INSTALLATION MANUAL
DX3-3001S Cold Climate
Solar Lighting System
Hardware List
Wood Pole Solar System
4 ea. ⅝" x 18" Stainless steel ready rod –
1.
Battery Box, Pole Arm and Solar Panel
Frame Mounting
Toll Free: 866-796-0303
Tel: 780-756-0300
2. 8 ea. ⅝" Flat washers and nylon locknuts -
3. 4 ea. 5/16" x ¾" Bolt with washers and
4. 15 foot 2C #16AWG VNTC cable - pre-
5. 1 ea. Battery mounting strap, 1" x 6' black
6. 1 ea. Battery Jumper cable
7. 1 ea. Battery cable c/w quick connect plug
8. 2 ea. MC4 Cable, male/female, 15'
DX3 ENTERPRISES LTD.
102, 1289 - 91 Street SW, Edmonton, AB, Canada, T6X 1H1
Fax: 866-821-3732
Battery Box, Pole Arm and Solar Panel
Frame Mounting
nylon locknut - Mounting solar panel
connected to battery box, fish to light head
nylon c/w metal buckle
