Environmental Humidity Underrun CPS Event List: • CPS Communication Lost • Current Out of Threshold 1 • Current Out of Threshold 2 ATS Event List: •...

  • Page 18: Log Information: Data

    4-10. Log Information: Data 1. Data Log This screen shows the Data log for the connected UPS (Fig. 22). The log displays the Data/Time, Input Voltage, Output Voltage, Input Frequency (Hz), Output Loading (%), Battery Capacity (%), and the Battery Temperature. The SNMP-32 card can log up to 500 events.

  • Page 19: Firmware Upgrade Procedure

    5. Firmware Upgrade Procedure This section will guide you through the Firmware Upgrade Procedure of the SNMP-32 Card. 1. Open the ‘SNMP Utility’ group in the Windows ’Start’ 2. Click “SNMP Utility” to initiate the SNMP Utility program (Fig. 24). 3.
  • Page 20 5. Click , and then browse for the location of the new firmware file. Select the new firmware file (*.bin) and press “Start”. The SNMP-32 card’s Red and Yellow LEDs will flash alternately, meaning the firmware upgrade is in process (Fig. 27). 6.

  • Page 21: Telnet

    6. Telnet 6-1. Telnet Configuration This section will guide you through the Telnet Configuration of the SNMP-32 Card. 1. Select “Start” from Windows, click “Run”, then input Telnet and the SNMP-32 card’s IP Address. Then click “OK” (Fig. 29). 2. Telnet connection successful (Fig. 30). Press any key to continue. 3.
  • Page 22 4. Telnet Main Menu screen (Fig. 32). • Set IP Address This function is for setting the IP Address, the Gateway Address, and the Subnet Mask. • Set SNMP MIB System This function is for setting the MIB System Group parameters. •...

  • Page 23: Connected Device

    7. Connected Device 7-1. Uninterruptible Power Supply (UPS) This section will guide you through the SNMP-32 card’s UPS Web pages. See section 2, Installation Procedure, for installing the SNMP-32 card in the UPS. 1. UPS Information This screen shows the basic UPS information (Fig. 33). The UPS provides the values shown, or they are user settings from the Configuration pages.
  • Page 24 2. UPS Status This screen shows the UPS’s current status (Fig. 34). The users can choose a time interval from the drop-down box to refresh the status information. UPS Status This section is to show the UPS power status. The abnormal status will be displayed (in red) when there is an abnormal power event.
  • Page 25 3. UPS Control This screen is to provide remote UPS test functions (Fig. 35). Choose the test item and click on 'Apply' to execute the test. Quick Battery Test The Quick Battery Test function will test the battery for 5-seconds. General System Test The General System Test function will test the UPS and the battery for-15 seconds.
  • Page 26 4. Graphic View This screen displays the Temperature, the Capacity, the Load, the Voltage, etc of the UPS (Fig. 36). The three bar graphs are Output Voltage, Output Load, and Input Voltage. Fig. 36-Graphic View Screen Clicking on the “Setting” button, the user can set the Upper Threshold and the Lower Threshold for the Output Voltage, the Output Load, and the Input Voltage (Fig.
  • Page 27 5. UPS Settings This screen is for the user to input information about the UPS (Fig. 39). UPS Properties The user can input the date of the last time the battery was replaced. UPS Recorded The user can set the time interval to log UPS Data. Test UPS The user can set the time interval for the UPS to perform a test.
  • Page 28 After selecting the “New” button or [Edit], the following page will appear (Fig. 41). Select the desired shutdown and restart configuration and then click the “Save” button. • Date: Input the date for the event to occur. • Time: Input the time for the event to occur on the specified date. •...

  • Page 29: Remote Power Manager (Rpm)

    7-2. Remote Power Manager (RPM) This section will guide you through the SNMP-32 card’s RPM Web pages. See the RPM User’s Manual for installation instruction. 1. RPM Status (Fig. 44) Select RPM Select which RPM to view and control (RPM01-RPM16). Outlet A-H Name the outlet.
  • Page 30 2. RPM Setting (Fig. 45) Select RPM Select the appropriate RPM to configure (RPM01-RPM16). Address Change Change the RPM’s ID. The factory default setting is RPM00, which is not configurable. The user must change the RPM’s ID to RPM01 through RPM16. Identification The user can rename the RPM.
  • Page 31 3. RPM Schedule This screen is for scheduling the RPM’s outlets to perform a specific Action (Fig. 46). To add a new schedule, select the “New” button. To make changes to the current schedule, select [Edit]. To remove a schedule, select [Delete].

  • Page 32: Current Probe Sensor (Cps)

    7-3. Current Probe Sensor (CPS) This section will guide you through the SNMP-32 card’s CPS Web pages. See the CPS User’s Manual for installation instruction. 1. CPS Status (Fig. 48) This screen shows the electrical current detected by CPS and indicates if the current is out of the preset range. 2.

  • Page 33: Temp/Hum32-Probe (Env)

    7-4. Temp/Hum32-Probe (ENV) This section will guide you through the SNMP-32 card’s ENV Web pages. See the Temp/Hum32-Probe User’s Manual for installation instruction. 1. ENV Status (Fig. 50) This screen shows the temperature and the humidity detected by ENV. The user can select the time interval for refreshing the ENV Status screen.

  • Page 34: Automatic Transfer Switch (Ats)

    7-5. Automatic Transfer Switch (ATS) This section will guide you through the SNMP-32 card’s ATS Web pages. See the ATS User’s Manual for installation instruction. 1. ATS Status (Fig. 52) This screen is to show which Input Power Source is being used. Clicking on the “ICON” can switch the input power source from Input Power Source A to Input Power Source B.

  • Page 35: Configuring The Nms

    8. Configuring the NMS To complete the SNMP-32 card installation and configuration process, you must compile the necessary MIBs to configure the NMS. Most NMS with a MIB compiler can manage the SNMP-32 card. For instructions on how to compile MIBs for the most popular NMS—HP OpenView Network Node Manager and SunConnect SunNet Manager, see the corresponding heading below.

  • Page 36: Appendix

    9. Appendix This section discusses: Communities, Gateways, IP Addresses, and Subnet masking. Communities A community is a string of printable ASCII characters that identifies a user group with the same access privileges. For example, a common community name is “public.” For security purposes, the SNMP agent validates requests before responding.
  • Page 37 A subnet mask is a 32-bit value that distinguishes the network ID from the host ID for different sub-networks on the same logical network. Like IP addresses, subnet masks consist of four octets in dotted decimal notation. You can use subnet masks to route and filter the transmission of IP packets among your sub-networks.

  • Page 38: Troubleshooting

    10. Troubleshooting Problem: The NMS cannot ping the SNMP-32 card. Solution: Make sure the network connection to the SNMP-32 card is good. Solution: Make sure the cable is in good condition. Solution: Make sure to set the Community String. Name the community with any lowercase name. A UPS monitors a designated community.

  • Page 39: Obtaining Technical Assistance

    11. Obtaining Technical Assistance For Technical Support on the Web, please visit the Support section of our Web site or visit our online Discussion Forum at www.minutemanups.com In order to diagnose the problem you are having, our technicians need the following information from you. Installation Site: Company Name: Address:...

  • Page 40: Limited Product Warranty

    12. Limited Product Warranty LIMITED PRODUCT WARRANTY Para Systems Inc. (Para Systems) warrants this equipment, when properly applied and operated within specified conditions, against faulty materials or workmanship for a period of three years from the date of original purchase by the end user.
