GSM Gateway 252236
User Manual
Art. No. 162236M V3.21D 2016-02-18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 252236 and is the answer not in the manual?

Questions and answers

Summary of Contents for FältCom 252236

  • Page 1 GSM Gateway 252236 User Manual Art. No. 162236M V3.21D 2016-02-18...

  • Page 2: Table Of Contents

    Table of contents Installation ..........................5 PIN code ........................5 1.1.1 PIN code deactivated ..................5 1.1.2 PIN code activated ..................5 Startup 5 Turn off the GSM Gateway .................... 5 Change SIM card ......................5 Front panel connectors and indications ................6 Back panel connectors and indications ................
  • Page 3 Declaration of Conformity We, Fält Communications AB, Vasagatan 23, SE-903 29 Umeå, Sweden. Hereby declare that this product, Fältcom GSM Gateway 202236, conforms with the following directives: R&TTE 1999/5/EC, EMC 2004/108/EC, LVD 2006/95/EC, RoHS 2002/95/EG and WEEE 2002/96/EG. The product complies with the following standards/norms: EN 55022(2006) and A1(2007), EN 55024(1998) and A1(2001) and A2(2003), EN 60950(2006) and ETSI EN-301 511 Umeå, Sweden, January 2013...
  • Page 4 SIM PIN code Activated or deactivated PIN code ACTIVATED DEACTIVATED Set PIN Turn of code to: PIN code 1234 lock CONNECTIONS Insert the SIM card, connect the Antenna, the lift phone Fältcom ECII Flex and Power 230 VAC Power Supply 12-24 VDC ANTENNA …...

  • Page 5: Installation

    1. Installation Find a suitable place where to mount the GSM gateway following these guide lines: • Make sure the GSM coverage is good before the GSM gateway is mounted. Place the Gateway near a window if possible. • Make sure the LEDs on both sides are visible. •...

  • Page 6: Front Panel Connectors And Indications

    2. Front panel connectors and indications PHONE USB 2.0 Mini connector to be used for connection with a PC. The USB can be used for updating the software of the GSM Gateway and also for adjusting parameters, such as battery tripping limits. For more information please see section 5.3 “...

  • Page 7: Back Panel Connectors And Indications

    3. Back panel connectors and indications 12V DC SMA Connector for the antenna Input of the SIM card Status for the GSM connection when the GSM Gateway is up and running (Green LED): Indicates Faulty GSM unit 800 ms ON / 800 ms OFF No service, No connection with GSM network or SIM-card missing.

  • Page 8: Battery

    4. Battery The battery is supervised in two different ways. The first “low battery voltage indication” is activated when the battery voltage is too low for any reason. The second is a “battery fault alarm” activated when the battery capacity is too low and it is time to replace the battery. In case there is a battery alarm/low battery voltage indication, the GSM Gateway will change the dial tone;...

  • Page 9: Sms Functionality

    5. SMS functionality Note: The symbol means new line. 5.1 Low battery voltage indication It is possible to generate an SMS when a Low battery voltage indication occurs; the functionality is activated by sending an SMS to the GSM Gateway. The SMS must include the telephone number and an alarm text.
  • Page 10 It is possible to generate an SMS (Bares) when the battery voltage gets above the set voltage level. This function is activated by sending an SMS to the GSM Gateway. The SMS must include and appropriate text. The SMS is not case sensitive. Bares SMS is always sent to the same number as Balarm.

  • Page 11: Dial Tone Battery Alarm - Dial Tone 2

    5.2 Dial tone battery alarm - Dial tone 2 The Dial tone battery alarm to the lift phone, indicating a battery fault alarm, is default activated but can be turned off. In case the function is deactivated the GSM Gateway will always use normal dial tone when the line is taken off-hook.

  • Page 12: Status

    5.3 Status Get current status of the Gateway by sending a “Status” SMS. The SMS must contain the SMS Access code followed by a new line and the word Status. The default Access code is 1111 and can be changed using the Fältcom Manager SW. If the access code or the request command (Status) is incorrect, the GSM Gateway will answer “Request command not supported”.

  • Page 13: Reset

    5.4 Reset Reset the Gateway sending a “Reset” SMS. The SMS must contain the SMS Access code followed by a new line and the word Reset. The default Access code is 1111 and can be changed using the Fältcom Manager SW. If the Gateway receives a correct request, the Gateway will restart.
  • Page 14 SMS to GSM Gateway: 1111 Gain GSM->POTS: x POTS->GSM: y The SMS can contain either one or both GSM and POTS settings. If the Gateway receives a correct request, the Gateway will answer the the new Gain settings: SMS acknowledgement from GSM Gateway: SN:V12345 Gain GSM->POTS: x...

  • Page 15: Upgrade Tool

    Upgrade Tool The USB interface is used to configure user specific parameters and to upgrade the GSM Gateway firmware. The upgrade requires the Windows program “Fältcom Manager” and is available from Fältcom or your local distributor. Use a standard USB – mini USB cable to connect the GSM Gateway to the PC.

  • Page 16: Firmware Upgrade

    6.1 Firmware upgrade To upgrade the GSM Gateway Firmware select the “FW update” tab. Click on “Select file” Browse to find and select the new FW file supplied by Fältcom or your local distributor. Note: The FW file always has the file extension .bin (e.g. gatewayFW.bin). Click on “Update”.

  • Page 17: Led Control On Signal Strength

    6.2.1 LED control on signal strength There are two LED’s showing the strength of the GSM signal; S1 and S2. You can set the limits when the LED should be lit. 6.2.2 Battery control The GSM Gateway can be used with or without battery backup. The default setting is battery Mounted and Battery fault alarm enabled.

  • Page 18: Gsm Sms Access Code

    6.2.4 GSM SMS Access code Change the SMS Access code. The SMS Access code is used as an authorisation code for the Gateway to send SMS to the user. If the Access code in the SMS sent to the Gateway is incorrect, the Gateway will not answer the SMS.

  • Page 19: Technical Data

    Setting the GSM Gateway to generate the Dial tone battery alarm, indicating a battery failure. When a battery failure occurs the Gateway will send a congested tone instead of the normal continuous dial tone. The Dial tone battery alarm is 1000ms ON / 250ms OFF / 250ms ON / 250ms OFF. To configure this setting set: “Dial/Congestion tone, battery fault”...

  • Page 20: Repair Return Procedure

    8. Repair return procedure Fält Communications AB only accepts returns that have a valid a RMA number. Please contact Fält Communications AB support to receive a RMA number. Repaired products are sent back to customers as a regular post parcel with freight paid on the assumption that the product is covered by warranty.
