Summary of Contents for Smart 2 DSD158
- Page 1 TheSmartDVR.com JPEG2000 + H264 USER MANUAL Models covered DSD154 – 4 Channel DVR DSD158 – 8 Channel DVR Version 2.0...
- Page 2 Quality & Value The SmartDVR.com INSTALLATION & SAFEGUARDS INSTALLATION & SAFEGUARDS All the safety and operating instructions should be read before the unit is operated. Environment Condition for Installation To prevent electric shock or other hazard, do not expose this unit to rain, moisture or dust. This unit should be located in an area with low humidity and a low dust level.
-
Page 3: Table Of Contents
Quality & Value The SmartDVR.com --------------------------------------------- Chap.1 Features & Package Contents ------------------- --------------------------------------------- 1-1. Features ------------------- --------------------------------------------- 1-2. Package Contents ------------------- --------------------------------------------- Chap. 2 Function of Each Button ------------------- --------------------------------------------- 2-1. Front ------------------- --------------------------------------------- 2-2. Rear ------------------- --------------------------------------------- Chap. 3 Installation ------------------- ---------------------------------------------... - Page 4 Quality & Value The SmartDVR.com --------------------------------------------- Chap.5 Set Up ------------------- --------------------------------------------- 5-1. Entering the Menu ------------------- --------------------------------------------- 5-2. Display Setup ------------------- --------------------------------------------- Screen Display ------------------- --------------------------------------------- Monitor Setup ------------------- --------------------------------------------- 5-3. Configuration ------------------- --------------------------------------------- HDD Management ------------------- --------------------------------------------- Time/Date Setup ------------------- --------------------------------------------- Camera Setup...
-
Page 5: Chap.1 Features & Package Contents
Contents Quality & Value The SmartDVR.com CHAP. 1 Features & Package Contents 1-1. Features Live View Real time display per camera Auto Sequence PIP (Picture in picture) Event Popup Digital Zoom Display Freeze Simple Playback mode Simple PTZ camera control Record Variable Record resolution (For higher picture quality or higher recording speed) Efficient Image Quality setup in 5 steps... -
Page 6: Package Contents
CHAP. 1 Features & Package Quality & Value Contents The SmartDVR.com 1-2. Package Contents 1. DVR Main Unit 2. Remote Controller 3. Power Cable 6. Software CD 5. User’ s Manual 4. Power Adapter 7. Battery for remote 8. Bolts & Foam Mount washers 9. -
Page 7: Chap. 2 Function Of Each Button
CHAP. 2 Function of Each Button Quality & Value The SmartDVR.com 2-1 FRONT 9/20 11/21 15/18 2.1 / 2.2 14/17 16/19 Name Function 1. LEDs Shows status of operation 2.1 USB Used for backup via upper USB port 2.2 USB Used to upgrade Firmware only via lower USB port 3 IR IR receiver... - Page 8 Quality & Value The SmartDVR.com 8. SHIFT & Search recorded data on HDD PLAY 9. MENU Set up for SYSTEM MENU or Use to exit the menu PRESS MENU BUTTON BEFORE POWERING OFF UNIT 10. ENTER Selects each menu option 11.
