Race Navigator ONE Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
YOUR PERSONAL TRACK ASSISTANT
QUICKSTART   G UIDE


RACE-­‐NAVIGATOR.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONE and is the answer not in the manual?

Questions and answers

Related Manuals for Race Navigator ONE

Summary of Contents for Race Navigator ONE

  • Page 1 YOUR PERSONAL TRACK ASSISTANT QUICKSTART   G UIDE       RACE-­‐NAVIGATOR.COM  ...
  • Page 3  Thank you f or c hoosi ng RN ONE! Please read this manual before the first use of the device. Visit the website for more info: w ww .rac e-nav ig ator.c om Release date: 23.09.2014 r.    ...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS · HOME ................................7 · STATUS BAR ............................8 · DASHBOARD ............................8 03.1 · DASHBOARD · Panel 1 ......................8 03.2 · DASHBOARD · Panel 2 ....................... 10 03.3 · DASHBOARD · Panel 3 ....................... 10 ·...
  • Page 5 12.1 · TRACK VARIANTS ........................22 · EVENT ............................... 24 13.1 · EVENT · Trackday ........................24 13.2 · EVENT · Endurance ......................25 13.3 · EVENT · Taxi ..........................26 · NETWORK ............................... 27 · DEVICE ..............................28 15.1 ·...
  • Page 6 The RN ONE’s battery is pre-charged 5−10‚cm above the dashboard. so you can start using the device Adjust the RN ONE so that the top is immediately.   approximately in balance. Check the ...

  • Page 7: Home

    Driver Selection Driver Track Name Event Type This page is the main page of the RN ONE and is displayed when the system starts. This view can be opened from any location by clicking the Device home button under the screen.

  • Page 8: Status Bar

    The bar at the top of the screen contains important information about the RN ONE device and its current status. Device Name Warning Video When the icon shows up, you should check the device status by clicking on the item. You can also...
  • Page 9 Gap to Reference Chart The chart displays the gap for the last 20 seconds. Green color means the time advantage compared to the reference lap, the red one means the opposite. Next Panel Reference Lap Selection The fastest lap is automatically selected as the reference lap.

  • Page 10: Dashboard · Panel 2

    Recorded Laps 03.2 · DASHBOARD · Panel 2 Panel 2 presents the laps from the current event. The best lap of each driver is colored yellow. Previous Panel Full laps are colored white, while the others are grey. Selected reference lap is framed in blue. Reference Lap Time Panels ...
  • Page 11 In addition to the automatic recording possibility, you can also start and stop recording videos manually. Start/Stop Button To start recording, press the Start/Stop button on the right side of the Home Screen. Press the button again to stop recording. Start/Stop Button ...

  • Page 12: Recording With Obd-Ii Diagnostic Data

    RN PLUG and the USB Bluetooth RN Stick. The RN PLUG can be purchased for an additional fee. Plug the USB Bluetooth RN Stick into the USB • port in you RN ONE. Plug PLUG into OBD-II •...
  • Page 13 The list can be sorted by the column headers. You can change the sorting method by clicking on one of them. Current sorting column is colored red. Clean up There are two ways to delete laps: Remove all not complete laps.

  • Page 14: Lap Details

    LAP DETAILS Here you can get all lap details and view the recorded video. Back Button You can go one step back by clicking on the button. Review Drive Here you can watch the animation with the lap data. View Video...

  • Page 15: Video Player

    · VIDEO PLAYER In the player you can watch the video of the selected lap. Recorded movies consist of both camera views: outer and inner. Along with the camera views other lap data is presented like: track name, current time, lap time, current speed. Bars on the right and bottom edges of the inner camera view present the current G-force values.

  • Page 16: Analysis

    The chart displays speed series with colors corresponding to selected laps. The red line can be moved with a finger. The chart can be enlarged. The right Plus button zooms in width, the left one in the height.    ...

  • Page 17: Settings

    09 · SETTINGS Here you can specify all device and system parameters. Driver You can select a driver. You can select a car. Track You can select a track variant. Event You can select an event type. Network You can connect to the network. Camera ...

  • Page 18: Driver

    To select a driver, go to the Settings view and click on Driver. There will be the list of existing users. Scroll down the list and select the proper one. Press Set to confirm your selection. Edit You can edit an existing driver.
  • Page 19 Now, you can use the cockpit camera of the RN ONE to take a photo of yourself. Press Take to take a picture. Use the Back button to complete the process. Now, you can find the new driver on the list and select it.

  • Page 20: Car

    11 · To select a car, go to the Settings view and click on Car. There will be the list of previously added cars. Scroll down the list and select the proper one. Press Set to confirm your selection. Edit You can edit an existing car.

  • Page 21: Track

    Here you can find all available tracks and their  variants. Click on the track element to open the Track Variants view.  You can select one of the available track variants or create a new one (see 12.1.2).    ...

