  • Page 1 VIP-150W VoIP WiFi Phone User’s Guide...

  • Page 2: Table Of Contents

    VIP-150W User’s Guide Contents: 1. Introduction, ........................3 2. Setup ............................. 4 2.1 Install the battery ............................. 4 2.2 Power on..............................4 2.3 Setup the necessary parameter......................... 4 2.3.1 Setup Wireless..........................5 2.3.2 Setup IP address ..........................5 2.3.3 SIP Setting............................5 2.3.4 STUN &...

  • Page 3: Introduction

    VIP-150W User’s Guide 1. Introduction, This VoIP WiFi Phone is an innovation of combining the most popular communication technology, WLAN and VoIP. The VoIP use the most popular standard that could easily connect with other VoIP service (ITSP, Voice over Broadband) or VoIP components (IP PBX, IP Centrex, SIP Proxy).

  • Page 4: Setup

    VIP-150W User’s Guide 2. Setup 2.1 Install the battery • Pull down the battery cap by push the battery cap lock. • Then move battery cap upward to open. • Put in the battery. • Put back the battery cap while the top of the cap is 3mm gap.

  • Page 5: Setup Wireless

    VIP-150W User’s Guide 2.3.1 Setup Wireless • The 1 time when you boot up the phone, it will automatically search for the available AP. You can also select by yourselves by following Step. • Select <Wireless Setting>, use up/down navigation key by scroll in the Setting Menu and press [Select] Softkey.

  • Page 6: Make A Call By Ip Address

    VIP-150W User’s Guide Once the callee answers the call, it will show the talking. At this moment, you will not hear the ring back tone and begin to talk each other. 3.2 Make a call by IP address You could dial by IP address as well. Dial IP address, “*” stand for “.” in the IP address.
  • Page 7 VIP-150W User’s Guide After input the correct ID and password it will show the main page for the web configuration as below. You could click the item to setup on the left menu. Some of the item (Management) will extend to the...

  • Page 8: Management Setting

    VIP-150W User’s Guide 4.2 Management Setting Configuration menu login name. User Name Configuration menu login password. Password Network Time Protocol (NTP) is a protocol used to help match your system NTP Server IP clock with an accurate time source (such as atomic clock, time server). It is good practice to have all your networked computers synchronized with one server.

  • Page 9: Management Setting - Restore Factory Setting

    VIP-150W User’s Guide 4.3 Management Setting – Restore Factory Setting Click on Management. Select Restore Factory Setting and the above screen will display on the screen. Restores all the settings back to factory default settings. Restore Factory Setting Management Setting – Firmware update FTP server, login ID, login password and firmware filename are preset when you purchase the phone.

  • Page 10: Network Setting - Dhcp

    VIP-150W User’s Guide 4.5 Network Setting – DHCP Select DHCP if you have cable internet. Dynamic Host Configuration Protocol (DHCP) Server address. This IP DHCP Server address information is obtained automatically from your ISP. 4.6 Network Setting – PPPoE (* Current version of firmware does not support PPPoE function) Choose PPPoE if your ISP uses PPPoE.

  • Page 11: Network Setting - Static Ip

    VIP-150W User’s Guide 4.7 Network Setting – Static IP Choose Static IP network setting if all Wide Area Network IP is provided to you by your ISP. IP address assigned to you by your ISP. IP Address Router IP address.

  • Page 12: Sip Setting - Message Server

    VIP-150W User’s Guide provider. SIP phone port number. SIP Phone Port Number Registrar server domain name or IP address. Registrar Server Domain Name/IP Address Registrar server port number. Registrar Server Port Number The time that the phone waits to connect to the SIP server after the user Authentication dialed a number.

  • Page 13: Sip Setting - Others

    VIP-150W User’s Guide 4.10 SIP Setting – Others There are many parameter could be adjusted to fit different kind of server. This function is reserve for technician who is familiar with SIP protocol. The time interval in which the phone periodically refresh SIP sessions by Session Timer sending repeated INVITE requests.

