Page 1: Amendent Records
VG1X, VG2X, VG53X and Series User Configuration Guide VopTel Technology Co., Ltd Page 1/67... -
Page 2: Table Of Contents
2.4.3 Application Examples of Routing Table .................36 2.4.4 IP Table...........................37 2.5 Line Configuration ..........................37 2.5.1 FXS or FXO Phone Number ....................37 2.5.2 Subscriber Line Features......................38 2.5.3 Trunk Line Features ........................41 2.6 Advanced Configuration ........................42 2.6.1 System.............................42 VopTel Technology Co., Ltd Page 2/67... - Page 3 2.9.3 Configuration export .......................63 2.9.4 Software upgrade ........................64 2.9.5 Software restart ........................65 2.9.6 System reboot..........................66 2.9.7 Restore factory settings ......................66 2.10 Version information ..........................66 2.11 Logout ...............................66 3 Appendix ............................67 3.1 VG59X system operation state ......................67 VopTel Technology Co., Ltd Page 3/67...
-
Page 4: Contents Of Figure
Contents of Figure Figure 1-1 VG1X Front Panel ........................10 Figure 1-2 VG1X Back Panel........................10 Figure 1-3 VG2X Front Panel ........................11 Figure 1-4 VG2X Back Panel........................13 Figure 1-5 VG53X,VG54X Front Panel....................14 Figure 1-6 VG53X,VG54X Back Panel ....................15 Figure 1-7 VG59X Front Panel .........................16 Figure 1-8 Schematic Diagram of VG59X Subscriber Line Connection...........17... - Page 5 Figure 2-28 Interface of export data ......................64 Figure 2-29 Interface of software upgrade ....................64 Figure 2-30 Interface of file upload......................64 Figure 2-31 Upgrade interface........................65 Figure 2-32 Prompt of upgrade process ....................65 Figure 2-33 Interface of successful upgrade....................65 VopTel Technology Co., Ltd Page 5/67...
-
Page 6: Contents Of Table
Table 1-3 Description of VG1X Front Panel.....................10 Table 1-4 Description of VG1X Back Panel .....................10 Table 1-5 Configuration Description of Analog Line Interfaces for All VG1X Models ......11 Table 1-6 Configuration Combination of VG2X..................11 Table 1-7 Description of VG2X Front Panel.....................12 Table 1-8 Pins and Indicators for Subscriber Line (FXS) or Trunk Line (FXO) of VG2X .......12... - Page 7 Table 2-24 Functional keys configuration parameter ................56 Table 2-25 Parameters of call state......................58 Table 2-26 Details for the call ........................59 Table 2-27 Parameters of system status.....................60 Table 2-28 Configuration parameters of debugging log management............62 Table 3-1 VG59X system operation state....................67 VopTel Technology Co., Ltd Page 7/67...
-
Page 8: Overview
VG Gateways are suitable for placement on office desktops or installation on walls in the corridor and racks in the equipment room. VG Series include VG1X, VG2X, VG100 and VG59X subseries. Their features are similar with the main differences as follows:... -
Page 9: Functions And Features
1.3 Equipment Structure 1.3.1 VG1X VG1X is the product with smallest capacity in VG Gateway Series. Designed with small plastic structure for desktop placement, VG1X can provide up to 8 analog line interfaces. VG1X supports the following types of configuration:... -
Page 10: Figure 1-1 Vg1X Front Panel
Number of FXO Ports VG1081 VG1082 Figure 1-1 VG1X Front Panel Table 1-3 Description of VG1X Front Panel Description Power indicator (PWR), the light on indicates that it has been powered. ① Ethernet interface indicator (ETH), the light on indicates successful connection, the ②... -
Page 11: Vg2X
Description ③ Analog subscriber line (FXS) or analog trunk (FXO) interface Table 1-5 Configuration Description of Analog Line Interfaces for All VG1X Models RJ11 Interface Configuration VG1X Models Subscribe Subscribe Subscribe Subscribe VG1040 r Line 1 r Line 2 r Line 3... -
Page 12: Table 1-7 Description Of Vg2X Front Panel
System in a diagnostic mode and able to execute Red Flash limited operation Green No alarms Alarm Red Flash New alarms occurred but not confirmed ALARM Indication Alarms existed and all alarm information confirmed VopTel Technology Co., Ltd Page 12/67... -
