NOTICE FOR SAFETY

Please make sure of usage after bearing the following

contents in mind to shorten the safety, and product

failure before its operation.

1. Do not shock in move, and installation.

2. Please check rating voltage (mini type : DC12V 3.0A / mobile type : DC12V)

before power on.

3. Please check power off before installation.

4. Avoid any place with moisture because of electric shock, and fire.

5. Avoid any place with moisture, dust, or soot.

6. Avoid any place with direct sunlight, or heating appliances.

7. Avoid high, or low temperature.

8. Procure sufficient air ventilation for the connection of system wiring.

9. Don't install near to electronic devices such as radio, or TV.

10. Install in sufficient air ventilation, and no vibration.

11. Please take care of not putting the electric product into the cooling fan.

12. Don't use water, or cleanser in surface cleaning to prevent an electric shock.

13. Please clean system by dry towel in external cleaning.

14. Do not pull power cord forcefully.

15. Do not place any heavy object on the main system.

16. Do not open, or disassemble DVR without an assistance of qualified service personnel.

17. Please power off in case of moving DVR.

18. Please equip with the safety facility to diminish the loss for electricity failure,

and lightning.

19. Do not connect signal cable of camera with DVR system during camera installation.

20. Please power off immediately, and contact manufacturer, or supplier if you

catch strange scent, or smog.

Car & Home Security System

Table of Contents

Need help?

Do you have a question about the JV series and is the answer not in the manual?

