Telvue InfoVue Pro Getting Started

The following instructions for launching a TelVue InfoVue system include configuring both the InfoVue
!
Pro Player and the InfoVue Stick (see back page). The rack-mounted Pro Player is generally for
broadcast and streaming applications, whereas the ultra-compact Stick is generally for individual
monitors, or to fully preview any content and design changes before publishing.

Set up the InfoVue Pro Player

1

Install in a Rack

To install the InfoVue Pro Player in a rack, use the ears to bolt the server in place.
Gefen HDMI Detective
Plus
Plugs into an HDMI
monitor (optional)
2

Plug In HDMI

Plug the InfoVue Player Pro HDMI output into the Gefen HDMI Detective Plus HDMI Input as
shown. Then optionally plug the Gefen HDMI Detective Plus HDMI Output into an HDMI
monitor for monitoring purposes.
!
Please do NOT connect the power supply to the Gefen device. This will cause it to malfunction.
The Gefen HDMI Detective Plus simulates an HDMI monitor being connected to your InfoVue
player at all times to prevent any interruptions to the IP streaming output when the display used
for monitoring is unplugged or turned off. It also allows you to run the player headless (without
a monitor) and still support the IP streaming output. If you are not using the IP output and are
just using the HDMI output to feed a fixed display or encoder, the Gefen is not required, but
still recommended.
Back Side of InfoVue Server
2
1
3
Plugs into HDMI
1. 6.
Power Mouse
2. 7.
Display Port Keyboard
(DP)
3. 8.
HDMI USB
4.
9.
Ethernet [0] DVI
5. 10.
Ethernet [1] Serial Ports
16000 Horizon Way
Mount Laurel, NJ 08054
800.885.8886
We share your vision™
3

Power Up

4
Power up the InfoVue Pro server.
Log In & Configure Networking
There are two ways to log in to the InfoVue User Interface:
a. USE PRE-SET IP - requires InfoVue Pro, ethernet cable, and an additional computer.
i. Assign IP address values to a network port on your computer:
1. IP 192.168.0.101
2. Net Mask: 255.255.255.0
ii. Connect ethernet cable between your computer and eth1 port on InfoVue.
iii. Access the Web UI from a web browser, login to InfoVue User Interface:
5
4
9 10
6 7 8
b. SET YOUR OWN IP - requires InfoVue Pro, keyboard & mouse, and HDMI monitor.
i. Attach an HDMI monitor by plugging the HDMI output of the connected Gefen from
ii. Attach keyboard & mouse
iii. Assign static IP to eth0 - Management.
(not used)
iv. Once IP configuration is completed, press Ctrl+Alt+Del and reboot the InfoVue
v. Now you can access the Web UI from a web browser. Login to the InfoVue User
Refer to the online user instructions on
encoder streaming settings.
Email: support@telvue.com
Online Resources: www.telvue.com/products/infovue
http://192.168.0.242. (This is the factory-assigned IP address for your InfoVue box.)
Step 2. above into your monitor HDMI input.
1. Press Ctrl+Alt+Del to bring up the Windows login window.
2. Log off the existing login.
3. Log in as user "config" with password "config".
1. Double click the desktop icon "Network":
a. Choose "Change adapter settings" (left side)
b. Double click on eth0 - Management.
c. Select Properties.
d. Choose Internet Protocol Version 4 (TCP/IPv4).
e. Click the properties button.
f. Choose "Use the following IP address" and fill in your network
specific values.
player. Your InfoVue Pro Player is now ready to receive content.
Interface at: http://(your IP address from previous step).
how to use the Web UI
http://www.telvue.com/infovue-pro-configuration-ui/
Turn the page for additional steps.
