V2/0910
AL 5
700.605
Bedienungsanleitung
Schnellkühler / Schockfroster
Instruction manual
Blast chiller/Shock freezer
Refroidisseur - surgélateur rapide
de page 51 à page 73
Bedieningshandleiding
Snelkoeler-snelvriezer
Instrukcja obsługi
Schładzarko-zamrażarka szokowa
Seite 3 bis 25
from page 27 to 49
Mode d'emploi
blz. 75 t/m 97
strony od 99 do 121
D/A/CH
GB/UK
F/B/CH
NL/B
PL
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AL-5 700.605 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bartscher AL-5 700.605

Summary of Contents for Bartscher AL-5 700.605

  • Page 1 AL 5 700.605 Bedienungsanleitung Schnellkühler / Schockfroster D/A/CH Seite 3 bis 25 Instruction manual Blast chiller/Shock freezer GB/UK from page 27 to 49 Mode d’emploi Refroidisseur - surgélateur rapide F/B/CH de page 51 à page 73 Bedieningshandleiding NL/B Snelkoeler-snelvriezer blz. 75 t/m 97 Instrukcja obsługi Schładzarko-zamrażarka szokowa strony od 99 do 121...

  • Page 2: Table Of Contents

    35-46 6. Cleaning and maintenance 6.1 Safety advice 6.2 Cleaning 6.3 Safety instructions for maintenance 7. Possible Malfunctions 8. Waste disposal Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax: +49 (0) 5258 971-120 - 27 -...

  • Page 3: General Information

    1. General information 1.1 Information about the instruction manual This instruction manual contains information about the installation, operation and maintenance of the device and should be consulted as an important source of information and reference guide. Awareness of the safety instructions and instructions for use in this manual will ensure the safe and correct use of the device.

  • Page 4: Liability And Warrantees

    1.3 Liability and Warrantees All the information and instructions in this manual take into account standard safety regulations, current levels of technical engineering as well as the expertise and experience we have developed over the years. The instruction manual was translated with all due care and attention. However, we do not accept liability for any translation errors.

  • Page 5: Safety

    2. Safety This section provides an overview of all important safety aspects. In addition every chapter provides precise safety advice for the prevention of dangers which are highlighted by the use of the above mentioned symbols. Furthermore, attention should be paid to all pictograms, markers and labels on the device, which must be kept in a permanent state of legibility.

  • Page 6: Intended Use

    CAUTION! The device is not intended for use by individuals (including children) with physical or mental disabilities, insufficient experience, and/or insufficient knowledge unless such persons are under the care of a person responsible for their safety or have received instructions regarding appropriate use of the device. Children should be observed to ensure that they are not playing with the device.

  • Page 7: Delivery, Packaging And Storage

    3. Transport, packaging and storage 3.1 Delivery check Please check the delivery upon completeness and transport damage immediately after receipt. In case of visible damage do not accept or accept the delivery with reservation only. Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint. Hidden damages should be reclaimed immediately after notice, as claims for damages can only be asserted within the effective period for complaints.

  • Page 8: Technical Data

    4. Technical data Name Blast chiller/Shock freezer AL 5 700.605 Article no.: Construction: CNS 18/10 in accordance with HACCP directive Coolant: R404a Rapid cooling cycle: +70° C to +3° C Flash freeze: +70° C to -18° C Usable volume: 5 x 1/1 GN or 5 x 600x400 mm Capacity: Cooling: 16 kg;...

  • Page 9: Installation And Connection

    WARNING! Hazard via electrical current! The device can cause injuries due to improper installation! Before installation the local power grid specification should be compared with that of the device (see type label). Connect the device only in case of compliance! Take note of the security advice! 5.2 Installation and connection CAUTION! The installation and maintenance of the appliance should only be carried out by...

