  • Page 1 OWNER'S MANUAL - - 0...
  • Page 2: Table Of Contents

    CATALOG CATALOG____________________________________________ WARNING____________________________________________ ATTENTION___________________________________________ IMPORTANT SAFETY PRECAUTIONS______________________ ASSEMBLY INSTRUCTION_______________________________ TECHNICAL PARAMETER_______________________________ OPERATION GUIDE____________________________________ TROUBLESHOOTING GUIDE_____________________________ MAINTENANCE INSTRUCTIONS__________________________ EXPLODED DRAWING__________________________________ PARTS LIST___________________________________________ - - 1...
  • Page 3: Warning

    WARNING Read all instruction carefully before use this product. Retain this owner’s manual for the future’s reference: ----When using this treadmill, keep attaching the safety pull pin rope to your clothes. ----When you are running, keep your hand swinging natural, stare front, never look at the bottom of your foot.
  • Page 4: Important Safety Precautions

    13、 When don’t use the equipment, cut off the power.When cut off the power,don’t pull the power supply line so as to keep the wire un broken. IMPORTANT SAFETY PRECAUTIONS 1. Plug the power cord of the treadmill directly into a dedicated grounded circuit carrying 10 amps. Grounding Instructions: This product must be grounded.
  • Page 5 14.The power cable of treadmill is special. if the power cable is damaged, please don't change by yourself, you must contact the local dealer ASAP. 15.When the treadmill is not being used, please pull out the safety lock and store it in a safe location. In order to avoid the unauthorized use by others, specifically children.
  • Page 6: Assembly Instruction

    ASSEMBLY INSTRUCTIONS When you open the carton, you will find the below spare parts: SPARE PARTS LIST: DES. SPEC. QTY(pcs) DES. SPEC. QTY(pcs) MAIN FRAME BOLT M5*10 LEFT UPRIGHT SCREW ST4.2*12 TUBE RIGHT UPRIGHT DUMBBELL BRACKET TUBE COMPUTER 2LB DUMBBELL - - 5...
  • Page 7 LEFT HANDLEBAR 3LB DUMBBELL BOTTOM COVER RIGHT HANDLEBAR 4LB DUMBBELL BOTTOM COVER LEFT PLASTIC BOTTOM SCREW ST4.2*19 COVER RIGHT PLASTIC BOLT M8*15 BOTTOM COVER 47 PEDAL COVER 5#ALLEN WRENCH WASHER ALLEN WRENCH WASHER WRENCH W/SCREW DRIVER BOLT M10*25 FIXING TOOLS: #5 ALLEN WRENCH (5mm): 1pcs #6 ALLEN WRENCH (6mm): 1pcs WRENCH W / SCREW DRIVER (S = 13, 14, 15): 1pcs...
  • Page 8 STEP 3: STEP 4: 4. Insert the PLASTIC BOTTOM COVER (#38, #39) into the UPRIGHT TUBE (#3, #4) vertically. Notice: Please don’t tighten the bolts and nuts until all the assembly steps are completed. 5. Insert the HANDLEBAR BOTTOM COVER (#13, #14) STEP 5: into the UPRIGHT TUBE (3, 4) separately.
  • Page 9 STEP 6: 8. Use WRENCH W / SCREW DRIVER to lock the HANDLEBAR PLASTIC BOTTOM COVER (#13, #14) onto the COMPUTER (#5) with SCREW (#102) . 9. Lock the PLASTIC BOTTOM COVER (#38, #39) onto the MAIN FRAME (#1) with the SCREW (#147).
  • Page 10: Technical Parameter

    STEP 9: 14. After complete the assembly above, upright the treadmill (as the left drawing), hook plastic bearing (51) of the adjustable holding with the pedal draw (49). 15. Put the pedal connecting piece (99) under the pedal (47) on the back of the pedal hook (49);...
  • Page 11: Operation Guide

