- Page 1 Owner’s Manual Tabletop Patio Heater Model: SHCTPH-SS-BK PH-T-107-MK IMPORTANT Read this manual carefully before assembling, using or servicing this heater. Keep this manual for future reference. For customer service, parts or warranty issues: Call 1-800-561-5550 or e-mail parts@jrhome.com...
-
Page 2: Table Of Contents
Contents DANGER General Safety Information........1 DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Contents Breakdown ..........Package Contents ..........WARNING Assembly..............WARNING indicates an imminently hazardous situation which, if not avoided, could result in death or serious injury. Portable Heater Location......... - Page 3 DANGER DANGER • EXPLOSION - FIRE HAZARD • Keep solid combustibles, such as building materials, • CARBON MONOXIDE HAZARD • This heater is a combustion appliance. All combustion paper or cardboard, a safe distance away from the heater as recommended by the instructions. appliances produce carbon monoxide (CO) during the •...
- Page 4 WARNING WARNING • This product is fueled by propane gas. Propane gas is • Children and adults should be alerted to the invisible, odorless, and flammable. An odorant is normally hazards of high surface temperatures. Stay away added to help detect leaks and can be described as a from these surfaces to avoid burning skin or igniting “rotten egg”...
-
Page 5: Contents Breakdown
Contents Breakdown Pins and Nuts(qty.3) Regulator Package Contents This outdoor/tabletop heater requires some assembly. Check over the contents to make sure all the parts are available for assembly. Contents: 1. Castle nuts (qty. 3) 11.3/16" Stainless bolts (qty. 4) 2. Reflector 12. -
Page 6: Assembly
Assembly Step 1 – Attach Base and Weight to Housing Fix the regulator(15) to the heater housing with one of Take out all the parts of the Tabletop Heater. Align holes the M5X10mm bolt & M5 nut(12). in base (6) to holes in weight (7). Align heater housing(13) with base(6) and weight(7) and use 4 - M6X15mm bolts(8) to attach Step 3 –... - Page 7 Step 4 – Attach Wire Guard to Burner Assembly Fasten the reflector(3) with 3 - castle nuts(1). Put guard(4) over emitter(3) and down onto the burner assembly(10). See below. Step 6 – Gas Tank Assembly Turn off the control knob of the burner. Fix the 1.02 Lb gas tank (not included) to regulator (rotate the tank clockwise toward the regulator until tight).
-
Page 8: Portable Heater Location
Procedure for Leakage Test Portable Heater Location 1. This portable heater is intended for outdoor use only. 1. Perodically check the whole gas system for leaks. Always ensure that adequate fresh air ventilation is 2. Immediately check for leaks if an odor of gas is detected. provided. -
Page 9: Troubleshooting
Troubleshooting If the problem is: And this condition exists: Then do this Cylinder valve is closed Open valve Blockage in orifice or pilot tube Clean or replace orifice or pilot tube Open gas line and bleed it (pressing control Pilot won’t light Air in gas line knob in) for not more than 1 - 2 minutes or until you smell gas... -
Page 10: Storage
1-800-561-5550 Note: Wait until heater is cool before covering. Customer Service / Imported by: JR Home Products Unit 1 - 5628 Riverbend Drive Burnaby During periods of extended inactivity or when BC Canada V3N 0C1...
