Summary of Contents for Hi Resolution HRVR0404S
- Page 1 DIGITAL VIDEO RECORDER HRVR0404S USER MANUAL HRVR0804S HRVR1604S HR0905/ver.1.0 www.hrcctv.com...
- Page 2 USER MANUAL HRVR0404S-0804S-1604S NORME GENERALI DI SICUREZZA - General safety recommendations Sicurezza delle persone - Safety warnings Leggere e seguire le istruzioni - Tutte le istruzioni per la sicurezza e per l'operatività devono essere lette e seguite prima che il prodotto sia messo in funzione.
-
Page 3: Table Of Contents
USER MANUAL HRVR0404S-0804S-1604S SUMMARY Introduction ..........................6 Warnings and cautions ..................6 Package contents ...................6 CD-ROM software ...................6 Features and specifications ................7 Overview and controls......................8 Front panel ....................9 Rear panel ....................11 2.2.1 Overview..........................11 2.2.2 Connection sample ........................11 Remote control .....................12 Mouse control ....................13... - Page 4 USER MANUAL HRVR0404S-0804S-1604S 4.6.2 Alarm setup .......................... 29 Backup ......................31 4.7.1 Detect device ........................31 4.7.2 Backup ..........................31 PTZ Control and color setup ................31 4.8.1 Cable connection ........................31 4.8.2 PTZ setup ..........................32 4.8.3 3D intelligent positioning key ..................... 32 Preset/Patrol/Pattern/Scan................33...
- Page 5 USER MANUAL HRVR0404S-0804S-1604S 7.10 SMART PHONE vision..................73 Faq ............................73 Appendix Compatible SATA HDD List ................78 www.hrcctv.com pag.
-
Page 6: Introduction
USER MANUAL HRVR0404S-0804S-1604S Introduction 1.1 Warnings and cautions Do not expose this product to rain or moisture Take away from clammy Put in horizontal position Skip out to the violent vibration Do not rest up on another electric device Exposition at light air,,do not cooling off the rear of DVR. -
Page 7: Features And Specifications
USER MANUAL HRVR0404S-0804S-1604S 1.4 Features and specifications HRVR0404S HRVR0804S HRVR1604S Model Sistema Operating system Embedded Linux PENTAPLEX Funtion Live, recording, Playback, Backup, remoto access User interface GUI, on-screen menu tips. Control device Front panel, USB mouse, HRKB001, HRKB001NET, remote control Video Video input(PAL) BNC_1.0VP- P_ 75... -
Page 8: Overview And Controls
USER MANUAL HRVR0404S-0804S-1604S Backup mode USB-HDD, HRX001GB, HRX004GB, Network download, DVD built-in SATA burner Rete Interface RJ-45 10/100Mb Web server internet explorer Functions TCP/IP, DHCP, DDNS, PPPoE, FTP Remote operation playback, PTZ Control, file download, system setting, Log info. Auxiliary interface 2 USB 2.0... -
Page 9: Front Panel
USER MANUAL HRVR0404S-0804S-1604S This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front panel This series DVR has two different front panels. You can refer to figure... - Page 10 USER MANUAL HRVR0404S-0804S-1604S Fast play Various fast speeds and normal playback. In playback mode, playback the previous video Play previous In menu setup, go to upper ward of the dropdown list. In normal playback or pause mode, click this button to reverse...
-
Page 11: Rear Panel
USER MANUAL HRVR0404S-0804S-1604S In real-time monitor mode it works as left/right direction key. Shuttle(outer ring) Playback mode, counter clockwise to forward and clock wise to backward Up/down direction key. Playback mode, turn the inner dial to realized frame by frame playback. -
Page 12: Remote Control
USER MANUAL HRVR0404S-0804S-1604S 2.3 Remote control The remote control interface is shown as in figure Serial Number Function pag. www.hrcctv.com... -
Page 13: Mouse Control
USER MANUAL HRVR0404S-0804S-1604S remote switch Multiple-window switch 0-9 number key Record Auxiliary key Confirm /menu key Cancel Direction key forward Previous Back Next Slow play Stop Fast play Play/Pause 2.4 Mouse control Left click System pops up password input dialogue box if you have not logged in. - Page 14 USER MANUAL HRVR0404S-0804S-1604S In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here stands for backspace button. stands for space button. In English input mode: stands for input a backspace icon stands for deleting the previous character.
