Summary of Contents for Jaroby ULTIMATE
- Page 1 OWNER’S MANUAL ULTIMATE ULTIMATE-B HIGH EFFICIENCY WOOD STOVE Certified and tested according to UL-1482-00 and ULC-S627-00 norms. Revised December 04, 2013 ULTIMATE and ULTIMATE-B 490, rue de l'Argon Quebec (Québec) G2N 2C9 Phone: 418-849-8095 Fax : 418-849-0077 www.jaroby.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING ...............................3 NOTICE ..............................5 Creosote ..............................5 SPECIFICATIONS - ULTIMATE and ULTIMATE-B ...............6 INSTALLATION .............................7 Vertical installation inside a masonry chimney ..................8 Exterior vertical installation .........................8 Vertical installation on a cathedral roof ....................9 Cross installation ..........................10 Vertical installation ..........................10 CLEARANCES ............................ -
Page 3: Warning
WARNING Before installing, please take a few minutes to read this handbook. Keep it in a sure place and easily reachable for future references. If this appliance is not properly installed, it could cause fire damages to the property, injuries and death. To reduce fire hazards, follow instructions contained in this handbook. - Page 4 Ashes must be evacuated frequently, remove it with a small steel shovel. Very hot while in operation. Keep the children away. Can cause burns by contact. Considering the need of air for the combustion, a window or a door must be half opened sometimes (fresh air drainage) to balance the pressure in the house, especially if: A fan already evacuates air towards outside (kitchen, bathroom.) You want to avoid smoke spillage when lighting the appliance and when reloading...
-
Page 5: Notice
- Do not use the appliance when a glass is broken or damaged. - Do not build the fire close to the glass. - Keep the door closed when using the appliance. - Do not connect the Ultimate with a chimney or a flue serving another heating appliance... -
Page 6: Specifications - Ultimate And Ultimate-B
SPECIFICATIONS - ULTIMATE AND ULTIMATE-B Combustible Wood 500 à 3000 ft² (46,5 à 278,70 m²) Recommended surface 6 in (15,24 cm) Evacuation pipe diameter Chimney minimal height 12 ft (3,66m) Dimensions 35.8 in. (90,9 cm) Exterior height 27,5 in. (70,0 cm) -
Page 7: Installation
INSTALLATION A good installation is extremely important for a safe and efficient use of your J. A. Roby Inc. appliance. If you doubt on the way to install the appliance correctly, seek for professional installation service. We suggest you to call masters fitters. 1. -
Page 8: Vertical Installation Inside A Masonry Chimney
ERTICAL INSTALLATION INSIDE A MASONRY CHIMNEY The Ultimate and Ultimate-B models must be installed in accordance with the applicable local laws or the CAN/CSA - B365 ULC S635, ULC S640, UL 1777 norms. For the chimney, follow the chimney manufacturer's instructions. -
Page 9: Vertical Installation On A Cathedral Roof
ERTICAL INSTALLATION ON A CATHEDRAL ROOF The Ultimate and Ultimate-B models must be installed in accordance with the applicable local laws or the CAN/CSA - B365 ULC S635, ULC S640, UL 1777 norms. For the chimney, follow the chimney manufacturer's instructions. -
Page 10: Cross Installation
ROSS INSTALLATION The Ultimate and Ultimate-B models must be installed in accordance with the applicable local laws or the CAN/CSA - B365 ULC S635, ULC S640, UL 1777 norms. For the chimney, follow the chimney manufacturer's instructions. ERTICAL INSTALLATION The Ultimate and Ultimate-B models must be... -
Page 11: Clearances
Due to its reduced clearances, this appliance occupies a minimum of space in the room where it is installed. No matter where you install it, the Ultimate and Ultimate-B models will complete perfectly your decoration by their originality and their heat. With the... -
Page 12: Floor Protector
FLOOR PROTECTOR Your wood stove should be placed on a non-combustible plate under the appliance, which must exceed 18 inches to the front, 8 inches on each side and 8 inches to the back. *** Only use non-combustible materials. Ex : (ceramic, marble, granite) -
Page 13: Door Adjustment
DOOR ADJUSTMENT In order for your stove to operate properly, the door should be adjusted using the small wrench tool to provide an air tight fit: To adjust: Turn clockwise until the door is air tight. LIGHTING Now that you have completed the installation of the appliance according to the recommendations, you are ready for the lighting! 1. -
Page 14: Fans And Thermodisc
FANS AND THERMODISC The 115 volts fans must be screwed with the grids beneath the air corridor. The thermo disc box must be screwed on the back of the corridor. Connect the thermo disc into the electrical outlet. When the appliance is in function, the heat reaching a temperature of F activates the thermo disc. -
Page 15: Preventive Measures And Maintenance
PREVENTIVE MEASURES AND MAINTENANCE We recommend opening the air intakes completely and to maintain an intense fire from 10 to 20 minutes per day or use a chimney thermometer, as flue gases should reach at least 350° F before closing the air intake. Verify the accumulation of creosote every week that you use the appliance until you know at which frequency it must be cleaned (minimum once per year). -
Page 16: Replacement Part L Ist
REPLACEMENT PART L IST • BRICKS • WOOL • PLATES USED TO RETAIN WOOL • PIPES • GLASS • BRICKS SUPPORTS • DOOR HANDLE • FANS • CORDS O ORDER PARTS PLEASE CONTACT YOUR AUTHORIZED RETAILER... -
Page 17: Installation Of The Firebricks
INSTALLATION OF THE FIREBRICKS Before you begin, please take note that the purpose for the screws is to secure the bricks inside the stove. First, install the bricks C (10), F (2), E (1) at the bottom of the stove and C (1) & D (1) on the inclined part near the door. -
Page 18: Figure 1 .
Figure 1 . 0... -
Page 20: Warranty
STOVES & FIREPLACES WARRANTY J. A. ROBY LIMITED LIFE WARRANTY – WOOD BURNING STOVES & FIREPLACES J. A. ROBY’s warranty only applies to original buyer and is non-transferable. This warranty covers brand new products only, which have not been altered, modified nor repaired since shipment from factory. The products covered by this warranty must be manufactured after review date indicated at the bottom of page.
