Steltronic ST-HB32 User And Installation Manual

Lcd 32” 16/9 monitor
Hide thumbs

Advertisement

Quick Links

Download this manual
Steltronic
ST-HB32 LCD 32" 16/9 Monitor
User and Installation Manual
Steltronic S.p.A.
Via Artigianale 34, 25082 Botticino Sera Brescia - Italy
Tel: +39 030 2190811 fax: +39 030 2190798
http://www.steltronic.com
Worldwide Service: + 39 030 2190830
Email: service@steltronic.com
US Steltronic: +1 (909) 287-0712
service.usa@steltronic.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the ST-HB32 and is the answer not in the manual?

Questions and answers

Summary of Contents for Steltronic ST-HB32

  • Page 1 Steltronic ST-HB32 LCD 32” 16/9 Monitor User and Installation Manual Steltronic S.p.A. Via Artigianale 34, 25082 Botticino Sera Brescia - Italy Tel: +39 030 2190811 fax: +39 030 2190798 http://www.steltronic.com Worldwide Service: + 39 030 2190830 Email: service@steltronic.com US Steltronic: +1 (909) 287-0712...
  • Page 2 Pg. 2 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual Index MONITOR ADJUSTMENTS and TECHNICAL SPECIFICATIONS Monitor technical specification Pg.
  • Page 3 Pg. 3 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [1.0] Monitor Technical specifications [1.1] General description ST-HB32A1X is a 32”...
  • Page 4 Pg. 4 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [1.5] Electrical Specifications [b] LCD PANEL: Max.Resolution...
  • Page 5 Pg. 5 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [2.0] OSD Screen Adjustments The monitor could be adjusted using the Remote control or directly from OSD panel accessible on rear of the monitor.
  • Page 6 English English Auto configuration ON/OFF SUGGESTED MONITOR SETTINGS FOR STELTRONIC SCORE [1]INPUT SOURCE Press vary time SOURCE button on Remote control until VGA screen appear on OSD [2] MENU DISPLAY Press <MENU> <ENTER> <Arrow DOWN> to display the Menu; use <Arrow LEFT>...
  • Page 7 Pg. 7 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual OSD tree menu...
  • Page 8 Pg. 8 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual...
  • Page 9 Pg. 9 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual...

  • Page 10: June

    Pg. 10 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual Next chapters are for installation crew only...
  • Page 11 “power supply connection” section of the Scoring Pre-installation manual. Steltronic S.p.A. supplies one power cord for each monitor with a VDE connector on it, 1.8 meters long (6 feet); the customer must provide one AC power outlet for each monitor at most 1.5 meters (about 4 feet) from the lane computer itself.
  • Page 12 Pg. 12 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [4.0] Monitor Dimensions ALL DIMENSIONS ARE IN MILLIMETRES...

  • Page 13: Tel +39 030 2190811 - Fax +39

    The monitors can be inclined to a max angle of 20 degrees. Washer, bolt, screws and metric nut for assembly the structure will be supplied by Steltronic, chain, fisher, etc for fix the T bracket to ceiling must be supplied by installers.

  • Page 14: 2190798 Http://Www.steltronic.com

    Pg. 14 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [5.1] Fixing the Brackets to the ceiling NOTE: All hanging method use the same “T”...

  • Page 15: St-Hb32 Lcd

    Pg. 15 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual Installation on concrete ceiling Installation with chain Warning: the “T”...
  • Page 16 Pg. 16 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual The distance between the 2 “T” bracket depends by choose of the installation’s method:...
  • Page 17 Pg. 17 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [5.2] Assembly the Frame for single monitor [Configuration A] Description Q.ty...
  • Page 18 Pg. 18 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [5.3] Hanging 2 near monitors [Configuration B] Description Q.ty...
  • Page 19 Pg. 19 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [5.4] Hanging 2 monitors with Central Plate [Configuration C] Description Q.ty...
  • Page 20 Pg. 20 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual To fix each vertical bar to the frame use 4 M6x30 “V head”...
  • Page 21 Pg. 21 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [5.5] Hanging 3 monitors [Configuration D] Description Q.ty...
  • Page 22 Pg. 22 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual Fix the vertical bar to the MC0153A structure: One vertical bar with the MW0129A support must be fixed on the left side of the frame MC0155A,the other on the center of the frame;...
  • Page 23 The RGB input for the monitor is the DB15 connector (VGA). When the Superelex is installed near the monitors, use one Steltronic RGB cable CA0260C for each lane. The Superelex could supply the AC power for to the monitor using one VDE female <>male cable for each monitor: with this connection, it’s be possible switch ON/OFF the monitors from Wins Software.
  • Page 24 Pg. 24 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual CA0260C (Superelex <> Monitor – VGA input) [6.1] Wins software settings for 16:9 monitors...
  • Page 25 Pg. 25 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual [6.2] Connecting the Lane computer (V.L.C.) to the monitor The RGB input for the monitor is the DB15 connector (VGA).NOTE: the DVI-D connector is not used.
  • Page 26 Connect MAX 8 Superelex in one daisy chain. For center with more than 8 Superelex, connect the CVBS source signal to a CVBS amplifier (supplied by Steltronic if requested) and split the Superelex in 2 or more daisy chain using the video amplifier output.
  • Page 27 Connecting a signal to the local S-Video / Video monitor input it’s possible use the Picture In Picture monitor function and split the screen with Score/TV. Using an CVBS video amplifier (supplied by Steltronic if requested) it’s possible connect 6 monitors under one CVBS source (DVD/SAT, etc); To connect more monitors, use more CVBS video amplifier in chain.
  • Page 28 Pg. 28 of 28 Steltronic STELTRONIC S.p.A. Rev A. ST-HB32 LCD 32” Botticino Sera (BS) - ITALY 16/9 Monitor Tel +39 030 2190811 - Fax +39 030 June 2007 2190798 http://www.steltronic.com User and Installation Manual Steltronic_ST-HB32LCD_ 32_16-9_Monitor_User_and_Installation_Manual (pdf) REV. A June 2007 Steltronic S.p.A.
