  • Page 1 3DCPI-03 START-UP GUIDE Product Summary 3DCPI-03...

  • Page 2: Product Image

    3DCPI-03 START-UP GUIDE Product Image...

  • Page 3: Product Parameters

    3DCPI-03 START-UP GUIDE Product Parameters Forming Tech.: Fused deposition modeling (FDM) Tech. Parameters: Extrude Number: Dual extruders（Perfect supported） Build Size: 300*250*520mm Precision: X, Y 0.01mm, Z 0.015 Min. Layer: 0.04mm Nozzle Diameter: 0.4mm（0.3、0.5 Optional） Max. Travel Speed: 250mm/sec. Max. Print Speed: 180mm/sec Max.

  • Page 4: Product Features

    3DCPI-03 START-UP GUIDE Product Features All-metal unibody, sufficient rigidity and Metal Body weight powerful guarantee high-precision printing, printing effect and stability than wooden frame printer. Build size up to 300*250*520mm (L/W/H), Large Build far more than other 3D printer available in the market worldwide.
  • Page 5 3DCPI-03 START-UP GUIDE Fully enclosed chassis designed to create a Thermostat climate of printing environment, and the cover is easily removed. Durable Nozz. The extruder made by special materials, and also uses a more advanced design technology, the extrusion have more stable and longer life.
  • Page 6 3DCPI-03 START-UP GUIDE Printer Showcase Enlarged display, Texture clear and delicate Industrial products, smooth regular, size: 185*185mm...
  • Page 7 3DCPI-03 START-UP GUIDE...
  • Page 8 3DCPI-03 START-UP GUIDE...
  • Page 9 3DCPI-03 START-UP GUIDE...
  • Page 10 3DCPI-03 START-UP GUIDE Oversize, Size: 245*245mm Overhanging perfect, size: 145*145mm...
  • Page 11 3DCPI-03 START-UP GUIDE High dimensional character portrait, height: 30cm...
  • Page 12 3DCPI-03 START-UP GUIDE Character models, crisp and clear, size: 55*50*155mm Character modeling, smooth delicate, size: 68*82*98mm...

  • Page 13: Unpacking And Installation

    3DCPI-03 START-UP GUIDE Unpacking and Installation 1. Carefully unpack boxes, take out the printer carefully, and do not touch the axis. Plug in the power cable and turn on the power switch. 2. Observe the LCD screen, press the knob switch, select “Prepare”...
  • Page 14 3DCPI-03 START-UP GUIDE corresponding position as well. 7. Fix the table panel to the prop arm, note two corbel is inserted between the work surface and the tray, as shown below: 8. Screw 6 screws below the table panel, be sure to tighten.