-
Page 9: Rear
Quality & Value CHAP. 2 Function of Each Button The SmartDVR.com 2-2 REAR Name Functions Connection with PTZ Camera or other external device using RS 485 interface RS485 (Pin 1: D- / Pin 2: D+) RELAY Output Relay out terminal Pin 3 Common, Pin 4 NC, Pin 5 NO SENSOR Input Sensor input terminal Pin 8 –... -
Page 10: Chap.3 Installation
Quality & Value The SmartDVR.com CHAP.3 Installation 3-1. Installation Configuration... -
Page 11: Detailed Installation
CHAP. 3 Installation Quality & Value The SmartDVR.com 3-2. Detailed Installation Rack mount Remove 4 bolts on each side to install rack mount brackets Attach rack mount bracket Attach DVR brackets to 19” rack. Hard Drive fitting points I/O BOARD I/O BOARD MAIN MAIN BOARD... -
Page 12: Camera
CHAP. 3 Installation Quality & Value The SmartDVR.com 3) Camera Connect cameras to the camera input on rear panel of DVR marked CAMERA IN. 4) Monitor Connect the video output marked MONITOR to Video In of Main monitor. 5) Power Connect one 12V DC 6.67A adaptor to the DC12V input connector on rear of unit. -
Page 13: Spot, Video Printer
CHAP. 3 Installation Quality & Value The SmartDVR.com 6) SPOT, VIDEO PRINTER AUDI O V G A I N1 IN 2 I N 3 I N4 O UT ET HERNET R S-232 C C AMER A SPEAK ER M ON ITOR PAN/T ILT SIRE N CAMERA... -
Page 14: Chap.4 Operation
Quality & Value The SmartDVR.com CHAP.4 Operation 4-0. Starting up system Before turning on the DVR be sure that everything is firmly connected. Turn on the DVR and go the Menu using the relevant Login Password and you will then see the System Setup Screen. -
Page 15: Display Configuration
Quality & Value The SmartDVR.com 4-3. Display Configuration 4-4. Live View Setup 1) Full / Multiple View Switch to multi-screen displays by pressing [MODE]. For full image display, just press the channel button you want or keep pressing [MODE] button. When you playback images that are recorded in 360x240 (360x288) or 360x120 (360x144) resolution, only 1, 4 and 9 way split screens are available. -
Page 16: View In Sequence
Quality & Value The SmartDVR.com 2) View In Sequence Press [SEQ] button. It automatically displays full screen images in sequence. To stop the sequence press the [SEQ] button. CH08 Picture in Picture (PIP View) When it is in full screen display mode, you can see another camera in a small window by pressing [PIP]. -
Page 17: Record
Quality & Value The SmartDVR.com 4-5. Record The recording mode set before delivery by manufacturer (Default recording mode) is Schedule Recording. In this default recording mode, it records 24 hours/day continuously during weekdays and the weekend. If you press the [E-REC] button whilst you are in live view mode, the record type is changed to Emergency Record mode. -
Page 18: Search
Quality & Value The SmartDVR.com 4-7. Search Press [PLAY] & [SHIFT] buttons, and 3 different methods for searching recorded data are available as shown in following SEARCH window. For selecting searching method, use direction key or Jog Shuttle. After selecting each search method, press [ENTER] button for playback. To exit press [MENU]. 1) SEARCH BAR Search by percentage of total recorded data, using the arrow keys or the jog shuttle. -
Page 19: Data Back-Up
Quality & Value The SmartDVR.com Button PTZ command Button PTZ command 1/ON LIGHT ON 10/CLEAR PRESET CLEAR 2/OFF LIGHT OFF 11/GOTO PRESET GOTO 3/OPEN IRIS OPEN 12/AUTO AUTO SCAN 4/CLOSE IRIS CLOSE 13/F1 ~ 16/F4 FUNCTION 5/NEAR FOCUS NEAR UP BUTTON TILT UP 6/FAR FOCUS FAR... -
Page 20: Mouse Operation
Quality & Value The SmartDVR.com 4-11. Mouse Operation 1) Basic Operation There are 11 keys that work by Mouse. These include LEFT (3) Click once, double click & click hold RIGHT (3) Click once, double click & click hold WHEEL (5) Upper, lower, click once, double click & click hold 2) The Mouse cursor is not present The following are reasons why the mouse cursor may not be displayed Double clicking the LEFT button : The assigned channel is sequencing to FULL Screen... - Page 21 Quality & Value The SmartDVR.com 4) Working Status of LIVE MOUSE ICON To work command in LIVE MOUSE ICON, user clickS Left button once. In case ICON is divided, upper part of button : Mouse Left button click once Lower part of button : Mouse Right button click once Following is the assigned KEY by each ICON.
- Page 22 Quality & Value The SmartDVR.com Following is the assigned KEY by each ICON. ICON Left Click Right WHEEL ICON Left Click Right WHEEL Click Click STOP Step play SLOW BACKWARD BACKWARD FAST PLAY PLAYBACK BACKWARD SPEED FAST SLOW FORWARD FORWARD STOP PLAY Step play PAUSE...
