Summary of Contents for Activeon CX GOLD
-
Page 1: User Manual
USER MANUAL www.activeon.com... -
Page 2: Table Of Contents
9. Playback mode 10. Setup mode 11. Quick menu 12. Recharging Battery 13. Smart phone control 14. Connect ACTIVEON CX GOLD to smartphone(using ACTIVEON App) 15. Transferring data to computer 16. Firmware update 17. Features and speci cation 18. Inside the Package ※... -
Page 3: Name Of Each Part
ENGLISH www.activeon.com * Please read this manual carefully before the use! 1. Name of each part Mode / Navigation Internal MIC LED Indicator Power / Shutter (Top, Bottom, Front, Back) LCD Screen Speaker Li-ion battery slot microSD Card Slot Mini USB port... -
Page 4: How To Use
2. How to use Button operation ACTIVEON CX GOLD IS OPERATED BY TWO BUTTONS. ( button , button ) ● )BUTTON FEATURES “ Power, Shutter and Enter”. ● )BUTTON FEATURES ”Mode change, Program change and Navigator”. ● The feature of buttons are de ned as below table. -
Page 5: Touch Operation
Touch operation If you want to use the CX Gold display ● responds to touch-based gestures like tapping and swiping. Double-Tap Tap & Hold Swipe up, down, left, right You can easily access the menu ● Swipe Right Swipe left <Mode menu>... -
Page 6: Start The Camera
3. Start the camera 1. Open the battery cover and insert ACTIVEON CX GOLD Li-ion battery. 2. Insert microSD Card on the microSD Card slot. (The camera will not record when microSD Card is not inserted.) 3. Press the ( ) button and hold for two seconds. -
Page 7: Lcd Screen Shot
4. LCD screen shot Video screen Function Description ① ② ③ ④ Recording mode Recording mode / Program status ① Recording time Recording time information ② ⑤ ⑧ ⑤ WiFi WiFi status ③ ⑥ ⑦ Battery Battery status ④ Photo screen ①... -
Page 8: Graphical Icon Description
5. Graphical icon description Video mode Photo mode Playback Setup Time lapse Looping Burst Self-timer Time lapse Video Setup Photo Setup Effect Setup General Setup Connection Video Program Photo Program Quick menu WiFi Quick REC Beep Upside Down Speaker Brightness Manual Water sports Diving... -
Page 9: Mode Menu
6. Mode menu Mode menu is available with both button and touch screen. For Button : There are 4 modes in “Mode menu” - Video, Photo, Playback and Setup. 1. Press ( ) button once. Then Video mode icon will appear 2. -
Page 10: Video Mode
7. Video mode 1. After the camera is turned on, Press( ) button to start video recording. 2. When the camera starts to record, LED light blinks* and shows recording time on the screen. 3. Press( ) button to stop recording. 4. - Page 11 Program menu Program menu provides fast and simple camera e ect settings based on your environment. Program menu is available with both button and touch screen. For button 1. At the Video mode, press and hold ( ) button for two seconds. Then Program menu icon will appear.
-
Page 12: Photo Mode
8. Photo mode Please change your mode into Photo mode. Press ( ) button to change into Photo mode. 1. Press ( ) button. The mode menu will appear on your LCD screen. 2. Press ( ) button once again, the camera will change into Photo mode. 3. - Page 13 Program menu Program menu provides fast and simple camera e ect settings based on your environment. Program menu is available with both button and touch screen. For button 1. At the Video mode, press and hold ( ) button for two seconds. Then Program menu icon will appear.
-
Page 14: Playback Mode
9. Playback mode Please change the mode into Playback mode. User can view recorded video or photo on the screen. Press ( ) button to select control panel on top menu. While the le is playing, you can call the play control panel by pressing ( ) button. - Page 15 PLAYBACK (Video) Icon Description File type Playback Time / Total time ① Battery remaining Prev. le / Pause / Next le With one tap, you can hide the control bar. ② Delete / Back When you tap the screen once again, the control bar will appear.
