Summary of Contents for AirKing CVS-22E QuietDrive

  • Page 1 CVS-22E QuietDrive Premium Pack ®...

  • Page 2: Important Safety Instructions

    iMPOrTANT sAFeTY iNsTruCTiONs * REad all inStRuCtionS before using the Electric Powerhead. When using this electrical appliance, basic precautions should always be followed, including the following: WaRninG: Electric shock could occur if used outdoors or on wet surfaces. Unplug and disconnect power before servicing. Always turn off this appliance before connecting or disconnecting either hose or motorized nozzle.
  • Page 3 sAVe THese iNsTruCTiONs CVS-22E CT20dXQd electric Package Individual tools may vary and are subject to change at any time. PaCkaGE inCludES: Ct20dXQd — 14” QuietDrive Electric Brush ® 99396 — 30 FT Universal Connect Hose 51691 — Integrated Telescopic Wand w/ButtonDown ™...

  • Page 4: Features Include

    CT20dXQd 14” eleCTriC BrusH This powerbrush, with metal agitator, is to be used to vacuum wall-to-wall carpeting, handmade carpets, fine rugs, and other flooring. This powerbrush must be used with the integrated wand. FEatuRES inCludE: Soft over molded wheels mean Height adjustment for a wide Brushroll design channels less wheel noise on hard floor...
  • Page 5 sAVe THese iNsTruCTiONs iNTegrATed TelesCOPiC WANd A gentle push on Button- Down releases your hose ™ from the wand. No struggling with tiny buttons or strain to separate the hose for above the floor cleaning. The hose to wand connection is designed for a positive lock with a reliable recessed electrical connection.
  • Page 6 CT20dXQd eleCTriC BrusH iNsTruCTiONs inStallation: Read important safety instructions before installing powerhead. Ensure vacuum cleaner is disconnected from power supply before installing powerhead. Connect extension wands from vacuum into powerhead’s neck. StoRaGE: Ensure vacuum cleaner is disconnected before unplugging powerhead. Disconnect wand from hose.
  • Page 7 sAVe THese iNsTruCTiONs CT20dXQd eXPlOsiON 40713 SCREW 40724 MOTOR GASKET 40999 BELT 40284 MOTOR SPRING 41010 LOWER PLATE 41021 MOTOR 40317 MOTOR BRIDGE 41032 OVERLOAD PROTECTOR 39943 LIGHT BULB 41043 BULB SOCKET 40339 HANDLE RELEASE PEDAL 40350 SWIVEL 40768 WIRE CONNECTOR 40383 SWIVEL SEAL 41054...

  • Page 8: Three Position Switch

    4-Wire sWiVel eleCTriC CrusH-PrOOF HOse The “slimfit” style handle has 360° rotation to minimize kinks, effort, and in-hand weight. For use with the electric brush. HoSE HandlinG: Hold the hose and handle in any way you find to be the most comfortable.
  • Page 9 sAVe THese iNsTruCTiONs CleANiNg ATTACHMeNTs ANd TOOls PlaStiC HoSE HanGER: • Use of hanger can increase the life of your hose and save space while storing. • Coil your hose around this hanger to store when not in use. • Mount on a wall in a closet, garage, or any other convenient location for hose storage, and place it high enough so you can loop your hose only four times and still clear the floor.
  • Page 10 CleANiNg ATTACHMeNTs ANd TOOls uPHolStERY tool: • Cleans upholstered furniture, drapes, mattresses, and even works well on vehicle upholstery and carpets. • Won’t seal to the floor or furniture, keeping the air flow neces- sary for effective cleaning. intEGRatEd tElESCoPiC Wand: •...