Questions and answers

Summary of Contents for omnikine JV series

Page 1 NOTICE FOR SAFETY Please make sure of usage after bearing the following contents in mind to shorten the safety, and product failure before its operation. 1. Do not shock in move, and installation. 2. Please check rating voltage (mini type : DC12V 3.0A / mobile type : DC12V) before power on.
Page 2: Table Of Contents
NOTICE FOR SAFETY - This equipment had been tested and found to comply with the limits for CLASS A digital deice, pursuant to Part 15 of FCC Rules. - These limits are designed to provide reasonable protection against harmful interface when the equipment is operated in a commercial environment.
Page 3: Quick Setup Guide
Quick Setup Guide STEP 1 Package Details STEP 2 HDD Installation STEP 3 Camera & Monitor Connection STEP 4 Menu Setup 1. Date & Time Setup 2. Record Setup STEP 5 Operation Check 1. Monitor Check Car & Home Security System 2.
Page 4 Quick Setup Guide Quick Setup Guide STEP1.1 Package Details STEP 1.2 Optional Accessories 1. Camera extention cable A Type (MINI) 1) Type A (MINI) : 60 feet cable 2) Type B (Mobile) : 20 feet cable Battery Adaptor Remote controller 2.
Page 5 Quick Setup Guide Quick Setup Guide STEP2 HDD Installation STEP3 Camera, Monitor and Power Connection 1. Unscrew 4 fixed screws on 4. Insert rubber rings into screws the bottom of case. and then screw them to fix HDD & main baord to case. 1.
Page 6 Quick Setup Guide Quick Setup Guide STEP4 Setup STEP5 Operation Check 1. Date & time setup 1. Monitor Check 1) Date and time information : It appears - Press menu setup button. on the left top of screen. 1) Go to system menu and set : It shows that recording is on.
Page 7 Main Features Main Features 1. Good design and super slim 4ch DVR 2. Optimized observation system 3. Real time display and recording (Max. M-JPEG 60 fps) 4. Various display mode (1ch display / 4ch split disply) 5. Video loss and motion detection 6.
Page 8: Front Panel
Main Features Main Features Specification 4 Channel Input (Phone jack) Video Input NTSC / PAL, 1V 75 Ohm Video Signal Front Panel Video Output 1 Output (Phone jack) M-JPEG Compression Real Time Display / Record / Playback Multiplex Operation Resolution NTSC-720 X 480 / PAL-704 X 576 1.
Page 9: Specification
Specification Specification Cable information Remote Controller 1. Camera input cable NAME FUNCTION Mute BACK UP - Connect camera with specially designed one jack cable (which can be purchased MENU from supplier) to DVR and monitor to DVR, using AV out cable in package. - You can connect normal camera to DVR as well, using optional camera cable.
Page 10: Operation
Specification Menu Icon Menu setup System setup Car & Home Security System Search Camera setup Backup Motion setup Operation DVR Information Audio setup Record setup Car & Home Security System...
Page 11 Operation Operation 1. Power On 2. Live Display It must be required to use adaptor in package. 1. Display Mode (1ch mode, 4ch mode) 1. Connect adaptor in package to DVR. 4ch display mode is default and it can be changed to 1ch display mode 2.
Page 12 Operation Operation 3. Search 4. Playback Recording data can be played in various modes. Recording data can be searched by normal recording list or event recording list. Press search button and go to search mode as below. Select search mode between time search and event search by pressing up/down buttons.
Page 13: Backup Viewer
Operation 5. Backup Recording data can be archived to USB memory as backup. But it stops recording automatically during data backup. Backup data can be played on backup viewer program provied in package CD. The recording data in HDD can played on backup viewer as well after conneting HDD to PC directly through USB to SATA converter.
Page 14 Backup Viewer Backup Viewer 1. Backup Viewer Installation 1. Backup Viewer Download Backup viewer program is provided in package CD or can be downloaded from the link as below. http://www.videonetserver.com/jvp/index.htm or http://222.231.1.156/jvp/index.htm Change icon name as want. Check if creating a desktop icon. Double click JVP Viewer Setup.exe file Press next button.
Page 15 Backup Viewer Backup Viewer 2. Program Open 3. Backup Viewer Function - It can play backup data in USB memory. - It can play recording data in HDD as well after conneting HDD to PC directly through USB to SATA converter. Record Open file Capture...
Page 16: Menu Setup
Menu Setup 1. Storage Setup 1) Overwrite Once HDD is full with recording data, it goes back to the first stage and record videos from it again. (Overwrite enable - yes is default.) Car & Home Security System If overwrite enable sets to no, it stops recording once HDD is full with recording data.
Page 17 Menu Setup Menu Setup 2. Password Setup 3. Date & time Setup - Select GMT as your standard time zone. - Go to time set and set date & time as your local time. - Press enter button and change date & time. - After completing date &...
Page 18 Menu Setup Menu Setup 5. Language Setup 6. Log List It shows system operation status with date & time information. It supports multiple languages. Go to language menu. It shows all system operation information like recording start time. 7. Car Number Setup Input car number (4 digits only) and it is displayed on the right bottom of screen in both of live and playback mode.
Page 19 Menu Setup Menu Setup 8. Firmware Upgrade 9. Camera Setup Download new firmware and upgrade DVR by USB memory. Inset USB into DVR and follow steps as below. After upgrade, press i button and check system information. Select camera number and optimize display quality by selecting menu values.
Page 20 Menu Setup Menu Setup 11. Motion Detection Setup 12. Record Setup Setup motion detection with sensitivity and area. It is recorded in event list once motion is triggered. Setup record mode, speed and quality. Partial motion area setup Full motion area setup 12-1.Record Mode Select normal record or event record.
Page 21: Troubleshooting
Menu Setup 12-2. Record Speed Set record speed up to max. 30fps per channel within total 60fps. Car & Home Security System 12-3. Record Quality Select quality among high, normal and low. Troubleshooting - Record setup is related to HDD recordingperiod. - When overwrite is on, it records again from the start point once HDD is full.
Page 22 Troubleshooting Troubleshooting 1. The system power is turn off. Impossible to search for the recorded video. Check if power cable is correctly connected . Check if there is a recorded video data when you are trying to search for on the table. If there is no recorded video data, check if it is set to “NONE”...
Page 23: Warranty
WARRANTY WARRANTY GUIDE The quality of this product is guaranteed by strict quality control processes, and testing. If the product becomes non-operational, the warranty may be in operation. The warranty period is valid for 1 year from the date of purchase. WARRANTY If the product becomes non-operational, the warranty may be in operation.
