Full 3D Pass-through 30M Solution HDMI Extender Over 2 x Cat5e/6/7 EXOB03N User Manual... -
Page 2: Package Contents
INTRODUCTION This HDMI transmitter and receiver is the right way to send your HDMI signal over long distances. It allows you to use 2X Cat.5e/6/7 cables to extend the HDTV display up to 30M for 1080P without any loss. It is equipped with HDMI connector and is capable of supporting DVI equipment when used with an HDMI to DVI adaptor. -
Page 3: Panel Description
PANEL DESCRIPTION Transmitter Unit DC 5V HDMI Extender Over CAT 5E/6/7 1 POWER SUPPLY INPUT 2 HDMI INPUT 3 CAT5E/6/7 OUTPUT Receiver Unit HDMI Extender Over CAT 5E/6/7 DC 5V 1 CAT5E/6/7 INPUT 2 HDMI OUTPUT 3 POWER SUPPLY INPUT... -
Page 4: Installation
INSTALLATION •Connect HDMI input port on transmitter to the signal source equipment such as DVD player. •Connect the 2x CAT5e/6/7 output of the transmitter with 2 CAT5e/6/7 cables to the CAT5e/6/7 inputs of the receiver. •Plug the 5VDC power supply into the unit and connect the adaptor to AC outlet. -
Page 5: Specification
SPECIFICATION Transmitter Input Port 1 x HDMI (Female Connector) Output Port 2 x Cat5e/6/7 Receiver Input Port 2 x Cat5e/6/7 Output Port 1 x HDMI (Female Connector) Bandwidth 10.2Gbps Output Resolution 480i~1080P@50/60,1080P@24/50/60, VGA~UXGA Operating Temperature -15℃~55℃/5°F~131°F Deep Color 36bit Chassis Metal Dimension 83mm(L)x46mm(W)x22mm(H) -
Page 6: Safety Precautions
8.Unplug the equipment when unused for a long period of time. 9.Do not try to open any non-serviceable parts. Contact your authorized servicing center and personnel. Keep Away Danger Electric Keep Dry from Heat Shock Risk Tel:+86 769 81877098 Email:chinasales@hailink.cn Fax:+86 769 81877138 Http:www.hailink.cn...