Page 13: Vg53X,Vg54X
25-pair cable supplied with the unit. VG53X,VG54X supports the following types of configuration: Table 1-13 Configuration Combination of VG53X,VG54X Models Number of FXS Ports Number of FXO Ports VG5480 VG5321 VG5322 VG5320 VopTel Technology Co., Ltd Page 13/67... -
Page 14: Figure 1-5 Vg53X,Vg54X Front Panel
System in a diagnostic mode and able to execute Red Flash limited operation Green No alarms Alarm Red Flash New alarms occurred but not confirmed Indication Alarms existed and all alarm information confirmed VopTel Technology Co., Ltd Page 14/67... -
Page 15: Vg59X
VG59X dual-chassis system can provide up to 96 ports. It supports the following configurations: Table 1-17 Configuration Combination of VG59X: Models Number of FXS Ports Number of FXO Ports VG59X-48S VG59X-72S VG59X-96S VG59X-24FXO VG59X-48FXO VG59X-72FXO VG59X-96FXO VG59X-40S/8 VG59X-64S/8 VG59X-88S/8 VG59X-36S/12 VG59X-60S/12 VG59X-84S/12 VG59X-32S/16 VG59X-56S/16 VopTel Technology Co., Ltd Page 15/67... -
Page 16: Figure 1-7 Vg59X Front Panel
CAT-5 cables are used to connect the interface card and distribution panel in equipment installation. Standard RJ11 telephone lines can be used to plug in a RJ45 socket. The telephone/trunk lines are connected to the 3 pair of pins for simple call test. VopTel Technology Co., Ltd Page 16/67... -
Page 17: Figure 1-8 Schematic Diagram Of Vg59X Subscriber Line Connection
System operation status indication: This is the mode for displaying information on system operation of equipment in specific conditions. Usually, this mode is entered when some prompts VopTel Technology Co., Ltd Page 17/67... -
Page 18: Figure 1-9 Vg59X Back Panel
System in a diagnostic mode and able to execute Red Flash limited operation Green No alarms Alarm Red Flash New alarms occurred but not confirmed Indication Alarms existed and all alarm information confirmed VopTel Technology Co., Ltd Page 18/67... -
Page 19: Figure 1-10 Schematic Diagram For Front Panel Of Vg59X Dual-Chassis System
To ensure the reliable communications between two chassises and reduce EMI interference, the communication cable for connecting two chassises should be short. VG59X dual-chassis system must be placed adjacently in installation (users who plan to expand capacity should reserve a space for VopTel Technology Co., Ltd Page 19/67... - Page 20 VopTel Technology Co., Ltd Page 20/67...
-
Page 21: Parameter Setting
2.1.1 Obtain Gateway IP Address VG1X and VG2X Gateways start DHCP service by default, and automatically obtain an IP address on the LAN; users can use the factory default gateway IP address if it is unable to be obtained (e.g. -
Page 22: Permission Of Gateway Administrator
They are required to log in again for continuing operations. Upon completion of configuration, click "Logout" button to return to the login page, so as not to affect the login permission of other users. VopTel Technology Co., Ltd Page 22/67... -
Page 23: Buttons Used On Gateway Management Interface
Subscribers can click “Restart” on the “Tool” page to restart. 2.3 Basic Configuration 2.3.1 Network Configuration After login, click “Basic > Network” tab to open the configuration interface. Figure 2-2 Network Configuration Interface VopTel Technology Co., Ltd Page 23/67... -
Page 24: Table 2-3 Network Configuration Parameters
Description Host name This is the equipment name of a configuration gateway. The default values of VG1X, VG2X, VG53X,VG54X and VG59X are VG1X-VoIP-AG, VG2X-VoIP-AG, VG53X,VG54X-VoIP-AG and VG59X-VoIP-AG respectively. Users can set a different name for each gateway to distinguish from each other according to the deployment plan. -
Page 25: System Configuration
(GMT+05:00) Karachi Almaty (GMT+06:00) (GMT+07:00) Bangkok (GMT+08:00) Beijing (GMT+09:00) Tokyo (GMT+10:00) Canberra (GMT+10:00) Adelaide (GMT+11:00) Magadan (GMT+12:00) Auckland 2.3.2 System Configuration After login, click “Basic > System” tab to open the system configuration interface. VopTel Technology Co., Ltd Page 25/67... -
Page 26: Figure 2-3 System Configuration Interface
The gateways provide the following processing modes after detecting hook flash from subscriber terminals: processing the hook flash internally; transmitting the hook flash to platform with RFC 2833, and transmitting the flash-off to platform with SIP INFO. VopTel Technology Co., Ltd Page 26/67... -
Page 27: Sip Configuration
