Summary of Contents for q-Tech NETQ-6000
- Page 1 NETQ-6000 Quick Installation Manual FOR ROUTER Enterprise High Power Outdoor Wireless Access Point NETQ-6000 Laptop IPAD...
- Page 2 NETQ-6000 quick installation manual for router Thank you for purchasing Enterprise High Gain wireless Router. This manual will instruct you how to configure router, and enable you to use it in a perfect status. After you have installed the router, you will be able to enjoy the surfing feely.
- Page 3 NETQ-6000 quick installation manual for router 1. Connect PC to one of the lan ports 2. Connect router’s Wan Port to ADSL Modem. Please do this only after you have finished the router configuration, to avoid any installation issues. This is very important.
- Page 4 NETQ-6000 quick installation manual for router B, Click “General ” ,Select “Obtain an IP address automatically” and “Obtain DNS server address automatically”, then click OK.
- Page 5 NETQ-6000 quick installation manual for router 1.3. log in wireless router A. Connect the configured PC to one of the four lan ports of router. Do not connect router to any other devices. (this is to avoid any IP address chaos), and switch on the router B.
- Page 6 NETQ-6000 quick installation manual for router 『Remark』Set up the router is necessary by wired or wireless network type. Please note the router setup page is not for internet. 1.4.Wizard Setting Finish internet connection and wireless encryption by setting wizard to enjoy...
- Page 7 NETQ-6000 quick installation manual for router Click and enter into“setting wizard” for below 3 steps. 2.1. Wlan Settings Please choose any one broadband setting method of below 3 2.1.1. ADSL（PPPOE）dial-up settings As example of China Telecom ADSL with below related details provided by telecom operator.
- Page 8 NETQ-6000 quick installation manual for router As example of a telecom operator fixed IP address with below related details. IP Address：212.197.17.56 Subnet mask：255.255.255.0 Gateway：212.197.17.254 Main domain name server：202.96.128.68 Sub domain name server：202.96.134.133 A. Static IP user should fill in the blank column upon IP address provided by telecom operator,as below picture.
- Page 9 NETQ-6000 quick installation manual for router Here you can set up LAN IP and DHCP address upon your needs.Or click “next” for wireless settings. 4.1. Wireless Settings Here you can amend router SSID and make encryption Pls write down the right SSID and security method in above picture( It is better to choose WPAPSK with secutiry), click finish to share the network.
- Page 10 NETQ-6000 quick installation manual for router Remarks: if you computer with build in 802.11b/g/n wireless USB adapter, and can’t search the available network, pls contact with after-sale department of your computer seller. With Wireless network connection: Right-click Network Neiborhood and choose Nature，only local connections or other connections, but no wireless...
- Page 11 NETQ-6000 quick installation manual for router List of Accessory: 1, Wireless broadband router; 2, power adapter; 3, quick installation guide; 4, 1Meter LAN Cable; 5, warranty card. FAQ: 1、It can not enter router setting interface after typing router IP in browser..
- Page 12 NETQ-6000 quick installation manual for router Pls check is there any other DHCP server in LAN, if yes, pls close it. The router’s original IP address is 192.168.1.1, pls make sure this IP address is different from other local networking. If same, pls change one. If the IP address is same in two different computers , pls change one to make them different.
