Iron Ether Xerograph Deluxe Owner's Manual

Finish
Each Xerograph Deluxe is
etched and polished by hand, so
each one is unique; no two will
ever look alike.
Warranty
Your Xerograph Deluxe is war-
ranted for materials and manu-
facturing for one year from the
date of purchase. Your warranty
is void if you use the wrong type
of power supply, take it apart,
attempt to modify it or abuse it
by using it in a way not
intended.
Details
-Power: The Oxide runs on the
industry-standard 9 volt DC
center negative power supply.
-Bypass: The Oxide features a
click-free relay-based true
bypass system. This maintains
the benefits of true bypass:
when the pedal is bypassed,
your signal does not travel
through any electronic
circuitry; it's connected through
a mechanical switch directly
from input jack to output jack.
This way you can be certain
that no tonal coloration or other
signal change is happening
when in bypass.
In addition, it offers some ben-
efits over the common "3PDT"
bypass switch: if power to the
pedal is lost, it will automati-
cally go into true bypass, regard-
less of the setting of the bypass
switch. The relay used is
designed specifically for audio
switching, unlike the "3PDT"
switch, so it won't ever make
popping or clicking sounds, and
will remain quiet and reliable
for decades.
Iron Ether
Xerograph Deluxe
owner's manual
Out 9vDC Exp
S F 2
Res Sens
Clean Filter Vol
Xerograph
Deluxe
IE
In
4
Freq
Iron
Ether