  • Page 10: Operating

    5.3 Operating Control panel Functions START (ON-/OFF) Cooling with time regulation Cooling with temperature regulation via probe for measuring internal product temperature Freezing with time regulation Freezing with temperature regulation via probe for measuring internal product temperature Defrost Raise Lower - 35 -...
  • Page 11 Notifications appearing on digital display FREEZING This indicator flashes when the freezing cycle is taking place, and lights up during the product conservation phase COOLING This indicator flashes when the cooling cycle is taking place, and lights up during the product conservation phase CONSERVATION This indicator lights up or flashes during the conservation phase TEMPERATURE...
  • Page 12 Regulation „SOFT“ rapid cooling with temperature regulation via probe for measuring internal product temperature 1. Insert the probe into the food product. CAUTION! Insert the internal product temperature probe into the food product to a maximum depth of 2 – 3 cm. 2.
  • Page 13 It is also possible to display the elapsed cooling time by pressing the button „cooling with time regulation” . The elapsed time will be displayed for 5 seconds in green. If you wish to remove the food product from the refrigerator-flash freezer, press the START button to suspend the rapid cooling cycle.
  • Page 14 Confirm the value via the „cooling with temperature regulation via probe for measuring internal product temperature” button 3. Activate the cycle by pressing the START button 4. The rapid cooling cycle is finished when the internal product temperature reaches +3° . 5.
  • Page 15 „SOFT“ rapid cooling with time regulation 1. Insert the probe into the food product. CAUTION! Insert the internal product temperature probe into the food product to a maximum depth of 2 – 3 cm. Hold the button „cooling with time regulation” .
  • Page 16 It is also possible to display the elapsed cooling time by pressing the button „cooling with time regulation” . The elapsed time will be displayed for 5 seconds in green. If you wish to remove the food product from the refrigerator-flash freezer, press the START button to suspend the rapid cooling cycle.
  • Page 17 Confirm the value via the „cooling with time regulation” button 3. Set the desired cooling time using the buttons and confirm using the button „cooling with time regulation” 4. Activate the cycle by pressing the START button 5. The rapid cooling cycle is finished when the time set for rapid cooling has lapsed. 6.
  • Page 18 Rapid freezing with temperature regulation via probe for measuring internal product temperature 1. Insert the probe into the food product. CAUTION! Insert the internal product temperature probe into the food product to a maximum depth of 2 – 3 cm. 2.
  • Page 19 The refrigerator-flash freezer is prepared for a new rapid cooling cycle. To begin the next cooling cycle, press and hold for 3 seconds one of the following buttons Rapid freezing with time regulation 1. Insert the probe into the food product. CAUTION! Insert the internal product temperature probe into the food product to a maximum depth of 2 –...
  • Page 20 If you wish to remove the food product from the refrigerator-flash freezer, press the START button to suspend the rapid freezing cycle. To place the unit in STANDBY mode, press and hold for 3 seconds one of the following buttons The internal unit temperature will be displayed in green.
  • Page 21 Do not overfill the unit (cooling: 16 kg, freezing: 12 kg); Leave an appropriate amount of space between containers in order to ensure the best possible circulation; Never place hot containers directly on the bottom of the unit – they should rest on special grates.

  • Page 22: Cleaning And Maintenance

    6. Cleaning and maintenance 6.1 Safety advice o Before beginning with repair or cleaning works make sure the device has been disconnected from power socket (pull the power plug!!!) and has cooled down. o Do not use any acid agents and make sure no water ingresses the device. o To protect yourself from electric shock, never immerse the device, its cables and the plug in water or other liquids.

  • Page 23: Possible Malfunctions

    7. Possible Malfunctions Error messages on the digital display Error Description of error Recommendation message Improper connection inside the unit – Er 1 probe for internal product temperature Contact service centre measurement Improper connection of probe for Er 2 internal product temperature Contact service centre measurement Er 3...

  • Page 24: Waste Disposal

    NOTE! For the disposal of the device please consider and act according to the national and local rules and regulations. Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax:...