-
Page 15: Virtual Keyboard And Front Panel
USER MANUAL HRVR0404S-0804S-1604S 2.5 Virtual keyboard and front panel 2.5.1 Virtual keyboard The system supports two input methods: numeral input and English character (small and capitalized) input. Move the cursor to the text column, the text is shown as blue, input button pops up on the right. Click that button to switch between numeral input and English input (capitalized and small), Use >... -
Page 16: Connecting Power Supply
USER MANUAL HRVR0404S-0804S-1604S 5.Loosen the power cable 6 place the upper cover back and screw firmly 3.3 Connecting power supply Please check input voltage and device power button match or not.We recommend you use UPS to guarantee steady operation, DVR life span, and other peripheral equipments operation such as cameras. -
Page 17: Connecting Audio Input And Output,Looping Video, Matrix
USER MANUAL HRVR0404S-0804S-1604S 3.5 Connecting audio input and output,looping video, matrix For the 25-pin or 37-pin interface, different models include different functions. For example, DVR1604S has 16 audio inputs, 1 audio output, I bidirectional audio input. See figure 3.5.1 Audio input/one audio output DVR1604S has 16 looping video inputs, 1 matrix video outputs, 4 audio inputs, I bidirectional audio input, 1 audio output. -
Page 18: Alarm Input And Relay Output
USER MANUAL HRVR0404S-0804S-1604S 3.5.3 Alarm input and relay output The DVR offers 16 alarm inputs for external signaling devices, such as door contacts or motion detectors. Each alarm input can be either normally open or normally closed. Once configured, an alarm input can invoke many different activities, including triggering a relay device, sending an alert to a security office or storing pre-alarm video to the DVR. -
Page 19: Relay Output Description
USER MANUAL HRVR0404S-0804S-1604S 16-ch grounding alarm inputs. (Normal open or Normal close type) 6-alarm output . 3.5.7 Relay output description 6 ways relay alarm output. Provide external power to external alarm device. To avoid over loading, please read the following relay parameters sheet carefully. (See below table) The controllable +12v can be used to restore the smoke detector. -
Page 20: Other Interfaces
USER MANUAL HRVR0404S-0804S-1604S 3.6 RS232 You can connect the DVR with POS or Keyboard(HRKB001 e HRKB001NET) through RS232.With POS system, the DVR can communicate through RS232 and network. For the POS system, the DVR can integrate the text content and even search the record through the info RS232 3.7 RS485... -
Page 21: Overview Of Navigation And Controls
USER MANUAL HRVR0404S-0804S-1604S Overview of navigation and controls Before operation, please make sure you have properly installed HDDs and all the cable connections. 4.1 Login, main menu and logout 4.1.1 Login When the system boots up, default video display is in multiple-window mode. Click Enter or left click mouse, you can see the login interface. -
Page 22: Auto Resume After Power Failure
USER MANUAL HRVR0404S-0804S-1604S There are several options for you. The other ways is to press power button on the front panel for at least 3 seconds, system will stop all operations. Then you can click the power button in the rear panel to turn off the DVR. -
Page 23: Basic Operation
USER MANUAL HRVR0404S-0804S-1604S C: card and pos test overlay recording file(For some special series only)There are several playback windows. System supports 1/2/4-ch playback. Serial Function Number Play Backward Stop Slow play Fast play Previous frame Next frame Volume Previous file... - Page 24 USER MANUAL HRVR0404S-0804S-1604S File backup System supports backup operation during search. You can draw a before file name (multiple choices). Then click backup button . click the backup button and it will open the following screen completed the backup procedure by clicking on the backup button...