  • Page 22: Track Variants

    12.1 · TRACK VARIANTS All available variants of the selected track are enlisted here. Scroll down the list and select one of them. Press Set to confirm your selection. Edit You can edit a track variant. You can add a new track variant.
  • Page 23 Place the car exactly on the start line, press Start Track Recording and drive. The RN ONE automatically records the new track. When you cross the finish line again, the RN ONE stops recording and the new track is stored. NOTE: Make sure that the GPS signal is strong enough.

  • Page 24: Event

    13 · EVENT All available event types are enlisted here. You can browse the list and select one of them. Available types are colored white while the unavailable ones are colored grey. Press Set to confirm your selection. Trackday is default event type and is always available.

  • Page 25: Event · Endurance

    EVENT · Endurance Endurance is a special mode designed for • "Endurance" events, when it is important to obtain the video recorded by the Race Navigator to the memory stick immediately during the pit stop. • Recording requires the memory stick to be plugged in.

  • Page 26: Event · Taxi

    13.3 · EVENT · Taxi Taxi is a special mode designed for "Taxi" events. • • Recording requires the memory stick to be plugged in. Otherwise, the video is nor recorded and you are informed about missing memory stick. The videos and data are recorded directly on the •...

  • Page 27: Network

    14 · NETWORK You can select the one of two available connection modes: internet connection and analyzer mode. Analyzer Mode Click on this button to create the access point for your iPad. Now, you can download videos and data directly to your iPad and make more extensive analysis of your laps with our RN Analyzer app.

  • Page 28: Device

    Diagnostics You can download diagnostic data. RN Reset  You can reset various device settings.  Help You can read the descriptions of RN ONE functions. Video Logo You can change the video logo. 15.1 · DEVICE · Status Basic data of the device and its components are presented here.
  • Page 29 Commercial edition name of the software Device Name Unique name of the Race Navigator ONE device. Version The version of the installed software. Left SD/HD Video Time Estimated remaining recording time for SD/HD quality. Free Disk Space Free space on the hard drive.

  • Page 30: Device · Clock

    15.2 · DEVICE · Clock Here you can set the current date and time. Zones Zones  You can choose the proper time zone or set the time manually. Use the Back button to complete the process. 15.3 DEVICE · Update ·...
  • Page 31 You can install the latest version of the RN ONE software on you device. The connection to the Internet is required. Follow the instructions below to install the latest version. On the Settings page click the RN Device button and then the Update button. Make sure that your device is connected to the WiFi network (to connect, go to: Settings >...
  • Page 32 When the download is finished, click the Install button on the Updates view. Wait for the next screen. On the next screen click the Start Update button.      ...
  • Page 33 Installing a new version is in progress. It may take few minutes. The installation is finished with the successful message. Press the Back button to restart your device.      ...

  • Page 34: Device · Diagnostics

    15.4 · DEVICE · Diagnostics Here you can copy the diagnostic data directly to the memory stick. Press Export Data button to start the process. The memory stick is required to be plugged in. Otherwise, the Export data button is disabled and you are informed about missing memory stick.

  • Page 35: Device · Rn Reset

    15.5 · DEVICE · RN Reset Here you can reset various RN ONE settings and restore the device to the basic installation. 15.5.1 · RN Reset · Reset Event Data   Press the RN Reset button to display the list of events.
  • Page 36 15.5.2 · RN Reset · Factory Settings Press the RN Factory button to restore the device’s software to its original settings. In the next dialog, click YES to confirm or NO to abort the operation. The operation cannot be undone. 15.5.3 ·...

  • Page 37: Device · Help

    DEVICE · Logo  All available video logos are enlisted here. You can browse the list and select one of them. Press Set to confirm your selection. You can also import your own logos. When you plug the memory stick, your logos will be automatically added to the list.

  • Page 38: Autostart

    16 · AUTOSTART Different video recording modes are available. You can start recording manually or it can be activated automatically after exceeding the required speed: 20 km/h or 40 km/h. Select the mode by clicking on the proper element. Use the Back button to complete the process. 17 ·...

  • Page 39: Export Video

      The list can be sorted by the column headers. You can change the sorting method by clicking on one of them. Current sorting column is colored red. You can find the laps on the list and select it.
  • Page 40 (see also: www.race-navigator.com). The accordance to instructions published by MACRIX, accident. In case of a repair, please contact warranty is in force for a period of ONE (1) YEAR technical data and other instructions concerning MACRIX or an authorized MACRIX service.
  • Page 41 VAT tax and all necessary taxes and charges. normally in accordance with Macrix’s published PROTECTION AGAINST POSSIBLE FAILURES, THE guidelines for a period of ONE (1) YEAR from the USER SHOULD PERIODICALLY CREATE BACKUP CONSIDERATION OF WARRANTY CLAIMS date of original retail purchase by the end-user...
  • Page 42 Macrix product’s purchase, through one or more of the following options: the replaced product or part. If you follow the the Macrix manufacturer can repair or replace 1) Mail-in service.
  • Page 43 Macrix Customer Privacy Policy, the laws of the country in which the Macrix available at: www.race-navigator.com. product purchase took place. © 2014 Macrix: All right reserverd. RaceNavigator ONE is a trademark of GENERAL BATTERY Macrix company. No Macrix reseller, agent, or employee is...