    1720 RUNNING 1520 X 520 BOARD SIZE INCLINE 0-12% (mm) MAX ALLOWED 200 Kg WEIGHT SPEED, TIME, DISTANCE, CALORIE, PULSE, INCLINE, 5 LED DISPLAY WITH 7 INCH VIDEO DISPLAY OPERATION GUIDE - - 10...
  • Page 12 2-1-1. The main window display: Display with the circle of dummy playground (400 M) when it is running ; Display with rolling “LIME” logo when it is in the standby mode. 2-1-2. Speed window display: min speed eg. “1.0 KM or 0.8 M”.
  • Page 13 3-3. In the profile window, the speed and incline of each program will display automaticly, the interval time is 5s. The profile window is 8 X 8 dot matrix. It can only display 8 profile when the process is carrying out. Therefore, when the quantity of the setting profile is beyond 8, it will adopt the progressive display, namely the first line of the profile will flicker, then turn to the second line.
  • Page 14 EEPROM 3.0. 5.0 5.0 6.0 7.0 7.0 5.0 7.0 7.0 8.0 8.0 6.0 7.0 5.0 5.0 6.0 7.0 4.0 4.0 3.0 Incline profile 6 Segment EEPROM Speed profile 6 Segment EEPROM Incline profile 7 Segment EEPROM Speed profile 7 Segment EEPROM 2.0 3.0 3.0 6.0 7.0 7.0 4.0 6.0 7.0 4.0 6.0 7.0 4.0 4.0 4.0 2.0 3.0 4.0 4.0 2.0 Incline profile 8 Segment...
  • Page 15 EEPROM 2.0 4.0 4.0 5.0 7.0 5.0 4.0 7.0 7.0 4.0 6.0 6.0 4.0 5.0 4.0 2.0 5.0 4.0 3.0 4.0 Incline profile 13 Segment EEPROM Speed profile 13 Segment EEPROM 2.0 4.0 4.0 7.0 7.0 4.0 7.0 8.0 4.0 8.0 9.0 9.0 4.0 4.0 4.0 5.0 6.0 3.0 3.0 2.0 Incline profile 14 Segment EEPROM...
  • Page 16 4-5. MODE key: 4-5.1. When it is in the MANUAL stand by state, press the mode key, choosing ordinally the item you want, the sequence of the items will be as follows: Time → Calories → Distance When we choose the other programs, except the MANUAL, press the MODE in its stand by state, we can only set TIME, but CAL, DIST are not available.
  • Page 17 and the incline should be got back to the original data. 5-2. Whatever the manual, p1~p15, user are all in their stand by state, when we press the start key, it will begin to count down in 3 seconds with the alarm “bi-bi-bi” and the letter of “GO” which are showed in the middle of dot matrix.
  • Page 18 Time unit: seconds; ?% is motor incline. 5-9. Incline: 5-9-1. It will display in Multi-data (incline, pulse) window. The motor incline will be up and down if you press the incline up and down key. 5-9-2. Incline regulation: adopts manual into self-regulation program. Press INCLINE UP/DOWN +STOP 5s simultaneously in the stand by state, it will directly enter the INCLINE self-regulation.
  • Page 19 6-8-2. When we choose the program and press the start key, the orientation and control of INC/Speed will carry out automatically as per the profile curve of program display on the LED Bar. Meanwhile, INC/Speed will adjust and orientate automatically. 6-8-3.
  • Page 20 Error message: display on speed window. 8-1. E1. The program will stop automatically when press “start” key but no speed program input in 10s. 8-2. E2. Either the EEPROM nor the ID code is wrong, or can not reading; this action won’t accept unless it last for 5s.
  • Page 21 III. If you select “Picture displayed usage”, you can choose “Stochastic->Fade in & Fade out->Close->Down-Up->Up-Down->Left-Right->Right-Left->Sideways-Middle->Middle-Sideways->Int erlude horizontally->Interlude vertically” circularly by “ ”, then press “ /ENTER” to confirm. If you select “Music repeating mode”, you can choose “All repeat-> one repeat” circularly by “ ”, then press “...
  • Page 22 of all the “PHOTO” files. It also can be paused by “ /ENTER”, when it is playing, the toolbar will be shown under the photos, you can choose the playing mode by “ ”. Then, press “GO BACK”, the photos display will stop and enter the picture preview. (Repress “GO BACK”, it will return to the end menu, as shown by Picture 1).
  • Page 23: Troubleshooting Guide

    TROUBLESHOOTING GUIDE: TROUBLESHOOTING GUIDE CAUSE CHECKING CORRECTION PROBLEM 1. The plug and the line is 1. Checking the plug and 1. Insert the plug and the line well. Treadmill loosen. the line is connected well. will not 2. Checking the power start.
  • Page 24 2. Checking the wire and computer if the tie-in is 2. Reset to insert the wire connected well. 3. Put the both hands to The hand pulse do not touch bedew a litter or scrub 3. Reset to test. well. with both hands.
  • Page 25: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS WALKING BELT CENTERING AND TENSION ADJUSTMENT The walking belt may occasionally need to be centered and tightened. TO ADJUST WALING BELT TENSION: ● Run treadmill at approximately 3.5 mph. ● Using Allen wrench, turn both the right and left adjustment bolts ONE full turn clockwise.
  • Page 26 WARNING: ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL OUTLET BEFORE CLEANING OR SERVICING THE UNIT. CLEANING General cleaning or the unit will greatly prolong the treadmill. Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails.
  • Page 27: Exploded Drawing

    EXPLODED DRAWING...
  • Page 28: Part List

    Part list DESCRIPTION REMARK DESCRIPTION REMARK MAIN FRAME PLASTIC BOTTOM COVE (L) BASE FRAME PLASTIC BOTTOM COVE (R) LEFT UPRIGHT MAGNETIC SENSOR RIGHT UPRIGHT INCLINE MOTOR DISPLAY BOARD TAPER CUSHION COMPUTER TOP COVER ADJUST BRACKET COMPUTER BOTTOM COVER STRENGTH TUBE LEFT COMPUTER COVER SUPPORTING ASSEMBLY ¢38*¢33*16...
  • Page 29 ∮ 63*∮ 8.2*35 M6*12 WHEEL SCREW M5*6 END CAP SCREW COMPUTER MIDDLE FLAT WASHER WIRE COMPUTER LOWER M5*8 SCREW WIRE AMPLIFIER UPPER ST4.2*13 SCREW WIRE AMPLIFIER MIDDLE ST4.2*13 SCREW WIRE AMPLIFIER LOWER SPRING WASHER WIRE M8*45 ST4.2*16 SCREW BOLT M8*50 SAFETY LOCK BOLT φ...
  • Page 30 COMPUTER UPPER WIRE AV IN LOWER WIRE SOUND BOX BACK SEAL RING SPEAKER SEAL RING FOR SPEAKER SCREW ST4.0*15 ADJUSTMENT COVER CUSHION ADJUSTMENT PLUG CUSHION ADJUSTMENT STICK PLASTIC WHEEL SPLIT WASHER SCREW M5*20 INCLINE MOTOR GUIDING PLASTIC BUSHING M18 PLASTIC NUT GUIDING MANDRIL CONNECTION FIXED BLOCK CONNECTION IRON BOARD...
