Secuway IS-5000 Installation Manual

Electronic lock
Hide thumbs Also See for IS-5000:

Advertisement

Quick Links

IS-5000 Electronic Lock
INSTALLATION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the IS-5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Secuway IS-5000

  • Page 1 IS-5000 Electronic Lock INSTALLATION MANUAL...
  • Page 2 | IS-5000 IS5000 EXPLODED VIEW RETRACTOR LATCH YOKE POWER MOTOR PCB CABLE CABLE CABLE LATCH OUTSIDE LEVER INSIDE TRIM CONNECTIONS KEY BUSHING LATCH TAIL LATCH BODY LATCH & LOCK BODY OUTSIDE TRIM ASSEMBLY INSIDE TRIM REAR VIEW CABLE MANAGEMENT PCB CABLE...
  • Page 3: Door Preparation

    IS-5000 | 1. DOOR PREPARATION Determine required backset Determine door edge bevel requirement Ensure template is printed at 1:1 (or True) scale Fold template according to chosen door edge requirement (Step 2) Fix template to door at required latch height...
  • Page 4 | IS-5000 3. LOCK DISASSEMBLY FROM PACKAGING Insert Disassembly Tool into pin hole as shown while pulling on INSIDE lever POWER MOTOR Remove all fasteners as indicated PCB CABLE CABLE CABLE OUTSIDE TRIM ASSEMBLY INSIDE TRIM CONNECTIONS PCB CABLE INSIDE TRIM PLATE...
  • Page 5 ADJUSTMENT FOR 1-4/7” (40mm) DOOR FOR DOOR THICKNESS ADJUSTMENT IS-5000 Series is designed to fit door thicknesses between 1-4/7” (40mm) to 1-7/9” (45mm). The factory default door thickness is set to 1-7/9” (45mm). To adjust for thinner door, down to 1-4/7” (40mm):...
  • Page 6 | IS-5000 4. INSTALL OUTSIDE TRIM 3/8”HOLE RETRACTOR LATCH YOKE LATCH 2-1/8” HOLE LOCK BODY VIEW “A” PCB CABLE Gently fold PCB Cable against connector and pass edge of connector through 3/4” hole as shown Insert Motor Cable and Lock Body chassis through 2-1/8”...
  • Page 7 IS-5000 | 5. INSTALL INSIDE TRIM POWER MOTOR PCB CABLE CABLE CABLE INSIDE TRIM CONNECTIONS PCB CABLE MOTOR CABLE INSIDE TRIM PLATE INSIDE TRIM PLATE SCREWS INSIDE TRIM INSIDE TRIM ASSEMBLY M5 1” CABLE MANAGEMENT REAR VIEW INSIDE TRIM SCREWS (SHORT) M4x1 /3”...
  • Page 8: Strike Installation

    | IS-5000 6. STRIKE INSTALLATION Using latch bolt as reference, align and mark the position of the strike Drill pilot holes for fasteners and mortise cavity as shown Install strike and dust box using supplied fasteners DEPTH 1/2” DUST BOX...
  • Page 9 IS-5000 | IS5000 TEMPLATE Do not use template 1” if not to scale 1”...
