Summary of Contents for Lindell Audio 77X-500
- Page 1 LINDELL AUDI Ω WWW.LINDELLAUDIO.SE 77X-500 USER MANUAL 500 Series Stereo FET Compressor/Limiter with Stepped Controls, Built-in Highpass Sidechain Filter, Attack and Release Knobs, Link Mode, and True Bypass WWW.LINDELLAUDIO.SE 2015-05-02 Rev.1...
- Page 2 Normally, that's when you give a profound sigh, zero out your compressor, and start over from scratch. The 77X-500 compressor saves you that frustration with its mix control, allowing you to beef up your compression and the blend in the dry signal to bring back some of the original dynamics.
- Page 3 LINDELL AUDI Ω WWW.LINDELLAUDIO.SE How to Install the module into a power chassi: 1) Power OFF the power chassi 2) Unpack the module and make sure nothing surrounds the card edge connector 3) Carefully slide the module into an empty slot in your power chassi 4) Make sure the module connectors sits well into the mating Edac chassi connector 5) Power ON the power chassi 6) Rock’n’Roll...
- Page 4 LINDELL AUDI Ω WWW.LINDELLAUDIO.SE SPECS: Power Requirements: CARD EDGE PIN OUT +/- 16V Attack Time: CHASSIS GROUND 20 microseconds to 800 microseconds 2* OUTPUT + (XLR PIN 2) Release Time: 4* OUTPUT - (XLR PIN 3) 50 milliseconds to 1.1 seconds COMMON Input Impedance: 25kohm...
- Page 5 WARRANTY * Lindell Audio warrants all of our products to be free from defective parts and workmanship for a period of one year. * The warranty period begins at the original purchase date and is transferable within the period of warranty.
