Summary of Contents for ATL twotwo sub1
- Page 1 User Guide Advanced Transmission Line Model Serial No. Hand built by...
- Page 3 IMPORTANT Warranty Certificate Please take a few moments to complete the warranty card at the back of this booklet (or register at www.pmc-speakers.com) as this not only records the purchase of your loudspeakers, but also provides you with an opportunity to make suggestions and provide feedback directly to PMC.
- Page 4 A message from Peter Thomas: “ Peter Thomas Owner & Chief Designer Our sole aim while designing loudspeakers is to recreate the true essence of an artist’s intention, combining the ultimate level of sonic resolution with solid engineering principles. We believe that the same loudspeaker can be used throughout the entire audio chain, from composer to studio or film stage, post-production or mastering and then, finally, the consumer.
- Page 5 Congratulations - You have joined the elite PMC: the authority for quality sound. Prince Over more than two decades PMC has UNIVERSAL MUSIC GROUP earned an unrivalled reputation for creating the world’s finest professional loudspeakers. Stevie Wonder Thomas Newman Simply put, our loudspeakers provide a reference for the world’s highest profile ESPN Brian May...
-
Page 6: Table Of Contents
User EQ Options Connections Running In Applications – 2.1 Configurations Applications – 5.1 Configurations Applications – 7.1 Configurations Positioning & Alignment twotwo sub1 Specifications twotwo sub2 Specifications Operational Controls Service The PMC Range Our Meticulous Care and Attention Inspection Certificate Warranty On-Line Warranty Certificate –... -
Page 7: General Usage Guidelines
General Usage Guidelines Read these instructions and keep them in a safe place for future reference. Heed all electrical safety warnings, including any on the loudspeaker itself. Do not use the loudspeaker near water. Do not install the loudspeaker near heat sources such as radiators, ovens or other very hot equipment, or in unventilated soffits or enclosures. -
Page 8: Introduction
The two long-throw bass drivers employed in the twotwo sub1 subwoofer are a bespoke PMC design using natural materials, with an ultra-light and ultra-stiff doped-paper cone to deliver unparalleled transient response. -
Page 9: Unpacking And Care
If you dispose of the packaging please do so in an environmentally responsible and safe way. What’s in the Box? 1x twotwo sub1 or sub2 active subwoofer 1x AC mains power cable 1x RJ45 control link cable... -
Page 10: Advanced Transmission Line
Advanced Transmission Line How it works Advanced Transmission Line PMC’s unique (Advanced Transmission A further advantage of the ATL design Advanced Transmission Line Line) enclosures have taken loudspeaker approach is greater bass extension and design to the highest level, using sophisticated... -
Page 11: System Description
System Description All twotwo active subwoofers share the same equalisation, and phase alignment for the subwoofer, as well as high-pass filtering bass powerful DSP engine, operating at a fixed sample rate of 96kHz. management options for the analogue and digital outputs. It also provides non-invasive The two balanced analogue inputs are excursion limiting to protect the drivers. -
Page 12: User Eq Options
User EQ Options PMC’s twotwo active subwoofers feature DSP-based user-equalisation options. These comprise an adjustable low-pass filter to determine the frequency range over which the subwoofer operates, with an adjustable slope which allows perfect integration with the low-frequency response of the stereo satellite speakers. -
Page 13: Connections
Connections Caution To avoid potential damage, please ensure that the signal source is turned off before connecting or disconnecting your twotwo active subwoofer. Connections The rear panels of all twotwo active subwoofers carry the same connectors for audio, control and mains power as described below. www.pmc-speakers.com Audio The two electronically-balanced analogue inputs and the AES3... -
Page 14: Running In
Running-In 1 1 2 2 11 1 1 1 0 0 When brand new, PMC monitors will take a short period of use before they reach their full potential. This is because the mechanical and acoustical characteristics of the bass driver alter slightly after manufacture as the flexible surround elements relax and reach their optimum compliancy. -
Page 15: Applications - 2.1 Configurations
The diagram below illustrates one example of configuring the analogue audio and control connections in a stereo configuration using a twotwo sub1 active subwoofer to extend the bass performance of twotwo active monitors. In this arrangement the left and right analogue inputs are connected to the subwoofer, and the digital output from the subwoofer (suitably high-pass filterered, if desired) is passed on to the satellite twotwo monitors via RJ45 cable. - Page 16 Applications – 2.1 Configurations Centre Analogue Audio Input Source External Analogue Audio Connections 2.1 Configuration, Analogue Sources RJ45 Data Control Connections Controller Channel Front Front Optional Right Left Remote Controller menu back presets push to select mute Analogue In Analogue In Bass Extension Left Analogue Out...