- Page 23 Quality & Value The SmartDVR.com 7) Working Status of SPLIT MOUSE ICON. To change assigned screen division, click left button of mouse once. Please note that specific division cannot be supported such as QUAD record/playback. and according to DVR channel, screen division can be different. 8) Working Status of NUMBER MOUSE ICON.
-
Page 24: Chap.5 Set Up
Quality & Value The SmartDVR.com CHAP. 5 Set Up 5-1. Entering into the Menu Enter into SYSTEM MENU by pressing [MENU] button. BUTTON FUNCTION MENU Enter into SYSTEM MENU, Move to previous menu, ESC ENTER Selection key, Move to sub-menu, change status (ON or OFF) NEXT Move to next page Move Up... -
Page 25: Display Setup
Quality & Value The SmartDVR.com 5-2. DISPLAY SETUP Setting up parameters for monitor and display on screen. Enter into SYSTEM MENU-DISPLAY SETUP. 1) SCREEN DISPLAY Setting up the screen display in LIVE mode and PLAYBACK mode. Select the sub-menu, that you would like to set using direction buttons and [ENTER] then change ON/OFF with... -
Page 26: Configuration
Quality & Value The SmartDVR.com 5-3. CONFIGURATION Various system parameters can be set in the CONFIGURATION menu. Enter the SYSTEM MENU-CONFIGURATION and press the [ENTER] button. HDD SETUP HDD INFORMATION HDD CHANGE SETUP 1) HDD MANAGEMENT Enter SYSTEM MENU-CONFIGURATION-HDD MANAGEMENT and press the [ENTER] button. (1) HDD SETUP This page includes information about start and end of recording, location of recorded data, or location of last playback on HDD. - Page 27 Quality & Value The SmartDVR.com (3) HDD CHANGE SETUP Without losing data, user can use HDD from other DVRs, and HDD installed in current DVR can be used in other DVRs. HDD CHANGE SETUP HDD CHANGE SETUP SAVE DVR INFO SAVE DVR INFO LOAD DVR INFO LOAD DVR INFO...
-
Page 28: Time/Date Setup
Quality & Value The SmartDVR.com 2) TIME/DATE SETUP Set the time and date of the DVR system. It is very important for searching an event with time and date that this is accurately set. Note that the time and date set by manufacturer may be different from the local time and user must set the date and time before recordings start. - Page 29 Quality & Value The SmartDVR.com CAMERA ACTIVE SETUP CAMERA ACTIVE SETUP MOTION CONFIGURATION MOTION CONFIGURATION CHANNEL CHANNEL STATUS STATUS LIVE LIVE --------------------------------------------------------------------------- --------------------------------------------------------------------------- SENSITIVITY GRADE SENSITIVITY GRADE ACTIVE ACTIVE MOTION DISPLAY TYPE MOTION DISPLAY TYPE ACTIVE ACTIVE LOSS LOSS RECORD DURATION RECORD DURATION 05 SEC 05 SEC...
