CHANGING A BULB
FRONT LIGHTS
1. Dipped headlamps
2. Main beam headlamps
3. Fog lamps
4. Side lights
5. Direction indicators
Handle the bulbs with a dry cloth.
Make access easier on the right-hand
side by removing the wash-wipe pipe
and the fuse box cover.
High pressure washing: when using
this type of washing on stubborn dirt,
do not persist on the headlamps, the
lights and their surrounds to avoid
damaging their coating and their seal.
1 - Dipped beam headlamps
H7-55 W or xenon bulb.
2 - Main beam headlamps
H7-55 W or xenon bulb.
3 - Fog lamps
H1-55 3W.
- Turn the protective cover
corresponding to the faulty bulb
a quarter of a turn to the left and
remove it.
- Disconnect the connector.
- Press the end of the securing clip
to free it. Change the bulb.
When fi tting the new bulb, ensure that
the direction notches are positioned
correctly and the securing clip is fi xed
properly.
- Reconnect the connector.
- Refi t the protective cover, then turn
it a quarter of a turn to the right.
Changing a bulb
4 - Side lights
W 5 W.
- Push the light from the inside
towards the outside of the bumper.
- Pull the light forwards.
- Turn the bulb holder a quarter of a
turn to the left and remove it.
- Turn the bulb a quarter of a turn to
the left, remove it and change it.
When refi tting, engage the light
towards the outside and move it
towards the inside of the bumper.
WARNING: RISK OF
ELECTROCUTION
Xenon bulbs must be changed by a
PEUGEOT dealer.