  • Page 14: Sip Account Settings

    VIP-150W User’s Guide 4.11 SIP Account Settings You may have up to 4 accounts. i.e., the IP phone can receive up to four different phone numbers. When you dial a number, the default account is used to dial. User Name of Default Account default account is displayed on the receiver’s IP phone.

  • Page 15: Stun Setting - Stun Server Setting, Upnp Setting

    VIP-150W User’s Guide 4.12 STUN Setting – STUN Server Setting, UPnP Setting Simple Traversal of User Datagram Protocol through Network Address STUN Translators is a protocol that allows applications to determine the types of NATs and firewalls are in between them and the internet. STUN also provides the ability for applications to determine the public IP addresses allocated to them by the NAT.

  • Page 16: Voice Setting And Qos

    VIP-150W User’s Guide Enable or disable universal plug and play. Some NAT supports UPnP so UPnP STUN is not required and must be disabled. 4.13 Voice Setting and QoS Voice Compression Algorithm priority settings. Select from the most used Codec codec to the least used codec.

  • Page 17: Phone Settings - Phone Setting

    VIP-150W User’s Guide 4.14 Phone Settings – Phone Setting Recall you can only enable or disable call forwarding from the IP phone MENU key. With the web-browser, you can enter the forwarded phone numbers in the Phone Setting menu. Reject all incoming calls.

  • Page 18: Phone Setting - Timer

    VIP-150W User’s Guide Click No Answer to enable call forward to another number when no one Call Forward answers the phone after 180s (default). The timer can be changed from 0-600s. Refer to section 7.14 to change the timer. Click Busy to enable call forward to another number when user is busy on the phone.

  • Page 19: Phone Book

    VIP-150W User’s Guide 4.16 Phone Book Phonebook menu allows the user to add, modify and delete phone numbers. To add, type in the name and number then click NEW to add. To modify/delete, select the name from the list and click modify/delete.

  • Page 20: Advance Function

    VIP-150W User’s Guide 5. Advance function 5.1 Phonebook Edit/ Browse This WiFi phone could store up to 200 records of phonebook. Each record you could store the name/number/E-mail address. There are 2 items on the phone book menu, New and Browse.

  • Page 21: Java

    VIP-150W User’s Guide 6. Java 6.1 Play JAVA game Select the {Entertainment} Icon in the Main Menu to load the Java virtual machine. Use the up down key to move the scroll bar up and down to select the application you want to execute.

  • Page 22: Java Download Process

    VIP-150W User’s Guide 6.2 JAVA download process This WiFi Phone could download the J2ME game from Internet. The key definition of the Java Virtual Machine is a little different than general setting. Left / Right key shows as soft keys functions. Middle key standard for activate key. (It has the same operation method as common JAVA games that define for 2.5/3G mobile.

  • Page 23: Firmware Upgrade

    VIP-150W User’s Guide 7. 7. Firmware upgrade. VIP-150W VoIP WiFi Phone builds in a TFTP server for user to upgrade the firmware with latest functions. Any authorized technician could easily download the firmware via TFTP. Press and hold [Off-hook] before you turn on the power. Wait about 5-7 sec, you can see the following screen.
  • Page 24 VIP-150W User’s Guide Use up/down select the item you want to modify. SSID XtendLan □DHCP ■Static IP 192.168.0.100 Subnet Mask 255.255.255.0 Default Gateway 192.168.0.1 Status : Ready to upload Apply Reboot If any item change press [Apply] to change the setting.
  • Page 25 VIP-150W User’s Guide Phone will show the following screen. Wait for 2-3 min to finish the upgrade SSID XtendLan ■ DHCP □Static 192.168.0.100 Subnet Mask 255.255.255.0 Default Gateway 192.168.0.100 Status : Upgrading …. Reboot Press [Reboot] to reboot. SSID XtendLan ■...