  • Page 15: Software And Driver Installation

    3DCPI-03 START-UP GUIDE Software and Driver installation 1. From then CD or here download the installation package, follow the prompts to install the software, please try to use the default installation path, the path must not contain Chinese character. 2. Plug the power cable, connect the USB cable to the computer, open...
  • Page 16 3DCPI-03 START-UP GUIDE Installing and Replacing Filament 1. Important notes: “Installing and replacing filament must heat extruder firstly”, heating method reference later. 2. Install the axletree to the chassis at the corresponding screw hole. 3. Put filament reel on the axletree, ensure filament without wrapping, knotting and other anomalies.
  • Page 17 3DCPI-03 START-UP GUIDE Brief Slice and Printing Procedure 1. Open“CreatBot 3D Printer V4.x”software: 1、Open 2、Save GCode 2. Click “File”-> “Load model file”load model file. 3. Click “File”-> “Save GCode”. 4. Copy the GCode file to SD card, use SD card printing the model, and you can also printer the model at mentioned below: 5.
  • Page 18 3DCPI-03 START-UP GUIDE Usage of Cura Software The software's main role is to slice model into a series of two-dimensional plane pieces, each piece according to the shape dimension generate different paths to generate three-dimensional model GCode entire code, also called slices code, the exported file called slice files, extensions named ".GCode".
  • Page 19 “Extruder2” You can fine-tune the position of Vice-nozzle, which according to the actual situation stud print calibration, 3DCPI-03 printer defaults to using X-20, Y0 configuration, if your printer to print double-color model has a misalignment occurs, appropriate modifications X , Y offset value.
  • Page 20 3DCPI-03 START-UP GUIDE withdrawing a certain amount of filament in order to eliminate the phenomenon of draglines. Top / bottom thickness is the thickness of the upper and lower models, usually a multiple of layer height. Fill density controls how density filled the insides of your print will be, a value around 20% is usually enough.
  • Page 21 3DCPI-03 START-UP GUIDE nozzle temperature to compensate. Nozzle temperature is the melting temperature of filament, different manufactures have different melting temperature, general use 210 degrees with PLA, ABS with 240, too high or too low temperature can cause abnormal filament feed.
  • Page 22 3DCPI-03 START-UP GUIDE Attachment means use Brim like which method to fixed boundary model platform. “Brim” refers to create a boundary edge around the model, it is easy remove (recommended)，“Raft” refers to create a grid at the bottom of the model.
  • Page 23 3DCPI-03 START-UP GUIDE parameters to match the size of your printouts, too big too small will causing abnormal feeding。 Retract the filament when the nozzle is moving over a none-printed area, the speed is about 80~100, distance base on actual situation.
  • Page 24 3DCPI-03 START-UP GUIDE Speed at which infill parts are printed. If set to 0 then the print speed is used for the infill. Usually 1.5 times the print speed. Minimum time spend in a layer, gives the layer time to cool down before the next layer is put on top.
  • Page 25 3DCPI-03 START-UP GUIDE minimal speed. Create a solid top surface, if set to false the top is filled with the fill percentage. Useful for cups/vases. Create a solid bottom surface, if set to false the bottom is filled with the fill percentage. Useful for buildings.
  • Page 26 3DCPI-03 START-UP GUIDE 5、Model scaling, rotating, mirroring. Use Cura software can easily perform various operations on the model， modified model can also be through the "File" -> 。 "Save Model" to save To edit the model must first click the ，...
  • Page 27 3DCPI-03 START-UP GUIDE lead to thread into the opposite direction. 6、Viewing of the model. Cura can provide five different viewing modes, in order to provide better observe situation. Right picture: 5 kinds of ways from top to bottom as: Normal, Overhang, Transparent, X-Ray, Layers.
  • Page 28 3DCPI-03 START-UP GUIDE 7、Print Model With Cura. Cura software not only provides slicing function, but also provide basic functions of printing: 1. Load the STL model, set the slice parameters, after this a GCode will automatically generated. Or you can also click "File"...
  • Page 29 3DCPI-03 START-UP GUIDE turn on the power, open cura software, and reconnect. 4. Click Print button, the printer automatically heated hot-bed nozzle, when temperature reaches specified value, then start printing. You can adjust the printing speed through speed panel, as shown below: By...
  • Page 30 3DCPI-03 START-UP GUIDE Click “Term” switch to interactive terminal mode, you can control printer via command line.
  • Page 31 3DCPI-03 START-UP GUIDE The Use of Dual-nozzle 3DCPI-03 3D printer launched the first dual-nozzle printing perfect solution, using a dual-nozzle printer, you can not only print dual-color model but also use main nozzle print model and vice nozzle print support.
  • Page 32 3DCPI-03 START-UP GUIDE “support dual extrusion” option on the basic panel. 3、Advance using of dual-nozzle. Replace the main nozzle with vice-nozzle, sometimes we want to use vice-nozzle subtitude main nozzle, to achieve the above functions , it is necessary to manually modify the GCode file.
  • Page 33 3DCPI-03 START-UP GUIDE LCD and SD Operation 3DCPI-03 3D printer using the original Ultimaker screen mode, with new design, SD card position better than before. Offline print consists following three parts, LCD, SD, knob. knob both CLICK and SPIN two functions. The main screen screen displays as shown: 1、Main screen.
  • Page 34 3DCPI-03 START-UP GUIDE There have deference at the second menu. Go back Prepare Control SD card ♦ Watch. Back to main screen. ♦ Prepare print. E.g. heating nozzle and hot bed, platform back to zero position. ♦ Control. Change some parameters.
  • Page 35 3DCPI-03 START-UP GUIDE • Preheat PLA. • Preheat ABS. • Cool down the nozzle and hotbed. • Move axis and extruders. Move X,Y axes, you can only move z with 0.1mm per step, you can also do filament extrude and retract.
  • Page 36 3DCPI-03 START-UP GUIDE then select Tune to enter sub menu. 2、Select Nozzle and press knob, screw adjust, press confirm. 7、Real-time adjustment hot bed temperature 1、Press knob in the main screen, select Tune to enter real-time adjustment menu. 2、 Select Bed and press knob, screw adjust, press enter confirm.
  • Page 37 3DCPI-03 START-UP GUIDE 11、Other menu 1、Other menu is not commonly used, please do not modify.