-
Page 30: Interval Setup
Quality & Value The SmartDVR.com 4) INTERVAL SETUP Set the switching time interval for SEQ or PIP SWITCHING INTERVAL function.(1sec. ~ 99 sec.) FULL SCREEN: set the sequencing switch time interval in live full screen. PIP SCREEN: set the sequencing switch time interval of PIP window. -
Page 31: Buzzer Setup
Quality & Value The SmartDVR.com 7)) BUZZER SETUP BUZZER SETUP BUZZER SETUP Set parameters for buzzer (On or Off). Use direction button and [ENTER] button. KEY BEEP KEY BEEP VIDEO LOSS VIDEO LOSS KEY BEEP: buzz when button is pressed. VIDEO LOSS: buzz when video signal is lost. -
Page 32: Record Setup
Quality & Value The SmartDVR.com 5-4. RECORD SETUP This is the most important configuration of the DVR. Enter SYSTEM MENU-RECORD SETUP and press the [ENTER] button. 1) RECORD CONFIGURATION Use direction button to move and [-] [+] button to set value. (1) OVERWRITE: Set overwrite or stop recording when the HDD is full. -
Page 33: Schedule Setup
Quality & Value The SmartDVR.com 2) SCHEDULE SETUP Unless you selected another recording mode, DVR system records in Schedule Recording mode. In SCHEDULE REC SETUP, you set type of recording for every time interval of 2 hours in each day of the week. -
Page 34: Back-Up
CHAP. 5 Set Up Quality & Value The SmartDVR.com 5-5. BACK-UP 1) CDR/DVDR SETUP User can back up the recorded data to CD or DVD using DVD writer installed in DVR. Refer to [START] and [END] of data on HDD and set copy from time, [START], and size of data copied, [SIZE], and move to BURN and press [ENTER] button to start copy. -
Page 35: External Device
Quality & Value The SmartDVR.com USB SETUP USB SETUP START 2005/AUG/07 AM04:04:12 START 2005/AUG/07 AM04:04:12 2005/AUG/08 PM08:12:23 2005/AUG/08 PM08:12:23 USB MEDIA START 2005/AUG/07 AM04:04:12 USB MEDIA 2005/AUG/08 PM08:12:23 START 2005/AUG/07 AM04:04:12 SIZE 00000MB 2005/AUG/08 PM08:12:23 SIZE 28 MB - > 28MB BACKUP BACKUP USB STORAGE IS CHECKING... - Page 36 Quality & Value The SmartDVR.com (2) DDNS SETUP : DDNS SETUP DDNS SETUP - DDNS ON/OFF : Select if DDNS Function use DDNS ON/OFF DDNS ON/OFF DDNS SERVER DDNS SERVER 211.062.253.087 211.062.253.087 - DDNS SERVERS : IP Address of DDNS SERVER. INTERVAL INTERVAL D-00 H-00 M-20...
- Page 37 Quality & Value The SmartDVR.com (5) EVENT SERVER SETUP : IP ADDRESS : IP Address of PC that executes EVENT SERVER SETUP EVENT SERVER SETUP EVENT SERVER PROGRAM. IP PORT : PORT of PC that executes IP ADDRESS IP ADDRESS 192.168.001.072 192.168.001.072 EVENT SERVER PROGRAM...
-
Page 38: Rs-232C Setup
Quality & Value The SmartDVR.com 2) RS-232C SETUP User can control the DVR via RS-232C port. Connect DVR to PC via RS-232C port and user can control DVR using keyboard of PC. This function is mainly for programmer who wants to control DVR as part of many devices connected to a PC system. - Page 39 Quality & Value The SmartDVR.com [SPEED SETUP] Allows the defining of operational speeds for PTZ controls. It may be helpful to reduce these settings when operating the DVR over a network, to reduce “ over shoot” because of network delay. Important Note: To operate PTZ controls always ensure the PTZ channel is set to full screen.
-
Page 40: Spot Monitor Setup
Quality & Value The SmartDVR.com Move mouse over icon and using wheel select preset number you wish to programme. Press icon to save preset – “ SET PRESET” will flash momentarily confirming save. Calling PTZ presets using mouse Move mouse over icon and using wheel change the top left hand menu bar to Press button on mouse menu to select Preset number... -
Page 41: Audio Setup
Quality & Value The SmartDVR.com 1) REC a) ON: Record with AUDIO b) OFF: Record without AUDIO 2) PLAY a) ON: Audio on playback b) OFF: No Audio on playback 6) AUDIO VOLUME SETUP AUDIO VOLUME SETUP AUDIO VOLUME SETUP INPUT VOLUME INPUT VOLUME INPUT VOLUME: Adjust VOLUME of... -
Page 42: Language Setup
Quality & Value The SmartDVR.com 5-8. LANGUAGE SETUP The menu can be displayed in a number of languages. Press [ENTER] button to select language. -
Page 43: Chap. 6 Network Setup
Quality & Value The SmartDVR.com CHAP. 6 Network Setup 6-1. DVR Network Configuration Please call your Internet provider to identify what type of service they are providing for you. You will need to know the following; Upload speed – For your own knowledge for expected frame rates Download speed –... - Page 44 Quality & Value The SmartDVR.com 1) Static I.P Address from an Internet Service Provider Configure the DVR to operate with a modem router. Configure the DVR as follows: a. It is assumed you have a PC working on Broadband Internet. b.
