DigiSender HDPRO3 DGHDP3 Instruction Manual

1080p powerline av sender system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model : DGHDP3
®
DigiSender
HDPRO3
1080P Powerline AV Sender System
Please keep this instruction manual for the future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDPRO3 DGHDP3 and is the answer not in the manual?

Questions and answers

Related Manuals for DigiSender HDPRO3 DGHDP3

Summary of Contents for DigiSender HDPRO3 DGHDP3

  • Page 1 Model : DGHDP3 ® DigiSender HDPRO3 1080P Powerline AV Sender System Please keep this instruction manual for the future reference.

  • Page 2: Table Of Contents

    1080P Powerline AV Sender System User Manual Table of Contents SAFETY WARNINGS ..................... 2  1.  Introduction ..................... 5  2.  Quick Setup Guide ..................6  3.  Troubleshooting ....................8  4  Video Source Remote Control ..............10  5  Remote Controller ..................11  6 ...

  • Page 3: Safety Warnings

    1080P Powerline AV Sender System User Manual SAFETY WARNINGS These safety warnings are provided to ensure the best user experience with the least inconvenience. Please read this user manual completely before installation and operation. It is advised that you keep the original packaging and protective material in case you need to safely transport the equipment in the future (e.g.
  • Page 4 1080P Powerline AV Sender System User Manual  Only use a dry cloth to wipe down the case. Do not use liquid cleaners or spray cleaners.  Do not place the devices in areas that are confined in a limited space (e.g. in the middle of a crowded bookshelf).
  • Page 5 1080P Powerline AV Sender System User Manual  Components that are consumptive in nature (e.g. battery) are not included in the warranty and will incur a fee when replaced. 【ABOUT ABNORMAL OPERATIONs】  If any smoke or odors emanate from these devices, turn off the device immediately, unplug the power cable from the socket and contact your dealer;...

  • Page 6: Introduction

    1080P Powerline AV Sender System User Manual 1. Introduction The 1080P Powerline AV Sender System DGHDP3 incorporates HDMI™ technology, allowing you to transmit HD Video anywhere in your home using existing Power lines. This avoids the complexities of rewiring your house or buying new Video Equipment (e.g.

  • Page 7: Quick Setup Guide

    1080P Powerline AV Sender System User Manual 2. Quick Setup Guide This chapter describes how to get your DGHDP3 AV Sender System environment quickly installed. After the setup, you will be able to view video that is streaming from a video player on one power outlet to a TV on another power outlet anywhere in your home.
  • Page 8 1080P Powerline AV Sender System User Manual Step 3: Power on TV set and Blu-Ray Disc player Power on your TV set and Blu-Ray Player in any order. Place a Blu-Ray video disc into the player. Step 4: Connect the power cables to the TX and RX Connect one end of the TX power cable to the Transmitter.

  • Page 9: Troubleshooting

    1080P Powerline AV Sender System User Manual 3. Troubleshooting If no video displays on the remote TV attached to your RX, proceed with the steps below: Step 1: Check connections, power and equipment  Make sure all power connections are secure and power is supplied to all equipment.
  • Page 10 1080P Powerline AV Sender System User Manual Step 2: Pairing procedures for troubleshooting “Pairing” refers to the process where two independent systems (i.e. RX and TX) identify themselves and establish/re- establish the link over the powerline or Ethernet network. You can use these procedures when troubleshooting your system (i.e.

  • Page 11: Video Source Remote Control

    1080P Powerline AV Sender System User Manual 4 Video Source Remote Control With the DGHDP3 AV Sender System, you can control your video player from the remote location (i.e. where RX is located) using the Video Player’s remote controller (must be Infrared Remote Controller). The RX is fitted with an IR sensor that receives the signals and sends them over the power lines to the TX, where the TX re-emits the same IR signals to the video player.

  • Page 12: Remote Controller

    1080P Powerline AV Sender System User Manual 5 Remote Controller The DGHDP3 AV Sender System comes with its own Remote Controller Unit that is designed to control the Transmitter and Receiver. The Remote Controller can manipulate the TX locally or from a remote location (i.e. where receiver is located). The receiver accepts IR signals from the Remote Controller and passes them to the transmitter through the power lines.
  • Page 13 1080P Powerline AV Sender System User Manual Remote Controller Button Descriptions Area Name Description Toggles the states of the TX and RX between Active mode and Power Saving mode. Power Saving mode is the state you can set the TX and RX to when not in use.
  • Page 14 1080P Powerline AV Sender System User Manual Area Name Description 50 Hz (PAL). When the OSD menu is displaying, this button is used to enable/disable the display of PLC throughput warning message Setting Information (for RX) Displays OSD information Setting Scroll up (for RX) Scroll up button on the OSD Menu Setting...