-
Page 25: Record Setup(Schedule)
USER MANUAL HRVR0404S-0804S-1604S 4.4 Record setup(schedule) When the system boots up, it is in default 24-hour regular mode. You can set record type and time in schedule interface. 4.4.1 Schedule menu In the main menu, from setting to schedule, you can go to schedule menu. There are three record types: R-Regular, MD-Motion detection, A- Alarm. -
Page 26: Detect
USER MANUAL HRVR0404S-0804S-1604S files once hard disk is full. Please note only read/write disk or read-only disk can backup file and support file search function, so you need to set at least one read-write disk otherwise you can not record video. - Page 27 USER MANUAL HRVR0404S-0804S-1604S Tour: Here you can enable tour function when alarm occurs. It is a one-window tour. Please go to chapter 5.3.9 Display for tour interval setup. Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu.
-
Page 28: Video Loss
USER MANUAL HRVR0404S-0804S-1604S 4.5.3 Video loss Select video loss from the type list. You can see the interface is shown .This function allows you to be informed when video loss phenomenon occurred. You can enable alarm output channel and then enable show message function. -
Page 29: Camera Masking
USER MANUAL HRVR0404S-0804S-1604S 4.5.4 Camera masking When someone viciously masks lens, the system can alert you to guarantee video continuity. Camera masking interface is shown a. Channel: select the channel you want to enable camera mask detection function. Event type: please select camera mask detect from the dropdown list. - Page 30 USER MANUAL HRVR0404S-0804S-1604S Record channel: you can select proper channel to record alarm video (Multiple choices). At the same time you need to set alarm record in schedule interface (Main Menu->Setting->Schedule) and select schedule record in manual record interface (Main Menu->Advance->Manual Record).
-
Page 31: Backup
USER MANUAL HRVR0404S-0804S-1604S 4.7 Backup 4.7.1 Detect device Click backup button, you can see an interface is shown.Here is for you to view devices information. 4.7.2 Backup Select backup device and then channel, file start time and end time. Click add button, system begins search. All matched files are listed below. -
Page 32: Ptz Setup
USER MANUAL HRVR0404S-0804S-1604S 4.8.2 PTZ setup Here you can set the following items: Channel: select the current camera channel. Protocol: select corresponding PTZ protocol(such as PELCOD) Address: default address is 1. Baud rate: select corresponding baud rate. Default value is 9600. -
Page 33: Preset/Patrol/Pattern/Scan
USER MANUAL HRVR0404S-0804S-1604S 4.9 Preset/Patrol/Pattern/Scan Click the “set” button. The interface is shown as below. Here you can set the following items: Preset Tour Pattern Border Click page switch button, the interface is shown.Here you can activate the following functions:... -
Page 34: Activate Pattern Function
USER MANUAL HRVR0404S-0804S-1604S 4.9.4 Activate pattern function Input mode value in the No. blank, and click pattern button. 4.9.5 Auto scan setup Click border button. The interface is shown.Use direction arrows to select camera left limit Then please go to 398HErrore. -
Page 35: General
USER MANUAL HRVR0404S-0804S-1604S 5.2.1 General General setting includes the following items. System time: here is for you to set system time Date format: there are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY. Date separator: there are three denotations to separate date: dot, beeline and solidus. -
Page 36: Encode
USER MANUAL HRVR0404S-0804S-1604S 5.2.2 Encode Encode setting includes the following items.Please note some series do not support extra stream. Channel: Select the channel you want. Compression: system supports H.264. Or you can select from the dropdown list. Resolution: System supports various resolutions, you can select from the dropdown list. For this model, we can support D1/CIF. -
Page 37: Schedule
USER MANUAL HRVR0404S-0804S-1604S 5.2.3 Schedule Please refer to chapter 4.4 schedule. 5.2.4 RS232 RS232 interface is shown as below. Here are five items. Function: There are various devices for you to select. Console is for serial port or min-end platform to upgrade program. - Page 38 USER MANUAL HRVR0404S-0804S-1604S IP Filter IP filter interface is shown as in 414HErrore. L'origine riferimento non è stata trovata.. You can add IP in the following list. The list supports max 64 IP addresses. Please note after you enabled this function, only the IP listed below can access current DVR.