- Page 45 Quality & Value The SmartDVR.com Dynamic IP Address from an Internet Service Provider Customers using a dynamic I.P address on their Broadband connection are advised to source a modem/router supporting “ Dynamic DNS” within its firmware and to refer to the instructions provided with that router in order to configure that service.
-
Page 46: Chap. 7 Irs (Integrated Remote Station)
Quality & Value The SmartDVR.com CHAP 7. IRS (Integrated Remote Station) MAIN INTERFACE IRS SETUP Inputs Information for IRS network connection. DVR SETUP Changes DVR setting over a network. VIEWER Enables to show live image display. BACKUP Enables to back up recorded images in DVR to your PC. PLAYER Enables to back up recorded images on your PC. - Page 47 Quality & Value The SmartDVR.com 7-1. IRS SETUP MANUAL Select “ Manual” to input IP address and port number manually. DDNS Select “ DDNS” to use IP address and port number that you already registered in DDNS Server. MEMBER ID Input member ID that you registered in DDNS Server.
- Page 48 Quality & Value The SmartDVR.com 7-2. DVR SETUP User can change some settings of DVR listed below over a network. (Active Camera, Alarm, Buzzer, Interval, Password, Record Configuration, Record Schedule) MANUAL Input IP address and port number of DVR manually. ADDRESS Input IP address of DVR manually.
- Page 49 Quality & Value The SmartDVR.com 7-3. VIEWER 1. DVR connection setup : Input network information to connect. (IP / PORT / ID / PW) 2. Network Connection a) CONNECT : Click this button to connect to DVR & see live view over a network. b) DISCONNECT : Click this button to disconnect.
- Page 50 Quality & Value The SmartDVR.com 7-4. BACKUP 1) To execute BACKUP, input IP Address & Port and click ‘ Connect Test’ button. 2) After Connect Test is done, you can see ‘ Success Connect Test!’ message. Then,click ‘ lock’ button and click ‘...
- Page 51 Quality & Value The SmartDVR.com 3) Now you set ‘ Start Time’ , ‘ End Time’ , ‘ Save File Path’ , ‘ File Size’ and click ‘ Apply’ . 4) After finishing time setting, click ‘ Start Backup’ to start backup. Then, you can see the backup on the path that you chose.
- Page 52 Quality & Value The SmartDVR.com 7-5. PLAYER 1. Time Display : Displays current time. 2. Recorded data display : Displays start time & end time of recorded data. Also, displays operating status during playback. 3. Screen display : Selects full screen mode or split mode and displays full screen for each ch. 4.
- Page 53 Quality & Value The SmartDVR.com Image EDIT 1. EDIT TOOL : User can adjust color tone of copied images using these buttons. - Contrast : make bright part of image brighter and dark part of image darker : To reduce light and shade, lower contrast a little - Brightness : make an image brighter : make an image darker...
- Page 54 Quality & Value The SmartDVR.com AVI SAVE 1. OPTION : Used to save data in AVI file format. - CHANNEL : Selects channel. - FRAMERATE : Decides frames per second of data to be saved. - SIZE : Decides the size of data to be saved automatically. - START : Starts saving.
- Page 55 Quality & Value The SmartDVR.com 7-6. TRANSMITTER 1. DVR Connection Setting : Inputs information for DVR Network connection . Check ‘ IP / PORT / ID / PW’ information. 2. Network Connection a) CONNECT : Network connection to DVR. ( User can see live image of DVR. ) b) DISCONNECT : Network disconnection from DVR.
- Page 56 Quality & Value The SmartDVR.com SETUP (NVS Setup) Bitrate(Kb/s) DATA SIZE from NVS. The bigger it set, the better its quality. But sometimes image is not smooth. (Set Value : 100Kb ~ 2500Kb, can be adjusted by 50K) Image (I frame, P frame) from NVS. The bigger it set, the better its quality. Frame Rate DATA RATE from NVS.
- Page 57 Quality & Value The SmartDVR.com 7-7. CLIENT 1. Power button : Press the Power switch to exit the program. Please disconnect the live feed before powering off the software 2. Status window : Display’ s the current time and date based. The date is in the format : Year/Month/Day.