-
Page 17: Applications - 5.1 Configurations
Applications – 5.1 Configurations Centre Analogue Audio Input Source External Analogue Audio Connections 5.1 Configuration, Analogue Sources RJ45 Data Control Connections Controller Channel Centre Front Front Optional Right Left Remote Controller menu back Centre presets push to select mute Analogue In Right Front Left Front Analogue In... -
Page 18: Applications - 7.1 Configurations
Applications – 7.1 Configurations AES3 L/R Digital Audio Input Source External Digital Audio Connections 7.1 Configuration, Digital Sources RJ45 Data Control Connections Controller Channel Centre AES3 In Front Front (Left) Optional Right Left Remote Controller menu AES3 via RJ45 back presets push to select mute... - Page 19 Applications – 5.1 further Configurations The examples below, and on the next page, illustrate possible configuration arrangements involving two subwoofers – one employed to handle the LFE signal from a 5.1 surround source, and a second used to extend the bass performance of the front stereo pair of satellite monitors. The same basic principles are employed as previously illustrated in the 2.1 and 5.1 configurations.
- Page 20 Applications – 5.1 further Configurations This is the same configuration as the previous page, with separate LFE and bass-extension sub-woofers, but using digital input connections. The front stereo digital audio signals are connected to the bass-extension sub-woofer, and then routed on to the front left speaker via an AES3 cable.
-
Page 21: Positioning & Alignment
Positioning & Alignment With their unique cabinet design, ultra-low distortion, and smooth bass roll-off, PMC loudspeakers are Advanced Transmission Line more forgiving of difficult room conditions and placement constraints than conventional designs. However, we encourage you to spend some time experimenting in your own room to achieve the very best results, remembering that small changes in location can often influence system performance significantly. - Page 22 Specifications Input Connectors Two balanced analogue (left/right) via XLR (female) One AES3 digital (left/right or summed channel selectable) via XLR (female) Input sample rate: 32 -192kHz, 24-bit via internal sample rate converter All XLR-3F connectors wired Pin-1 screen, Pin-2 hot, Pin-3 cold Each input has independent ±8dB trim range Outputs Two balanced analogue (left/right) via XLR (male)
- Page 23 Polarity Invert Off/On Phase Alignment 0 to 180 degrees (in 5 degree increments) Parametric EQ (PEQ) Off/On PEQ Gain -8.00dB to +7.87dB PEQ Frequency 20Hz to 150Hz (in 5Hz increments) PEQ Bandwidth Q adjustable between 1 and 8 in steps of 0.5 Left/Right Output Levels Fixed/Variable Left/Right Output Response...
- Page 24 Specifications Input Connectors Two balanced analogue (left/right) via XLR (female) One AES3 digital (left/right or summed channel selectable) via XLR (female) Input sample rate: 32 -192kHz, 24-bit via internal sample rate converter All XLR-3F connectors wired Pin-1 screen, Pin-2 hot, Pin-3 cold Each input has independent ±8dB trim range Outputs Two balanced analogue (left/right) via XLR (male)
- Page 25 Polarity Invert Off/On Phase Alignment 0 to 180 degrees (in 5 degree increments) Parametric EQ (PEQ) Off/On PEQ Gain -8.00dB to +7.87dB PEQ Frequency 20Hz to 150Hz (in 5Hz increments) PEQ Bandwidth Q adjustable between 1 and 8 in steps of 0.5 Left/Right Output Levels Fixed/Variable Left/Right Output Response...
