- Page 1 MINI DESIGN MOSDET CAR AMPLIFIERS 1200W FA-2075A FA-2125A...
- Page 2 INTRODUCTION PRODUCT SPECIFICATIONS FA-2075A VVME RMS @ 4 Ohm (<1% DISTORTION)........2 X 75W RMS @ 2 Ohm (<1% DISTORTION)........2 X 110W Maximum Power Output............ 1 X 220W Frequency Response............5Hz ~ 30kHz S/N Ratio................. VVME >80dB THD................<0.05% VVME Input Sensitivity Level............
- Page 3 TROUBLESHOOTING AMPLIFIER FUNCTIONS FA-2075A BTL (4 MIN) REMOTE INPUT 1.Left Speaker Output Remote Control 2.Right Speaker Output 4.RCA Input Jacks VVME For additional questions please contact your authorized dealer. PROTECT POWER FUSE 4.30Amp Fuse Ground 2.Remote Turn-on Input 5.Protection Circuit Indicator LED 3.Battery +12V Input...
- Page 4 FA-2125A 2-Channel Full-Range Satellite, or Subwoofer FLAT System L Full Range R Full Range BASS GAIN BOOST FLAT 12dB 50Hz 1.2KHz 50Hz 500Hz BASS GAIN BOOST FLAT 12dB 50Hz 1.2KHz 50Hz 500Hz BASS GAIN BOOST FLAT 12dB 50Hz 1.2KHz 50Hz 500Hz 1.GAIN Control 4.Bass Boost Select Switch...
- Page 5 FA-2125A FA-2125A Bridged - Mono Subwoofer System 1.RCA Input Jacks 2.Left Speaker Output 3.Right Speaker Output Subwoofer BASS GAIN BOOST FLAT 12dB Ground 4.30Amp Fuse 50Hz 1.2KHz 50Hz 500Hz 2.Remote Turn-on Input 5.Protection Circuit Indicator LED 3.Battery +12V Input 6.Power Indicator LED...
- Page 6 FA-2125A Remote Turn-on BASS GAIN BOOST FLAT 12dB 50Hz 1.2KHz 50Hz 500Hz Right Speaker - Right Speaker + 1.GAIN Control 4.Bass Boost Select Switch 2.Filter Select Switch 5.LPF Control Left Speaker - 3.HPF Control Left Speaker +...
- Page 7 FA-2075A INSTALLATION 2-Channel Full-Range, Satellite, or Subwoofer System VVME We recommend you have the installation done by an Authorized Dealer. The ground wire should be connected directly with the chassis of your vehicle which should be a metal to metal ground point connection. The amplifier must be mounted securely at BTL (4 MIN) a solid, dry and low vibration surface in the trunk or passenger area.
- Page 8 FA-2075A WIRING AND APPLICATIONS Bridged - Mono Subwoofer System Our mini amplifiers can be used in a variety of system applications. A few examp- les are provided below. FA-2075A 2-Channel Full-Range Operation BTL (4 MIN) REMOTE INPUT Remote Turn-on PROTECT POWER...
