Rowley NS12 Safety, Operation And Maintenance Instructions

Safety, Operation and Maintenance Instructions
For Electric Upholstery Staple Gun (NS12)
Product Speci cations:
• Operating at 110 volts, 60 Hz, 12.5A.
• Staple type: 22 gauge ne wire, 71 series staples.
• Staple crown width: 9.1 mm.
• Staple leg length range:
• Use our fasteners. Stock #:
NS34/E, NS35/E .

Applications:

• Upholstery applications: covering cornice boards,
head boards, sofas, chairs, ottomans, upholstered
walls etc.
• Window treatment applications: covering dust boards,
mounting soft treatments to dust boards, etc.
Important:
This manual contains safety warnings, tool operation,
maintenance, cleaning procedures, parts list and
diagram. Keep the manual in a safe place for future
reference.

Limited Warranty

• The warranty covers material and workmanship
defects of the Electric Staple Gun (
• The warranty period is 90 days from the date of
purchase.
• During the warranty period, replacements or
repairs (at Rowley Co.'s discretion) of the tool will
be made free of charge.
• The warranty does not cover damages by accident,
misuse or due to using staples not recommended
by Rowley Co. Unauthorized repair or modi cation
of the tool will void the warranty.
• After warranty period expires, customers can still
receive repair services from Rowley Co. The
customer will be charged the labor and parts cost.
• To receive the repairs or replacements under
warranty or to obtain repair services after warranty
period expires, the tool must be returned to Rowley
Co. at the customer's expense.
• The user of the tool must read and understand the
safety warnings, tool operation procedures and
tool maintenance information contained in this
instruction manual. Rowley Co. is not liable for any
personal injuries or material damages associated
directly or indirectly with using this tool.
1 5
/ " to / ".
4 8
NS32/E, NS33/E,
NS12 ).

Safety Instructions:

Read and understand all safety, tool operation and
maintenance instructions BEFORE

A) Work Area Safety

1. Keep work area clean and well lit. Cluttered
benches and dark areas invite accidents. Always
keep the work area free of obstructions, grease,
oil, trash and other debris.
2. Do not operate the Staple Gun near ammable
fumes or liquids. Sparks created by the Staple
Gun may ignite fumes or liquids.
3. Keep bystanders, especially children away while
operating the Staple Gun.

B) Electrical Safety

4. The Staple Gun must be plugged into an outlet
properly installed and grounded in accordance
with all codes and ordinances. This Staple Gun is
equipped with a polarized plug and will t in a
polarized outlet only one way. If plug does not
plug fully into the outlet, turn the plug around. Do
not use any adapter plugs. Check with a quali ed
electrician if you are in doubt as whether an outlet
is properly installed.
5. Avoid body contact with grounded surfaces such
as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is
grounded.
6. Do not expose the Staple Gun to rain or any damp
or wet conditions.
7. Do not abuse the Power Cord. Never use the
Power Cord to carry the Staple Gun or yank it to
unplug the tool. Keep the Power Cord away from
heat, oil, sharp edges, or moving parts. Replace
damaged Power Cords immediately. Damaged
Power Cords increase the risk of electric shock.
8. If an extension cord must be used, make sure the
extension cord exceeds the recommended
minimum wire gauge (See Table below).
Cord Length (ft.)
Minimum Wire Gauge
9. Make sure your extension cord is properly wired
and in good condition. Always replace a damaged
extension cord.
10. Keep your extension cords from sharp objects,
excessive heat, and wet areas.
11. When operating the Staple Gun outdoors, use an
outdoor rated extension cord.
Updated August, 2007
1
using the tool.
0-25 26-50 >50
14 1 0
Rec ommended
© Rowley Co. 2007
I-50AA
Not
