    Table of Contents Overview ..........................2 Features ........................2 Package Contents ....................... 3 Dimensions ........................5 Connectors (Indoor Only)..................... 6 Function Cables (Outdoor Only) .................. 7 Camera Cabling ........................8 Power Connection ....................... 8 Ethernet Cable Connection ..................8 Alarm I/O Connection ....................8 Waterproof Cable Connector (Outdoor Only) ...............
  • Page 3: Overview

    Overview The Hyper Mini Dome IP Camera is an easy setup camera with PoE supported to reduce complicated cabling without sacrificing performance. Quad Streams Compression (H.264 Baseline / Main / High Profile / SVC + MJPEG) are supported for efficient bandwidth and storage management. Up to 4K2K real time resolution is offered for providing high definition images.
  • Page 4: Package Contents

    Package Contents Please check the package containing the following items listed below. Indoor Hyper Mini Dome IP Camera 2-Pin Power Terminal Block Self-Tapping Screw (x3) Plastic Screw Anchor (x3) Quick Guide (bundled software and documentation) NOTE: The supplied self-tapping screws are for soft substances / materials such as wood.
  • Page 5 Outdoor Hyper Mini Dome IP Camera Rubber Washer (x2) Security Torx Self-Tapping Screw (x3) Plastic Screw Anchor (x3) 2-Pin Power Terminal Block 4-Pin Alarm I/O Terminal Block Quick Guide (bundled software and documentation) NOTE: The supplied self-tapping screws are for soft substances / materials such as wood.
  • Page 6: Dimensions

    Dimensions The dimensions of the camera are shown below. Indoor Outdoor...
  • Page 7: Connectors (Indoor Only)

    Connectors (Indoor Only) The diagram below shows the default button and various connectors of the camera. Definition for each connector is given as follows. Connector Definition Remarks RJ-45 For network and PoE connections AC 24V 1 DC 12V Power Power (DC 12V / AC 24V) connection AC 24V 2...
  • Page 8: Function Cables (Outdoor Only)

    Function Cables (Outdoor Only) Connector Definition Remarks RJ-45 For network and PoE connection DC 12V 1 / AC 24V 1 Power* Power (DC 12V / AC 24V) DC 12V 2 / AC 24V 2 connection Pink Audio In Two-way audio Audio I/O* transmission Green...
  • Page 9: Camera Cabling

    Camera Cabling Before users connect cables, make sure that all cables and the power adaptor are placed in dry and well-waterproofed environments, e.g. waterproof boxes. The purpose is to prevent moisture accumulation inside the camera and moisture penetration into cables, which might lead to camera breakdown. Please refer to the following sections for camera connection.
  • Page 10: Waterproof Cable Connector (Outdoor Only)

    Waterproof Cable Connector (Outdoor Only) Follow the instruction below to waterproof the connectors of different types of cables. The supported cables are as shown below. All-in-One Cable RJ-45 Cable IP66 RJ-45 Cable All-in-One Cable Follow the steps below to waterproof the connectors of the All-in-One cable. Step 1: Plug the cables to the connectors of the All-in-One cable and coat the joints with...
  • Page 11 RJ-45 Cable Follow the instruction below to waterproof the connector of the RJ-45 cable. Plug the Ethernet cable to the connector of the RJ-45 cable and coat the joint with silicone gel. Make sure there is no gap between Ethernet cable connector;...
  • Page 12: System Requirements

    System Requirements To perform the IP camera via web browser, please ensure the PC is in good network connection, and meet system requirements as described below. Items System Requirement Minimum : 1. Intel® Core i5-2430M @ 2.4 GHz 2. 4 GB RAM Recommended : Personal Computer 1.
  • Page 13: Access Camera

    Access Camera For initial access to the IP camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Accessing the Camera by Device Search Software Step 1: Double click on the program Device Search.exe. Step 2: After its window appears, click on the <Device Search>...
  • Page 14 Step 8: A prompt window requesting for default username and password will appear. Enter the default username and password shown below to login to the camera. Login ID Password Admin 1234 NOTE: ID and password are case sensitive. NOTE: It is strongly advised that administrator’s password be altered for the security concerns.
  • Page 15 Once the Viewer is successfully installed, the Home page of the IP camera will be shown as the figure below. Vari-focal Lens Models...
  • Page 16 Motorized Lens Models...
  • Page 17 3x AF Lens Models...
  • Page 18 Zoom and Focus Adjustment (Vari-focal Lens Models) For vari-focal lens models, zoom and focus can be adjusted by the adjustment bars on the camera lens inside the dome cover. To adjust zoom and focus, please detach the dome cover first. For indoor models, use a plus screw driver to loosen the two screws of the camera.
  • Page 19: Setup Video Resolution

    Setup Video Resolution Users can setup video resolution on the Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default values of the video resolution are as below. H.264- 2048 x 1536 (25/30 fps) + H.264- 720 x 576 (25 fps) / 720 x 480 (30 fps) H.264- 2048 x 1536 (50/60 fps) +...
  • Page 20: Configuration Files Export / Import

    Configuration Files Export / Import To export / import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the camera.
  • Page 21: Tech Support Information

    Tech Support Information This chapter will introduce how to delete previously-installed Viewer in the PC and how to setup the Internet security. Delete the Existing Viewer For users who have installed the Viewer in the PC previously, please remove the existing Viewer from the PC before accessing to the IP camera. Deleting the Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>.
  • Page 22: Setup Internet Security

    Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>.