-
Page 39: Alarm
USER MANUAL HRVR0404S-0804S-1604S DDNS setup DDNS setup interface is shown. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server).In network DDNS, input your PPPoE name you get from you IPS and server IP (PC with DDNS ) . -
Page 40: Default
USER MANUAL HRVR0404S-0804S-1604S Click modify button after channel. You can see an interface is shown. Please note all your modification here applies to local end only. You need to refresh web or client-end to get the latest channel name. System max support 25-digital character. -
Page 41: Search
USER MANUAL HRVR0404S-0804S-1604S Channel name Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu.Warning! System menu color, language, time display mode, video format, IP address, user account will not maintain previous setup after default operation! 5.3 Search... -
Page 42: Abnormity
USER MANUAL HRVR0404S-0804S-1604S Click alarm set button, the interface is shown as below. (This interface is just like the abnormity setup).Please highlight icon to select the corresponding function. You can enable one or more alarm setups. The lower limit ranges from 1% to 99%. Alarm channel number ranges from 1 to 6. -
Page 43: Manual Record
USER MANUAL HRVR0404S-0804S-1604S 5.4.4 Manual record Please refer to chapter manual record. 5.4.5 Account Here is for you to implement account management. Here you can: Add new user Modify user Add group Modify group Modify password. For account management please note: System account adopts two-level management: group and user. -
Page 44: Tv Adjust
USER MANUAL HRVR0404S-0804S-1604S 5.4.7 TV adjust Here is for you to adjust TV output setup..Please drag slide bar to adjust each item.After all the setups please click OK button, system goes back to the previous menu. 5.4.8 Video matrix Some series DVR have the matrix and loop outputs. - Page 45 USER MANUAL HRVR0404S-0804S-1604S Blue: for matrix outputs, there are 4-ch matrix outputs White: for bi-direction talk, one is for audio in and the other is for audio out. Video matrix interface and application The video matrix interface is shown . This series support 4-channel matrix outputs and series support 1 channel matrix output.
-
Page 46: Information
USER MANUAL HRVR0404S-0804S-1604S Alarm input 1 can activate channel1/2/3/4/5/6 Alarm input 2 can activate channel 2/3/4/5/6/7/8 Alarm input 1 and alarm input 2 activate video output 1. So, when there is alarm from channel 1, video output 1 becomes valid. If there is no alarm from alarm input 2 during the same period, then video output 1 can tour between channel1/2/3/4/5/6. -
Page 47: Hdd Information
USER MANUAL HRVR0404S-0804S-1604S 5.5.1 HDD information Here is to list hard disk type, total space, free space, video start time and status. Note: Please remove the broken hard disk before you add a new one.Once there is a hard disk confliction, please check hard disk time and system time is the same or not. -
Page 48: Version
USER MANUAL HRVR0404S-0804S-1604S 5.5.4 Version Here is for you to view some version information.. Channel Alarm in Alarm out System version: Build Date 5.5.5 Online users Here is for you manage online users. You can disconnect one user or block one user if you have proper system right. -
Page 49: About Auxiliary Menu
USER MANUAL HRVR0404S-0804S-1604S About auxiliary menu 6.1 Go to pan/tilt/zoom menu In the one-window surveillance mode, right click mouse (click “fn” Button in the front panel or click AUX key in the remote control). The interface is shown as below. -
Page 50: Web Client Operation
USER MANUAL HRVR0404S-0804S-1604S Here is a sheet for you reference. Name Function function Shortcut Function function Shortcut Zoom Near Focus Near Iris close Open Web client operation Please note, all the operation here is taking 16-ch DVR as an example. There might be slightly difference in the interface due to different series. - Page 51 USER MANUAL HRVR0404S-0804S-1604S After installation, the interface is shown as below. See 487HErrore. L'origine riferimento non è stata trovata..Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login.
