Summary of Contents for IAG IDF6SE3
- Page 1 Freestanding Dishwasher IDF6SE3/IDF6WE3...
-
Page 2: Table Of Contents
Dear Customer, Please read this User Information carefully and keep it to refer to at a later date. Pass it on to any subsequent owner of the appliance. Control Panel............2 Dishwash er Features...........2 This manual contains sections of Safety Instructions, Operatin g Instructions, Installation Instructions and Troubleshooting Tips etc. - Page 3 Under certain conditions, Hydrogen gas may be produced in a hot-water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE.If the hot-water system has not been used for such a period, before using the dishwasher turn on all hot-water taps and let the w ater flow from each for several minutes. This will release any accumulated hydrogen gas.
-
Page 4: Rinse Aid
To get the best performance from your dishwasher,read all operating instructions before using it for the first time. 1 ON/OFF button: To turn On/Off the power supply. 7 Program Button : To select washing program when press the button. 2 Power Light : Illuminates when the ON/OFF Button is 8 Program indicator light: when you select washing program,... - Page 5 Before usi ng your dishwasher for the first time: A. Fill the rinse aid dispenser B. Function of detergent Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, spot and streak free drying. Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances (e.g.
-
Page 6: Concentrated Detergent
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and heavily deposited food particles from the dishwasher. Most commercially available detergents are suitable for this purpose. Concentrated Detergent Based on their chemical composition, detergents can be split in two basic types: conventional, alkaline detergents wi th caustic components low alkaline concentrated detergents with natural enzymes The use of “heavy”... -
Page 7: Detergent
Filling detergent dispenser Fill the detergent dispenser with detergent.recommended for automatic dishwashers only. The marki ng indicates the dosing levels , as Illustrated on right: The area where the detergent is placed fo r main wash cycle, “MIN”means approximately 20g of detergen. The area where the detergent is placed fo r pre-wash cycle, approximately 5g of detergent Please observe the manufacturers dosing and storage... -
Page 8: Loading The Upper Rack
For best performance of the dishwasher, follow these loading guidelines. Features and appearance of racks and cutlery baskets may vary from your model. Attention before or after Loading the Dishwasher Racks Scrape off any large amounts of leftover food. It is not necessary to rinse the dishes under running water. - Page 9 ***NOTE***: The upper rack has side flaps (pictured at left Above basket). There are 4 (2 on each side). These can be Adjusted into 2 positions = position 1 (high) and position 2 (low). To move the flaps between these positions, locate the large hinges clip each flap to the upper rack.
-
Page 10: Cutlery Basket
Cutlery Basket Cutlery should be placed in the cutlery basket with handles at the bottom: If the rack has side baskets, the spoon should be loaded individually into the appropriate slots, especially long utensils should be placed in the horizontal position at the front of the upper rack. -
Page 11: At The End Of The Wash Cycle
shes and items of cutlery must not lie inside one another, or cover each othe r avoid damage to glasses, they must not touch Load large items which are most difficult to clean into the lower rack he upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups Attention! Long bladed knives stored in an upri ght position are a potential hazard! - Page 12 For the heaviest soiled loads, -wash(45℃ such as pots,pans,casserol e Wash (50 ℃) Intensive 5/25g. dishes and dishes that have 1.55 17.7 Rinse (70 ℃) been sitting with dried food Drying on them for a while. Pre-wash For heavy soiled loads, Pre-wash such as pots...
-
Page 13: Turning On The Appliance
Turning on the Appliance Starting a wash cycle... Pull out the lower and upper basket, load the dishes and push them back. It is commended that loading the lower basket first, than the upper one (see the section entitled “Loading the Dishwasher”). Pour in the detergent (see the section entitled “Detergent and Rinse Aid”). - Page 14 Extreme care should be taken if opening door during wash cycle as hot water may scald. At the End of the Wash Cycle When the washing cycle has finished, the buzzer of dishw asher will sound for eight seconds, then stop.Turn off the appliance using the ON/OFF button,open the door of the dishwasher. Wait a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they are still hot and more susceptible to breakage.
-
Page 15: Cleaning The Spray Arms
Step１：turn the filter cylinder counter-clockwise, then lift it up Step２：lift the Main filter up Step 3： lift the Fine filter up NOTE： If do it from step1 to step 3, the filter system will be removed; while if do it from step3 to step 1, the filter system will be installed. - Page 16 To clean the edge around the door, you should use only a soft cloth and warm soapy water. To prevent penetration of water into the door lock and electrical components, do not use a spray cleaner of any kind. Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will scratch the finish.
- Page 17 Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded. Do not modify the plug provided with the appliance; If it is not fit for the outlet. Have a proper outlet installed by a qualified electrician.
-
Page 18: Water Outlet
Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned to the right or the left to facilitate proper installation. -
Page 19: Starting The Dishwasher For The First Time
Aquasafe The Aquasafe System is a safety valve system, preventing you from water leaks. If the water inlet hose starts to leak during a wash cycle, the safety valve cuts off the running water. Do not immerse the water inlet hose or the safety valve in water, because the electrical cable for the safety valve is in the double-walled water inlet hose. -
Page 20: Before Calling For Service
Before Calling for Service Review the charts on the following pages may make you be free of calling for service. Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker tripped appliances sharing the same circuit with the dishwasher Make sure the dishwasher is turned on and the door is Power supply is not turned on... - Page 21 Combination of soft Use less detergent if you have soft water and select a water and too much shortest cycle to wash the glassware and to get them clean. detergent Tea or coffee stains Using a solution of 1/2 cup of bleach and 3 cups warm water to remove the stains by hand.
- Page 22 Height : Min:850mm Max:900mm Width : 600mm Depth : 580mm Voltage connected Load : 240 volts Water pressure: 0.04-1.0MPa Hot water connection : max 60 ℃ Power supply: 240V/50Hz Capacity: 12 Place settings...