Bit Rate (Kbit/s) Sending (ms) 13.3/15.2 iLBC 20/30 G729A 10/20/30/40 G723 5.3/6.3 30/60 PCMU/PCMA 10/20/30/40 2.3.3 SIP Configuration After login, click “Basic> SIP” tab to open the SIP configuration interface. Figure 2-4 SIP Configuration Interace VopTel Technology Co., Ltd Page 27/67... -
Page 28: Table 2-6 Sip Configuration Parameters
Note: If “Register by gateway” or “Line Reg/GW Auth”, is selected, the password must be entered here. If “register by line” is selected the password should be set on “Line > Feature” page (Refer to “Feature”). Registration Valid time of SIP re-registration in second. period VopTel Technology Co., Ltd Page 28/67... -
Page 29: Mgcp Configuration
Note: This parameter must be set since there is no default value. The factory setting is L/HD, L/HU: L/HD: Offhook; L/HU: Onhook. FXO event Handset Package package Line Pakage VopTel Technology Co., Ltd Page 29/67... -
Page 30: Routing
Select if the gateways actively cancel connection disconnect when when on-hook subscribers hook on, and default not selected. 2.4 Routing 2.4.1 Digit Map After login, click “Routing> Digit Map” tab to open the dialing rules interface as shown in Figure 2-6. VopTel Technology Co., Ltd Page 30/67... -
Page 31: Figure 2-6 Configuration Interface For Digit Map
Call Transfer, Do not Disturb, etc. [2-8]xxxxxx A 7-digit number starting with of any number between 2-8, used to end the dialing. 02xxxxxxxxx A 11-digit number starting with 02, used to end the dialings starting with “02”. VopTel Technology Co., Ltd Page 31/67... -
Page 32: Routing Table
When matched port is not in idle state, 486 will be returned for FXS port, and 503 will be returned for FXO port. When domain name is used in rule, DNS must be selected and enabled first. VopTel Technology Co., Ltd Page 32/67... -
Page 33: Table 2-9 Routing Table Format
Note: Number matching follows the principle of “minimum matching ”. For example: x matches any number with at least one digit; xx matches any number with with at least two-digit; 12x matches any number with at least 3-digit starting with 12. VopTel Technology Co., Ltd Page 33/67... -
Page 34: Table 2-10 Number Transformations
For calls from FXS ports with called party number of 1234, removing one digit at the rear of the calling number and add 8621; for call s from FXS ports with calling party number starting with 13, add 0 in front of the called number. VopTel Technology Co., Ltd Page 34/67... -
Page 35: Table 2-11 Routing Destination
Example 2: IP 800[0-3] ROUTE FXS 1 Point this call to FXS port 1. Example 3: IP 800[0-3] ROUTE FXS 1,2,3,4/g For terminating the call from IP, ring FXS port 1, 2, 3, 4 simultaneousely. VopTel Technology Co., Ltd Page 35/67... -
Page 36: Application Examples Of Routing Table
There are three circuit selection algorithms available: 1) sequential selection, 2) circular selection, and 3) simultaneouse ringing. Routing Setting: Take VG1X-4S/4 gateway as an example. Send the inbound call from IP trunk and analog line in a circular way to the phone set on the 2 or 3 FXS port. -
Page 37: Ip Table
A calling starting with 00 is barred to dial at 1-4 FXS ports. FXS CPN2 ROUTE NONE The telephone whose calling number starts with 2 at FXS port is barred to call out. FXO Port Hunting with Outbound Calls Routing Setting (take VG1X-4S/4 as an example): ROUTE 127.0.0.1:5060 ROUTE 1,2,3,4/r Description: Send all calls from FXS port to 5060 port of gateway local IP (this port must be consistent with the local port in “Configuring SIP”);... -
Page 38: Subscriber Line Features
This should be manually perform if Batch mode is not used. 2.5.2 Subscriber Line Features This page is only used for configuring gateways with subscriber lines (FXS port). After login, click “Line > Feature” tab to open the configuration interface. VopTel Technology Co., Ltd Page 38/67... -
Page 39: Figure 2-10 Configuration Interface For Subscriber Line Features
Delayed hot line: Automatically dial out the hotline number after offhook is timeout with a time delay of 5 seconds. After the hotline function is activated on this line, the hotline number must Hot line number be entered here. VopTel Technology Co., Ltd Page 39/67... - Page 40 Note: it is required to set the CRBT file download platform. This is not selected by default. VG1X and M100 support two CRBT storage modes: on-system (stored in a flash memory) and run-time download (from FTP server). The capacity of...