-
Page 52: Real-Time Monitor
USER MANUAL HRVR0404S-0804S-1604S Preview window switch. System support 1/4/8/9/16-window real-time preview. Please you need to have the proper rights to implement preview operation. You can not preview if you have no right to preview the either channel. Section1 Section 3... -
Page 53: Start Dialogue
USER MANUAL HRVR0404S-0804S-1604S You can use button to refresh camera list. 7.2.2 Start Dialogue You can click this button to enable audio talk. Local Play Click local play button, system pops up the following interface for you to select local play file. - Page 54 USER MANUAL HRVR0404S-0804S-1604S In 498HErrore. L'origine riferimento non è stata trovata., click PTZ setup button you can see the following interface. Preset Move the camera to your desired location and then input preset value. Click add button, you have set one preset.
-
Page 55: Color
USER MANUAL HRVR0404S-0804S-1604S 7.2.4 Color Click color button in section 3, the interface is shown as 506HErrore. L'origine riferimento non è stata trovata.. Here you can select one channel and then adjust its brightness, contrast, hue and saturation. (Current channel border becomes green). -
Page 56: Configure
USER MANUAL HRVR0404S-0804S-1604S Configure In the main window, click config button, you can see an interface is shown 7.3.1 System information Version Click version button, you can see corresponding HDD information for your reference. HDD Information Here you can view HDD amount, HDD status, total volume and free space. -
Page 57: Setting
USER MANUAL HRVR0404S-0804S-1604S Click log button, you can see an interface is shown as in 518HErrore. L'origine riferimento non è stata trovata.. Here you can view current device log information. 7.3.2 Setting Setting includes the following items: General Encode setup... - Page 58 USER MANUAL HRVR0404S-0804S-1604S Detect Pan/Tilt/Zoom Tool Please note: setups for different device series may vary. Please refer to the corresponding user’s manual. General General interface is shown . System time: Here is for you to modify system time. Please click Save after your modification Data format: Here you can select data format from the dropdown list.
- Page 59 USER MANUAL HRVR0404S-0804S-1604S Schedule Schedule includes the following interface.When DVR boots up, it is in 24-hour continuous record. In this interface you can set record type, record time and period. Record type includes regular record(R), motion detection record (M) and alarm record (A).
- Page 60 USER MANUAL HRVR0404S-0804S-1604S Network Network interface is shown. This interface includes the following items: Max: Here you can set max connection amount. The value ranges from 0 to 10. 0 means no network connection is allowed. TCP port: default setup is 37777.
- Page 61 USER MANUAL HRVR0404S-0804S-1604S RS232 RS232 includes the following items.. Function: There are various devices for you to select. Console is for serial port or min-end platform to upgrade program. Keyboard is for you to use special keyboard to control current device.
- Page 62 USER MANUAL HRVR0404S-0804S-1604S Time period: Click set button, you can an interface . You can check the box to select the file type. System supports multiple choices. Alarm Please note before alarm setup, you need to properly connect alarm input and output device, send address and receive address.
- Page 63 USER MANUAL HRVR0404S-0804S-1604S Detect Detect interface is shown Here includes the following items: Channel: Select channel name from the dropdown list. Type: There are three types: motion detection/Video loss/Camera mask detection. Record channel: Here you can select record channel (Multiple choices). Please make sure you have set MD record in encode interface(Main Menu->Setting->Schedule) and schedule record in manual record...
- Page 64 USER MANUAL HRVR0404S-0804S-1604S pag. www.hrcctv.com...
- Page 65 USER MANUAL HRVR0404S-0804S-1604S Pan/Tilt/Zoom Pan/Tilt/Zoom interface is shown Please note you have properly set dome address and all connections are right. Decoder: Select the dome connected channel. Protocol: select the corresponding dome protocol.(such as Pelco) Address: Set corresponding dome address. Default value is 1. Please note your setup here shall comply with your dome address;...
- Page 66 USER MANUAL HRVR0404S-0804S-1604S Here you can export or import configuration information. .Save configuration data: Click export config button to save current setup as a file. Extension name is CFG.Load configuration data: Click import config button, you can load a setup file.
