Surefine SF-LED16-80 Installation Instructions

Quality You can
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precau ons should always
be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. To avoid the possibility of electrical shock, turn off power supply before
installa on or servicing. Installa on and servicing should be performed
by qualified personnel.
2. Product must be installed in accordance with your local electrical code.
If you are not familiar with these codes and requirements, consult a
qualified electrician.
3. Do not change the structure or any commponents of the fixture to
ensure safety.
4. Lock the installa on angle a er luminaire installed. As following figure.
Tighten bracket screws on both sides, luminaire
installa on angle will be fixed by the lock gear.
SAVE THIS INSTRUCTIONS FOR FUTURE REFERENCE
TO INSTALL:
Luminaire
2
Moun ng Blots*¹
Celling /Wall
Moun ng Nuts*²
Allen Wrench*³
*¹ Minimum M10 (3/8") Bolts (not-provided)
*² Moun ng Nuts are not provided
*³ Allen Wrench: 8mm (5/16")
Trust
Moun ng Bracket
Waterproof Connector
3
Power Cord
(Cord Not shown)
INSTALLATION INSTRUCTIONS
100-240V/277V AC, 50/60Hz, Suitable for Wet Loca ons (IP65), Class I
*This product must be grounding
Model No. Power Dimension
SF-LED16-40
40W 293 x340 x156 mm /11.5 x13.4 x6.1"
SF-LED16-80
80W 366 x340 x156 mm /14.4 x13.4 x6.1"
SF-LED16-120
120W 439 x340 x156 mm /19.4 x13.4 x6.1"
SF-LED16-160
160W 512 x340 x156 mm /20.2 x13.4 x6.1"
SF-LED16-200
200W 585 x340 x156 mm /23.0 x13.4 x6.1"
SF-LED16-240
240W 658 x340 x156 mm /26.0 x13.4 x6.1"
328 mm (12.91 inches)
Pendant
40 mm (1.57 inches)
Φ12 mm (0.47 inches)
Moun ng
Hole
138 mm (5.43 inches)
12 mm (0.47 inches)
DIRECT MOUNTING
STEP 1:
Assemble the moun ng bracket to the fixture
by provided M10 (3/8") round head screws.
Power Cord STEP 2:
(Cord Not shown)
Mount the fixture by TWO(2) minimum M10
(3/8") bolts. See Figure 2.
STEP 3:
Loosen the moun ng bracket screws, adjust
the fixture to desire posi on, re-secure the
screws.
STEP 4:
Connect the Power Cord to the supply wiring
per "Electrical Connec ons" sec on for
comple ng electrical connec ons.
LED FLOOD LIGHTS
Weight
3.1 kg /6.8 lbs
4.3 kg /9.5 lbs
5.2 kg /11.5 lbs
6.0 kg /13.2 lbs
7.0 kg /15.4 lbs
7.8 kg /17.2 lbs
Moun ng Holes For
Minimum M10 (3/8")
Moun ng Bolts
1