-
Page 41: Trunk Line Features
2.5.3 Trunk Line Features This page is only used for configuring gateways with trunks (FXO port). After login, click “Line > Trunk” tab to open the configuration interface. Figure 2-11 Configuration Interface for Trunk Line Features VopTel Technology Co., Ltd Page 41/67... -
Page 42: Advanced Configuration
FXO port. Used with the configuration item of “Answer delay” on the “Advanced > Trunk” interface. Advanced Configuration 2.6.1 System After login, click the label of “Advanced > System” to open this interface. VopTel Technology Co., Ltd Page 42/67... -
Page 43: Figure 2-12 Inferface Of System Advanced Configuraiton
SDP. This parameter can be set in IP address format or hostname format (note: DNS service should be activated when hostname format is used). There is no default value for this field. VopTel Technology Co., Ltd Page 43/67... - Page 44 “Configure network parameter”, and “DNS server” must be configured. Examples:“201.30.170.38:5060” and “softswitch.com:5060”. Signaling port Signaling port value of the gateway，the default value is 4660. Signaling port number could be set at will, but can not conflict with other ports of equipment. VopTel Technology Co., Ltd Page 44/67...
-
Page 45: Media Stream
This default value is 3. Higher value of this parameter could result in longer delay, therefore, it should be set with caution. Max. Jitter buffer RTP Jitter Buffer helps to reduce the influence brought by network jitter. The default value is 50. VopTel Technology Co., Ltd Page 45/67... -
Page 46: Table 2-17 Mapping Between The Reliability Requirement And The Tos Value
TOS Value (Low Delay and High Throughput) and Low Throughput) and High Throughput) 0x08 0x10 0x18 0x28 0x30 0x38 0x48 0x50 0x58 0x68 0x70 0x78 0x88 0x90 0x98 0xA8 0xB0 0xB8 0xC8 0xD0 0xD8 0xE8 0xF0 0xF8 VopTel Technology Co., Ltd Page 46/67... -
Page 47: Sip Related Configuration
Set the session refresh interval, the gateway will enclose the value of Session-Expires into INVITE or UPDATE messages. Default value is 1800 in second. Minimum timer Set the minimum value of session refresh interval. VopTel Technology Co., Ltd Page 47/67... -
Page 48: Characteristics Of Subscriber Line
Set whether to activate registration when SIP message of INVITE is INVITE timeout failed or time expired, and by default, re-registration is not selected. 2.6.4 Characteristics of subscriber line After login, click the label of “Advanced > line” to open this interface. VopTel Technology Co., Ltd Page 48/67... -
Page 49: Figure 2-15 Subscriber-Line Characteristics Configuration Interface
15 to 50 Hz, with default of 20 Hz. Caller release Set the delay release time of line as caller control method, with default of 60 seconds. Effective range of setting is 15~180 seconds. VopTel Technology Co., Ltd Page 49/67... -
Page 50: Characteristics Of Trunk Line
It’s essential to understand whether the phone supports the indicators and lighting method when selecting the lighting method. 2.6.5 Characteristics of trunk line After login, click the label of “Advanced > trunk” to open this interface. VopTel Technology Co., Ltd Page 50/67... -
Page 51: Figure 2-16 Trunk Line Characteristics Configuraiton Interface
10-60 seconds, with default of 24 seconds. Answer delay Set the delay time of outbound connection ranging from 10-60 seconds, with default of 12 seconds. Working with “Line >Trunk” interface and “Connect signal delay” configuration. VopTel Technology Co., Ltd Page 51/67... -
Page 52: Radius Call Logs
Secondary server fault appears in communications between gateway and preferred Radius server, the gateway will automatically activate standby Radius server. Note: in case of no configuration of port number, use default port number of 1813. VopTel Technology Co., Ltd Page 52/67... -
Page 53: Encryption
Choose whether to encrypt RTP voice pack, the default is “0” 0: None（not to activate)； 1: RTP（fully encryption to RTP package)； 2: RTP Header（only encrypt RTP header)； 3: RTP Body（only encrypt RTP payload)； 13: Encrypt with Newrock specific algorithm. VopTel Technology Co., Ltd Page 53/67... -
Page 54: Call Progress Tone Plan