  • Page 15: Osd Menu

    1080P Powerline AV Sender System User Manual 6 OSD Menu When the system is active, you can press the “Menu” button on the remote controller to bring up the OSD menu on the display attached to the RX. The OSD menu is used to configure various options as described below.
  • Page 16 1080P Powerline AV Sender System User Manual OSD Menu Descriptions Menu Item Description Options  English  German  Spanish  Japanese Language Selects language for OSD Menu  Italian  Traditional Chinese  Simplified Chinese  French  Auto Detect Choose the option that best matches your Network ...

  • Page 17: Ethernet Over Plc Function

    1080P Powerline AV Sender System User Manual 7 Ethernet over PLC Function The “Ethernet over PLC” Function allows you to deliver Ethernet data anywhere in your home over Power Lines. This means that you can access the Internet and browse the web from anywhere, without rewiring your entire home with Ethernet cabling.

  • Page 18: Running Tx As A Standalone Box

    1080P Powerline AV Sender System User Manual 9 Running TX as a Standalone Box You can use the TX in standalone mode without the RX. In other words, you can use the TX, along with the TV and input video devices attached to it, as a standalone system (i.e.
  • Page 19 1080P Powerline AV Sender System User Manual Press the “OK” button to confirm the selection. SETUP Select TX Station If the selected TX is currently transmitting the video, the video should TX Station 1 begin to display. TX Station 2 【Modifying the name of a TX device】...

  • Page 20: Appendix 1 Rx/Tx Pairing

    1080P Powerline AV Sender System User Manual Appendix 1 RX/TX Pairing These procedures are used when you want to add an additional RX into the environment or re-pairing RX/TX is necessary. “Pairing” is performed to establish/re-establish a logical connection between the RX and TX.

  • Page 21: Appendix 2 Reset Rx/Tx To System Defaults

    1080P Powerline AV Sender System User Manual Appendix 2 Reset RX/TX to System Defaults The procedures below set the RX and TX to factory defaults and are used when troubleshooting the system (i.e. Video fails to appear on TV attached to RX). RX/TX paired Powerline network PLC pre-paired...

  • Page 22: Appendix 3 Plc Pairing

    1080P Powerline AV Sender System User Manual Appendix 3 PLC Pairing  The paired PLCs form a logical network when connected to common power-line media. This is pre-paired during manufacturing. It’s not necessary to re-pair the PLCs normally.  Note: As the above application example, RX is well-paired with TX already when manufacturing.
  • Page 23 1080P Powerline AV Sender System User Manual PLC pairing with other PLC adaptors If you would like to connect the power line network to the legacy power line network(Home Plug AV series), you have to do PLC pairing before you connect it. ...

  • Page 24: Appendix 4 Trouble Shooting Checklist

    1080P Powerline AV Sender System User Manual Appendix 4 Trouble Shooting Checklist Trouble Shooting Scenario Possible Reason Resolution TV attached to the RX  Power is switched “off” at  Make sure the power switches on the displays no video the RX or TX.
  • Page 25 1080P Powerline AV Sender System User Manual Trouble Shooting Scenario Possible Reason Resolution cut). sure both are turned “On＂.  Power supply short  If the suggestions above do not remedy the problem, the power supply in the devices may have a short. Unplug the power cords immediately and contact your dealer.
  • Page 26 1080P Powerline AV Sender System User Manual Trouble Shooting Scenario Possible Reason Resolution  RX is continuously  If the Power LED indicator keeps rebooting. turning on and off, the power supply may not stable. Unplug the power cord and contact your dealer. ...

  • Page 27: Appendix 5 Tx Led Definitions

    1080P Powerline AV Sender System User Manual Appendix 5 TX LED definitions DGHDP3 Version 1.0...

  • Page 28: Appendix 6 System Specifications

    1080P Powerline AV Sender System User Manual Appendix 6 System Specifications Video Specifications: Interface HDMI Resolution  1920 x 1080p/24, 23.98  1920 x 1080i/60, 59.94  1920 x 1080i/50  1280 x 720p/60, 59.94  1280 x 720p/50  720 x 576p/50 ...