- Page 67 USER MANUAL HRVR0404S-0804S-1604S Click add user button, you can see the following interface..Here you can input a new user and then select corresponding rights.Please note one user must belong to one group and user right shall not exceed group rights limit.
- Page 68 USER MANUAL HRVR0404S-0804S-1604S HDD management This function needs DVR device supported. Please select the HDD first and then you can see the items on your right become valid. You can check the corresponding item here. After you completed setup, please click control HDD button, you can see the DVR begins restarting.
- Page 69 USER MANUAL HRVR0404S-0804S-1604S Video Matrix Video matrix interface is shown. Please note this function needs DVR supported. Snap Picture Snapshoot interface is shown . Please note this function needs DVR supported. (For special series only) www.hrcctv.com pag.
-
Page 70: Search
USER MANUAL HRVR0404S-0804S-1604S 7.4 Search Here you can select video type, channel number and time to search the file you want.Click search button, the interface is shown as below.Please use page up/down key to view the search results. Double click file name, you can view the file and system will automatically backup the image in you installation directory. - Page 71 USER MANUAL HRVR0404S-0804S-1604S Download You can select one or more files you want to download and then click down load button. System pops up a dialogue box asking you specify directory. Then you can input file name and click save to backup file in your local pc.
-
Page 72: Alarm
USER MANUAL HRVR0404S-0804S-1604S 7.5 Alarm Here you can set alarm type and alarm prompt audio file. 7.6 About Click about button, you can view current web client information. pag. www.hrcctv.com... -
Page 73: Log Out
USER MANUAL HRVR0404S-0804S-1604S 7.7 Log out Click log out button, system goes back to log in interface. 7.8 Un-install web control You can use web un-install tool “uninstall web. bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error. - Page 74 USER MANUAL HRVR0404S-0804S-1604S Seagate DB35.1 DB35.2 SV35 or Maxtor 17-g has compatibility problem. Please upgrade to the latest version to solve this problem. Front panel error. Main board is damaged. DVR often automatically shuts down or stop running There are following possibilities: Input voltage is not stable or it is too low.
- Page 75 USER MANUAL HRVR0404S-0804S-1604S Program read error, bit data is too small. There is mosaic in the full screen. Please restart the DVR to solve this problem. HDD data ribbon error. HDD malfunction. DVR hardware malfunctions. There is no audio when monitor There are following possibilities: It is not a power picker.
- Page 76 USER MANUAL HRVR0404S-0804S-1604S For Windows 98 or Windows ME user, please update your system to Windows 2000 sp4. Or you can install client-end software of lower version. Please note right now, our DVR is not compatible with Windows VISTA control.
- Page 77 USER MANUAL HRVR0404S-0804S-1604S Alarm output has been open manually. Input device error or connection is not correct. Some program versions may have this problem. Please upgrade your system. Alarm function is null There are following possibilities: Alarm setup is not correct.
-
Page 78: Appendix Compatible Sata Hdd List
USER MANUAL HRVR0404S-0804S-1604S Appendix Compatible SATA HDD List Manufacturer Series Model Capacity Type Seagate SV.35 SV.35.2 SATA Seagate SV.35 SV.35.3 SATA Seagate SV.35 SV.35.3 SATA Seagate Barracuda.10 ST3750640AS 750G SATA Seagate Barracuda.10 ST3500630AS 500G SATA Seagate Barracuda.10 ST3400620AS 400G SATA Seagate Barracuda.10... - Page 79 USER MANUAL HRVR0404S-0804S-1604S Technical specifications can be modified without notice. www.hrcctv.com pag.
- Page 80 USER MANUAL HRVR0404S-0804S-1604S HR EUROPE s.r.l. ROMA: sede legale e amministrativa; Via Giulianello, 1-7 – 00178 Roma, ITALIA – Tel +39 06 7612912 Fax +39 06 7612601 TORINO: sede operativa; Via G.B.Feroggio, 10 – 10151 Torino, ITALIA – Tel +39 011 453 53 23 Fax +39 011 453 70 49 SHANGHAI: ufficio di rappresentanza;...