Gateways provide tone plan for the following countries and regions: China; the United States; France; Italy; Germany; Mexico; Chile; Russia; Japan; South Korea; Hong Kong; Taiwan; India; Sudan; Iran; Algeria; Pakistan; Philippines; Kazakhstan; VopTel Technology Co., Ltd Page 54/67... -
Page 55: Functional Keys
Using *xx (dial * and 2 digits number ) to activate a service; Using #xx (dial # and 2 digits number) to cancel a service. Illustrate with following defaults of various parameters, which may be modified accoding to requirements. VopTel Technology Co., Ltd Page 55/67... -
Page 56: Figure 2-20 Functional Keys Configuration Interface
(please see the instructions on relevant configuration of “subscriber line”). Deactivate CFB The function key for deactivating call forwarding on busy, with default of #61. User operation: Off hook → press #61 → hang up. VopTel Technology Co., Ltd Page 56/67... - Page 57 User operation: off hook → dial the prefix number of abbreviated dialing（**）and dial abbreviated dialing number（20）。 Audit CRBT The function key for hearing the color ring，with default of *88. User operation: Off hook → press *88 → input color ring number. VopTel Technology Co., Ltd Page 57/67...
-
Page 58: Call Status And Statistics
Call The call state includes Idle, Ooutpusling, Ring, Entering number, In progress, Ring back, Talk, Near end hung up, Far end hung up, Timeout. Click the label of “check detail” to open detail interface. VopTel Technology Co., Ltd Page 58/67... -
Page 59: Log Management
The information about login of interface (including IP address and jurisdiction of the user); SIP registration status; Call related signaling and media (RTP) information; After login, click the label of “Logst > System Status” to open this interface. VopTel Technology Co., Ltd Page 59/67... -
Page 60: Table 2-27 Parameters Of System Status
For example: SIP Registration Info >>>>> ---- Not enabled ---- SIP Registration Info >>>>> Contact: <sip:2681403@220.248.27.70:1003； user=phone> latest response: 200 （timeout-555） Contact: <sip:2681402@220.248.27.70:1003； user=phone> latest response: 200 （timeout-555） Call Context Info Show the call status. VopTel Technology Co., Ltd Page 60/67... -
Page 61: Call Message
Figure 2-24 Interface of system startup 2.8.4 Manage log After login, click the label of “Logs > Manage Log” to open this interface. Log files can be downloaded through this interface. VopTel Technology Co., Ltd Page 61/67... -
Page 62: System Tool
The password being used by operator will be displayed as hidden codes, which could be changed by administrator at any time. The administrator is allowed to change the operator’s password by entering new password into “Operator password>password”. VopTel Technology Co., Ltd Page 62/67... -
Page 63: Configuration Import
After login, click “Tools >Export of configuration” to open this interface. It’s allowed to download the configuration files from the gateway through this interface. The downloading procedure is similar to the downloading procedure of log files.. VopTel Technology Co., Ltd Page 63/67... -
Page 64: Software Upgrade
Step 4: Click “Next” when the following interface appears, and start uploading the upgrade files to the gateway. Figure 2-30 Interface of file upload Step 5: Uploading will be completed in about 30 seconds, and click “Upgrade” on following dialog. VopTel Technology Co., Ltd Page 64/67... -
Page 65: Software Restart
For VG53X,VG54X and VG59X gateways, the software upgrade operation must be conducted on an 100M Ethernet port. 2.9.5 Software restart After login, click “Tools > Restart” to restart the gateway, making modified configuration come into effect. VopTel Technology Co., Ltd Page 65/67... -
Page 66: System Reboot
After login, click “Info” to view the gateway hardware and software version information. 2.11 Logout After login, click the “Logout” at top right to exit the gateway management system and return to the login interface. VopTel Technology Co., Ltd Page 66/67... -
Page 67: Appendix
“T” The application software of gateway has been exited. If it can not be restored by rebooting the system, please contact your local distributor for further diagnosis. VopTel Technology Co., Ltd Page 67/67...