-
Page 26: Operational Controls
Operational Controls The twotwo active subwoofers are configured and controlled via a simple menu system which is viewed on the rear panel display and navigated by four associated push-buttons. The first loudspeaker in a twotwo series chain acts as the master volume controller. Looking at the four cursor buttons, the left and right buttons step back (exit) and select (enter) the menu options, respectively, while the upper and lower buttons scroll through the various menu options and adjust the parameter values. - Page 27 Setup Mode Pressing the right (enter) button twice from the default volume display accesses the Setup menu, and the up/down buttons can then be used to access the various options. After selecting the desired option pressing the right button again displays the current parameter value, and the up/down buttons can be used to alter the value.
-
Page 29: Service
Service Service We are confident that your twotwo sub1 subwoofer will afford many years We are confident that your twotwo active subwoofer will afford many years of trouble-free listening of the highest order. However, in the unlikely event of trouble-free listening of the highest order. However, in the unlikely event... -
Page 30: The Pmc Range
The PMC Range The PMC range of professional monitors currently spans 25 different models, from the enormous BB5 XBD-A flagship system down to the diminutive twotwo.5 speaker. However, every monitor is designed with the same care and attention, using shared families of drive units, crossover designs and amplifiers. -
Page 31: Our Meticulous Care And Attention
Our Meticulous Care and Attention All PMC loudspeakers are hand-built in the U.K. using components that are individually matched to our reference model. This includes the structural integrity of every cabinet, and the testing and recording of each individual component to guarantee adherence to our strict tolerances. In this way we can ensure your purchase sounds identical to the original design. - Page 32 Inspection Checks Every component employed within a PMC product is measured, tested, matched and recorded by hand. This analysis also applies to the final product to ensure you receive an identical replica of the original reference model. Enclosure finish Assembly & Wiring Driver installation Enclosure seal Level –...
-
Page 33: Warranty On-Line
Warranty On-Line PLEASE ACTIVATE YOUR 5-YEAR WARRANTY ON-LINE GO TO WWW.PMC-SPEAKERS.COM AND CLICK ON ‘REGISTER A PRODUCT’ WARRANTY ON-LINE If you do not have access to the Internet please fill in the Warranty form on pages 34 and 35, and return to PMC. - Page 34 WARRANTy CERTIFICATE - PART 1 your copy to keep Please complete and retain this page for your own records Product Serial No’s Date of purchase Dealer’s name Dealer’s address Town County Postcode Dealer’s Telephone No. Servicing and warranty issues – Please read the following carefully. Non-UK clients Contact your local dealer/distributor for the details of warranty repairs –...
- Page 35 WARRANTy CERTIFICATE - PART 2 PMC’s copy Please complete and return this section – or simply complete the on-line registration at www.pmc-speakers.com and click on ‘Register A Product.’ Product Serial No’s Date of purchase Purchased from Your name Your email address Your address Town County...
-
Page 36: Help Us Improve. Your Comments
Help us Improve. Your Comments? We value all of our clients’ comments. Please take a moment to help us improve: If there is one thing we should change, what would it be? Please tell us how your new PMC loudspeakers perform. Your comments may appear on the customer quotes section for this product on our website –... - Page 37 Notes...
- Page 38 Notes...
- Page 39 twotwo is a trademark of The Professional Monitor Company Limited. This document should not be construed as a commitment on the part of The Professional Monitor Company Limited. The Professional Monitor Company Limited will not assume responsibility for errors that may appear in this document. Information may be subject to change.
- Page 40 T + 44 (0) 870 444 1044 E sales@pmc-speakers.com PMC stock code: 14767 W www.pmc-speakers.com Ref No. 613 - 06/15...
