Summary of Contents for CJT IM-800B

  • Page 1 IM-800B Blender User Manual...
  • Page 2 1、2、3、4、5：Speed mode Stop: On/off the appliance Pulse: Pulse mode Cup: If cup was not on base or not on correct position, the light will twinkle. Temp indication light: If motor was over temperature, the light will twinkle. Load indication light: If motor was over loaded, the light will twinkle. Mode 1: at the uniform velocity 13000 rpm for 18s: Mode 2: 0-2s:11000rpm;...
  • Page 3 4. Before using this unit, check the mains power voltage corresponds to the voltage shown on the rating plate. 5. Always remove the plug from the power socket when this unit is not use and before carrying out any cleaning or maintenance operation. 6.

  • Page 4: Troubleshooting

    indicate lamp to make sure the cup is assembled correctly. 6). Choose suitable speed mode or pulse mode, and let the unit operate continuously for a short time (less than rated working period). Press the “STOP” button and let the unit rest (more than rater interval period).
  • Page 5 Electric Circuit Diagram Specification Model No.: IM-800B Rated Voltage: 110-120V/220-240V Rated Power: 1500W Rated Frequency: 50/60Hz Rated working period: ≤2min Rotational Speed: 20000r/min Rated Interval period: ≥2min Noise: ≤ 80dB(A)
