The VGA Extender allows VGA video signals to be transmitted up to 500ft / 135m via 4-pairs CAT5
STP or UTP cable. Used in pairs, the VGA Extender can be used in home or commercial applications
as a smart, fast and cost-effective solution. It eliminates costly and bulky VGA cable, allowing VGA
monitors to be connected extended distances from the PC via standard twisted pair cable. This
product is ideal for classrooms, lecture halls, retail kiosks, video information displays, overhead
projector systems, PC-training systems, and tradeshows PC demo systems.
Features:
Passive device, no power required
Includes VB100VK-T Transmitter unit and VB100VK-R Receiver unit
Supports up to 1280x1024 pixels
Distance up to 500ft / 135m via standard CAT5 STP or UTP cable instead of VGA cable
Transmitter has built-in virtual DDC to avoid improper resolution and frequency settings
Transmitter has built-in sync mode selection for signal stability
Receiver has built-in sync filter level adjustment for signal stability
Installation:
Recommended Cable:
1. CAT5e UTP/STP or CAT6 UTP cable.
2. Certain brands or models of monitors are highly sync-sensitive. In these cases we recommend
using STP (shielded twisted pair) cable instead of UTP (unshielded twisted pair) cable.
RJ45 Pin Configuration: TIA/EIA 568B Wiring standard
1. Orange-white
2. Orange
3. Green-white
4. Blue
5. Blue-white
6. Green
7. Brown-white
8. Brown
Cabling Systems & Solutions
Rev102007
VGA Extender
Model: VB100VK
Red +
Red -
H-Sync
Green +
Green -
V-Sync
Blue +
Blue -
UTP = Unshielded Twisted Pair / STP = Shielded Twisted Pair
VGE01
Advertisement
Table of Contents
Summary of Contents for O.K.I. usa VB100VK
- Page 1 PC-training systems, and tradeshows PC demo systems. Features: Passive device, no power required Includes VB100VK-T Transmitter unit and VB100VK-R Receiver unit Supports up to 1280x1024 pixels Distance up to 500ft / 135m via standard CAT5 STP or UTP cable instead of VGA cable...
- Page 2 2. For older monitors, Mode 2 is recommended. If the picture is still not stable, please try adjusting the dip switches on the VB100VK-R Receiver unit. In the case that the dip switches still do not fix the problem, please use STP (shielded twisted pair) cable.
-
Page 3: Wiring Diagram
3. Picture tilt: Check DIP switch setting Change the resolution or frequency Change Link cable for STP cable Wiring Diagram: Panel View: VB100VK-T VB100VK-R Cabling Systems & Solutions UTP = Unshielded Twisted Pair / STP = Shielded Twisted Pair Rev102007 VGE01... - Page 4 350ft / 105m 1024x768 pixels (60MHz) 250ft / 75m 1280x1024 pixels (100MHz) 200ft / 60m Specification: Model Number VB100VK-T VB100VK-R Devices DVR, VGA Monitors, Projectors, Laptops, PCs. Input Signals Video: 1 Vp-p Horizontal & Vertical Sync : TTL standard. 300kHz max. bandwidth...
- Page 5 2. STP (shielded) RJ45 connector with STP cable connection. If your RJ45 connector has plastic housing (unshielded), then the cable connection must be configured as follows: The ground cable must be pulled out around 5-10cm to connect with the VGA Extender’s ground screw for grounding.