- Page 58 Quality & Value The SmartDVR.com IP/PORT Setting Screen MANUAL Input IP address and PORT manually DDNS Receive IP address and PORT from DDNS Server. For further information of DDNS, please contact your vendor. Name Name of IP address on the list. Address Input IP address which is set on DVR PORT...
- Page 59 Quality & Value The SmartDVR.com PTZ/SAVE Setting Screen Circular Monitoring Interval : This indicates the speed of the channels sequence when the SEQUENCE button is used from the main interface. Scan Rate : Set speed of playback. PTZ TYPE : Select PTZ camera which is connected to DVR. PTZ Baud Rate : Enter the Baud Rate of your PTZ camera.
- Page 60 Quality & Value The SmartDVR.com 7-7 CMS CMS Setting : CMS Setting. (User can set DVR Registration here for multi-access.) Group Setup : Among multi-access DVRs, User can set a group of specific channels for live monitoring. Search : Playback and search recorded image of one DVR. View Tree : If No11 is not displayed,it will be displayed again.
- Page 61 Quality & Value The SmartDVR.com DVR Registration and Screen Display 1) To connect DVR, from main screen select ‘ CMS Setting > Site setup > ‘ Registering Site’ , and then, register necessary information for DVR connection as below. (Registration is the same as ‘ IRS SETUP’ .) 2) After registration, user can display specific channel or select whole site by dragging Mouse as below.
- Page 62 Quality & Value The SmartDVR.com DVR Group Setup 1) After finishing DVR registration, click ‘ Group Setup’ in Main Screen. 2) Click ‘ Add Group’ and input group name. Drag camera channel user wants as shown below, and set channel displays in Group and click ‘ Save Array’ to setup group.
-
Page 63: Programmer Reference
Quality & Value The SmartDVR.com 1 2 3 4 7. Programmer reference 6 7 8 9 Connector Pin Assignment RS-232C Description Description Data Carrier Detect Data Set Ready Receive Data RS232C:Rx/Tx data Transmit Data RS232C:Rx/Tx data Data Terminal Data Signal Ground RS232 ASCII-CODE The information regarding ASCII codes for programmers is only supplied as reference material and is not supported. - Page 64 Quality & Value The SmartDVR.com Key Release for PTZ function power on , light on “ 1” power off , light off “ 2” iris open “ 3” iris close “ 4” focus near “ 5” focus far “ 6” zoom in “...
-
Page 65: Chap. 9 Specifications
Quality & Value The SmartDVR.com CHAP. 7 Specifications CHAP. 9 Specifications • The best picture quality in Playback (JPEG-2000) • Real time live display on all channels • 8 channel video 240(200) ips recording capability • Triplex (Recording/Playback/Ethernet) • Multi-language menu •... -
Page 66: Chap10 Hand Remote Controls
Quality & Value The SmartDVR.com 1. NORMAL Type CHAP. 10 Remocon Key Definition M enu /E xit Me nu MENU S cre en D ivision / Cha ng e M ode MODE Free ze S EQ ZOOM ZO O M P IP (P icture in P icture ) P TZ S low B ackw a rd P layba ck... - Page 67 Quality & Value The SmartDVR.com 2. SINGLE Type CHAP. 10 Remocon Key Definition PTZ On/Off SEARCH Search Menu PTZ CONTROL Menu MENU SET PRESET CLEAR CLEAR PRESET GOTO GOTO PRESET OSD DISPLAY On/Off AUTO AUTO PAN 4-SPLIT 9-SPLIT 16-SPLIT 1 ~ 9 Select Ch / Input Number Indicates 2 digits ‘...
-
Page 68: Appendix Channel Record Timetable
Quality & Value The SmartDVR.com 4 Channel Record time table. HDD Capacity Basic Normal Enhanced Fine Super Fine (GB) 33 Hr 25 Hr 19 Hr 16 Hr 15 Hr 67 Hr 49 Hr 39 Hr 32 Hr 29 Hr 104 Hr 77 Hr 61 Hr 50 Hr...
