Page 1: User Guide
Multifunctional Food Processor User guide Model No: AMFP4001 For Customer Services & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com IMPORTANT: RETAIN FOR FUTURE REFERENCE... -
Page 2: Table Of Contents
Connection to the mains supply ……………………………………… Thank you for purchasing your Abode Food Processor To get the best from your new food processor, take a few moments to read these instructions, and keep them in a safe place for future reference. -
Page 3: Safety Instructions
Safety instructions IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • When using electrical appliances, basic safety precautions should always be observed, including the following: • Read all instructions. • Avoid contact with moving parts. • To protect against electrical shock do not immerse cord, plug, or appliance in water or other liquid. - Page 4 Safety instructions WARNING: • Never remove parts from the appliance such as screws. • Never operate the Food Processor when the bowl is empty and do not remove the bowl lid before the blades come to a complete stop. • Do not touch the cutting blades or insert any object, such as knives, forks, spoons, etc.
-
Page 5: Food Processor Feature Diagram
Food processor feature diagram Food processor bowl with lid Blending cap Unit base Blender jug with lid Base feet Blender jug handle Speed control dial Double sided slicing/grating disc Food pusher Drive shaft Feeding chute Mixing blade Processor handle Chopping blade... -
Page 6: Preparing Your Food Processor
Preparing your food processor Before using your food processor Check the appliance after unpacking for any visual damage or missing parts such as: • Misaligned or damaged casing. • Damage to the plug or cable. • If any parts are missing or there is any damage, please refer to page 16 for Customer Services. -
Page 7: Using Your Food Processor
Using your food processor Assembly/Disassembly Always unplug the food processor before attaching/removing parts Food processor bowl Lock Holding the base secure with one hand, use the other hand to unlock the bowl by rotating the handle clockwise to the unlock position. This is indicated by the unlock symbol. - Page 8 Using your food processor Double sided slicing/grating disc Remove Insert When the food processor bowl is on the base and the lid is removed, you can remove the slicing/grating disc from the top of the drive shaft by lifting the plastic blade connector. To reattach the disc, place the blade connector onto the top of the drive shaft and lower.
- Page 9 Using your food processor To lock the jug, place it onto the drive cog in the unlock position, secure the base with one Lock hand, and rotate the handle anticlockwise to the lock position to secure. This is indicated by the lock symbol.
- Page 10 Using your food processor Attachment guide for use Tool/Attachment Function Recommended Maximum Speed Capacity Chopping blade Chopping e.g. 300g meat meat Mixing blade Mixing e.g. dough 400g flour + 240g water Double sided disk Slicing/grating 1 litre mark Jug with blade Blending e.g.
- Page 11 Using your food processor Speed control dial • 0 – Off • 1 – Moderate speed • 2 – High speed • ‘P’ – Pulse, can be used for momentary power to the food processor. Select your desired speed setting using the speed control dial. Turn clockwise for 1 or 2, or anticlockwise for momentary pulse control.
- Page 12 Using your food processor Empty the food carefully onto a clean area, such as a chopping board or a bowl. You can use your hands or a long plastic/wooden spoon to scoop out the contents if necessary. Clean the bowl as per the cleaning and care instructions in this manual. To use the blender jug, detach the drive shaft and bowl according to instructions on page 7.
- Page 13 Using your food processor When the food has successfully processed, turn the speed control dial to the ‘0’ position. Pour the liquid carefully into a clean container. If the liquid is very thick, you can remove the lid and use a long plastic/wooden spoon to scoop out the contents if necessary.
-
Page 14: Cleaning And Care
Cleaning and care Before cleaning, turn the speed control dial to ‘0’, make sure to switch the power off at the plug socket, and remove the plug. Clean your food processor After using the food processor you should clean the removable food processor bowl and plastic accessories in warm soapy water, with a soft cloth or sponge. -
Page 15: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 16: Customer Services
Customer services Attach your receipt to this page for proof of purchase. We’re here should you need us For Customer Services & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com Produced for: WM Morrisons,... -
Page 17: Spare Parts
Spare parts The following spare parts are available to purchase online or by calling Product Care. Visit us at www.productcareuk.com Or call 0345 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Food processor Double sided Blender jug bowl with lid... -
Page 18: Connection To The Mains Supply
Connection to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of 220-240V ~ 50/60Hz. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 5A plug complying with BS1363. If this plug is unsuitable or needs to be replaced, please note the following: Important: The wires in the mains lead are coloured in accordance with the following code:... - Page 19 Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which...
- Page 20 Model number: AMFP4001 Technical Specifications: Wattage: 500W Rated Voltage: 220-240V ~ 50/60Hz Capacity: 1.5 litre blender jug, 1 litre food processor bowl...