-
Page 16: Setup Mode
10. Setup mode Screen shots of using button & Touch screen Please change the mode into Setup mode. Setup Option Video Setup Mode/Pixel/FPS/FOV/Interval Able to choose more options with Setup mode. ● Photo Setup Mode/Pixel/FOV/Interval Video Setup : Provides detailed video recording ●... -
Page 17: Setup Options
10-1. Setup options Function Description MODE Manual/ Looping/ Time Lapse RESOLUTION 1080P/ 720P/ 480P 240/120/60/30 Super wide/ Wide/ Medium/ Narrow T/LAPSE INTERVAL 0.5/ 1 / 3 / 5 / 10 /30 / 60 (sec) Function Description MODE Manual/Time Lapse/Burst/Self Timer MEGA PIXEL 16MP / 12MP / 8.5MP/ 7MP Super wide/ Wide/ Medium/ Narrow... - Page 18 Function Description Filter OFF/ BLACK&WHITE/SEPIA/ VINTAGE/ WARM AE Meter CENTER/AVERAGE/SPOT Zoom x1/ x2/x3/x4 AUTO/-2.0/-1.0/0/+1.0/+2.0 White Balance AUTO/3000K/5500K/6500K AUTO/100/200/400/1600/6400 Upside Down ON/OFF Time Stamp ON/OFF Function Description CONTROL MIC/Speaker/ LCD Brightness BEEP ON/OFF LED INDICATOR OFF/TWO/FOUR QUICK REC OFF/1SEC/3SEC/5SEC AUTO LCD OFF OFF/ 5min/ 10min/ 30min AUTO POWER OFF OFF/ 5sec/ 10sec/ 30sec...
-
Page 19: Quick Menu
Function Description WiFi ON/OFF WiFi INFO SSID-PW 11. Quick Menu Quick menu provides easy access to your Function Description most often used menu. WIFI ON/OFF Quick menu is only available with touch UPSIDE DOWN ON/OFF screen. QUICK REC ON/OFF(last setting value) BEEP ON/OFF 1. -
Page 20: Smartphone Control
13. Smartphone control Utilizing WiFi APP function of ACTIVEON, user can control the camera through smartphone. ● Compatible with iOS and Android OS. ● Before connecting the camera, download ‘ACTIVEON’ application from smartphone app store. ● Search for ‘ACTIVEON’ in Apple App Store or Google Play Store. - Page 21 On your smartphone or tablet, turn the WiFi on and select the network CXG-xxxxxx under WiFi setting. ● Default password is ‘1234567890’ . ● 'ACTIVEON' app on your smartphone or tablet. ● Press ’Connect ACTIVEON’ on the app. You can now control your ACTIVEON camera. ●...
-
Page 22: Transferring Data To Computer
While the camera is connected to a battery charger or car charger for recharge, ● the camera can record while it is recharging. 1. Power on ACTIVEON CX GOLD. 2. Connect the camera to a computer via USB cable. 3. The camera LCD will display as 'USB Ready' . -
Page 23: Firmware Update
16. Firmware update (Find the latest firmware at www.activeon.com) You can always nd the latest rmware updates of ACTIVEON products on the website. (www.activeon.com) ● Firmware upgrade may fail if battery is too low. ● Recharge up to two cells of battery gauge for proper upgrade. -
Page 24: Features And Specifications
17. Features and specifications “ACTIVEON CX GOLD” 1080p 60fps Action Camera. ● FULL HD(1920 x 1080) resolution, 60fps recording. ● 196ft(60m) waterproof housing. ● 16M SONY IMX CMOS sensor. ● Easily control camera E ect setting by Program mode. ●... -
Page 25: Inside The Package
18. Inside the Package... -
Page 27: Caution
CAUTION It could be exploded if the battery is inappropriate type. Please insert proper type of battery according to instructions. The symbol means that according to local laws and regulations your product should be disposed of separatly from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities. -
Page 28: Rf Exposure Information (Sar)
RF Exposure Information (SAR) NOTE : This appliance and its antenna must not be co-located of operation in conjuction with any other antenna or transmitter. A minimum separation distance of 20cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. This device meets the U.S. - Page 29 USA Warranty www.activeon.com...
-
Page 30: Warranty
For assistance (USA) – If you purchased ACTIVEON product in USA and have questions regarding the product or this Limited Warranty, please call 1-858-798-3300. Or visit www.activeon.com. It is the Purchaser’ s responsibility to properly package and send the Product, together with a copy of the original proof of purchase, an explanation of the problem, and a return address to ACTIVEON at the Purchaser’... - Page 31 EU Warranty www.activeon.com...
- Page 32 For assistance (EU) – If you purchased an ACTIVEON product in the EU and if you have questions regarding the Product or this Limited Warranty, please visit www.activeon.com. It is the Purchaser’ s responsibility to properly package and send the Product, together with a copy of the original proof of purchase, an explanation of the problem, and a return address to ACTIVEON.
