Introduction
The enclosed DVD includes instructions for several different GPS Tracker models from our manufacturer. If you
choose to use the DVD, you will Jind instructions for your tracker, "EyeTrak", under Model # TK302A. Please also
note that tracker instructions are the same, whether you use the enclosed Booklet or the DVD. Hence you do not
need both: Use whichever you prefer, but start with this quick guide.
Getting Started Steps
1.
Obtain an active SIM card and phone number. Your mobile carrier can help you set it up.
2.
The SIM card needs to be inserted with the SIM (brass metal part) facing up, and the side with the notch gets
inserted Jirst. Make sure to insert it into the slot, not the space below the slot.
3.
Once you have a SIM, you will then want to set up a minutes plan. Some carriers offer both monthly plans and
minute plans. A minutes plan may be helpful since your device use may be more sporadically used than a cell
phone.
4.
Take EyeTrak outside for initial set up in order to obtain a clear signal. We recommend Text message (SMS)
setup as the simplest method.
5.
The device IMEI number is needed to set up a minutes plan with your chosen carrier. You can Jind this on the
back of the device. Write this down in a safe place or take a picture of it.
6.
Begin by choosing your own password for your tracker:
a.
Text "begin123456 from your cell phone; device responds with "begin ok"
b.
Change the password by texting "password123456", followed by a space, then the password you
want to choose. You should receive a "password OK" message, meaning your new password is
enabled. Note: New password length should be 6 numeric digits.
Other Useful Tips & Troubleshooting
Hang on to your charging cord, as it isn't universal. If you do misplace it though, we have extras – contact us.
•
EyeTrak lights: The Red indicator light means the device is charging (and will turn off once charging is
•
complete). The Green indicator light means the device is on; it will Jlash once every second after acquiring a
GSM (mobile communication) signal, and every 3 seconds with a GPRS (2G/3G) signal. The Blue indicator light
means the GPS signal is being received, and will Jlash once every second after acquiring the signal. Note:
Signals can take up to a minute to receive.
The device can only be programmed to store and call (outbound) 3 phone numbers. However, 5 mobile
•
phones can be authorized to track the device. See instruction manual (page 8) on how to authorize a device.
Tracking the device is most easily done through your cell phone(s). It is possible to track the device using a
•
computer; however this requires a more involved setup process, including a setup fee of $10 for 5 years of
service or $3 for 1 year of service. If you are interested in this service, please contact us: info@modfamily.com
or see the instruction manual, pg. 27
o
If you get the message, "Your IMEI has Expired", this is because you are trying to set up the device
using a computer for tracking, but haven't yet paid the required fees (noted above).
"EYETRAK" GPS TRACKER QUICK REFERENCE GUIDE
Advertisement
Summary of Contents for Modfamily eyetrack TK302A
- Page 1 Introduction The enclosed DVD includes instructions for several different GPS Tracker models from our manufacturer. If you choose to use the DVD, you will Jind instructions for your tracker, “EyeTrak”, under Model # TK302A. Please also note that tracker instructions are the same, whether you use the enclosed Booklet or the DVD. Hence you do not need both: Use whichever you prefer, but start with this quick guide. Getting Started Steps Obtain an active SIM card and phone number. Your mobile carrier can help you set it up. The SIM card needs to be inserted with the SIM (brass metal part) facing up, and the side with the notch gets inserted Jirst. Make sure to insert it into the slot, not the space below the slot. Once you have a SIM, you will then want to set up a minutes plan. Some carriers offer both monthly plans and minute plans. A minutes plan may be helpful since your device use may be more sporadically used than a cell phone. Take EyeTrak outside for initial set up in order to obtain a clear signal. We recommend Text message (SMS) setup as the simplest method. The device IMEI number is needed to set up a minutes plan with your chosen carrier. You can Jind this on the back of the device. Write this down in a safe place or take a picture of it. Begin by choosing your own password for your tracker: Text “begin123456 from your cell phone; device responds with “begin ok” Change the password by texting “password123456”, followed by a space, then the password you want to choose. You should receive a “password OK” message, meaning your new password is enabled. Note: New password length should be 6 numeric digits. Other Useful Tips & Troubleshooting Hang on to your charging cord, as it isn’t universal. If you do misplace it though, we have extras – contact us. • EyeTrak lights: The Red indicator light means the device is charging (and will turn off once charging is • complete). The Green indicator light means the device is on; it will Jlash once every second after acquiring a GSM (mobile communication) signal, and every 3 seconds with a GPRS (2G/3G) signal. The Blue indicator light means the GPS signal is being received, and will Jlash once every second after acquiring the signal. Note: Signals can take up to a minute to receive. The device can only be programmed to store and call (outbound) 3 phone numbers. However, 5 mobile • phones can be authorized to track the device. See instruction manual (page 8) on how to authorize a device. Tracking the device is most easily done through your cell phone(s). It is possible to track the device using a • computer; however this requires a more involved setup process, including a setup fee of $10 for 5 years of service or $3 for 1 year of service. If you are interested in this service, please contact us: info@modfamily.com or see the instruction manual, pg. 27 If you get the message, “Your IMEI has Expired”, this is because you are trying to set up the device using a computer for tracking, but haven’t yet paid the required fees (noted above).
- Page 2 If installing tracking through your computer, you will be prompted for a user name and password, which is “admin” for both. The device can be used outside the United States wherever a GSM network is enabled, for example T Mobile • international plan. GSM network is common in Europe and many other countries throughout the world. There is an available App for both Android and IOS called “Tracker Home”. • Battery: Charge the battery using the included charger plus about 8-12 hours before use. The battery has up • to 180 hours of standby time once fully charged, however you should charge the battery regularly. Basic troubleshooting: See manual, page 28 • Text Message Device Code Commands For these commands, don’t type any of the “+” signs or the where “space” is shown as a word – just insert a space. All codes should be texted from an Admin’s Cell Phone. ADMIN SETUP: This command is used for the cell phone that Text call+password to the device; tracker replies • will control the device and be the SOS contact for that button “call ok” and can now receive and make calls. on the unit: Text admin+password+space+admin cell phone WALKIE TALKIE/CB RADIO DEVICE FEATURE • number Text speak+password to the device; tracker • For roaming purposes, may need to include your replies “speak ok” and device enabled for 2-way country code ahead of the cell phone number, plus a talk. “1” following this code. (U.S. country code is 011). SOS ALERT CONTACTS SETUP: These are 3 phone numbers the device can • Press SOS button on the device for 3 seconds call using the push buttons on the device: and it will text help me!+location info to all of • Set up device button 1 (dorsal Jin on EyeTrak): the authorized numbers and then dial them one Text “contact”+space+”one”+password+space after another, stopping when any authorized...
- Page 3 OVER SPEED ALARM: Triggers when pre-set speed violated. • To activate, text “gpssignal”+password+space Minimum allowed speed for tracking is 50 km/hour. +”on” • Set Up: Text “speed”+password+space+080”, • To deactivate, text “gpssignal”+password+space where “080” = 80 km/hour; device replies “speed +”off” OK!” If device exceeds speed, texts “speed”+080! CHECK IMEI #: This only works once the tracker has been • latitude & longitude” to authorized #’s every 3 enabled with an active SIM card and text plan minutes. Text “imei”+password to the device; device • • Cancel speed alarm by texting “nospeed replies with 15 digit IMEI to texted cell number +password” CHECK EYETRAK TRACKER STATUS LOW BATTERY ALERT – defaults as on Text “check”+password; replies GSM status (in • Tracker texts “low battery+latitude/longitude” %), GPS (OK or not), GPRS (On or Off) and Battery • 2X each 15 min ongoing when battery lowers to (in %) 3.55 V. Deactivate: text “lowbattery”+password+space FORWARD 3 PARTY TEXTS: Can forward message sent to • +”off”; Re-enable: “lowbattery”+password tracker from one third party phone to another cell number. An +space+”on”...
