AV Tech AVC733 User Manual

Mpeg-4 video web server
Hide thumbs
Table of Contents

Advertisement

Quick Links

13
Video Web Server
Video Web Server
MPEG
-
4
MPEG
-
4
VIDEO WEB SERVER
VIDEO WEB SERVER
User
'
s Manual
User
'
s Manual
Please read instructions thoroughly before operation and retain
it for future reference.
733_V0.95
Please read instructions thoroughly before operation and retain
it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVC733 and is the answer not in the manual?

Questions and answers

Summary of Contents for AV Tech AVC733

  • Page 1 Video Web Server Video Web Server MPEG MPEG VIDEO WEB SERVER VIDEO WEB SERVER User ’ s Manual User ’ s Manual Please read instructions thoroughly before operation and retain it for future reference. 733_V0.95 Please read instructions thoroughly before operation and retain it for future reference.
  • Page 2 Thank-You Note Before You Get Start First of all, we would like to express our gratitude to you for purchasing this product. This product is designed to meet your personal needs with our great industry-designing ability and our everlasting perseverance to the quality of all our products. This manual will introduce to you how to install this apparatus.
  • Page 3 IMPORTANT SAFEGUARD IMPORTANT SAFEGUARD CAUTION CAUTION RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NO OPEN DO NO OPEN CAUTION: CAUTION: To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label. Failure to do so may cause injury or death by electric shock and invalidates the warranty.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS PARTS AND FEATURES PARTS AND FEATURES 1.1 FEATURES ------------------------------------------------------------------------------------------------------------ 1.2 PACKAGE CONTENTS -------------------------------------------------------------------------------------------- 1.3 SPECIFICATION ----------------------------------------------------------------------------------------------------- 1.4 PANEL ------------------------------------------------------------------------------------------------------------------ INSTALLATION AND CONNECTION INSTALLATION AND CONNECTION 2.1 SYSTEM CONNECTION ------------------------------------------------------------------------------------------- 2.2 CONNECT DVR TO VIDEO WEB SERVER ------------------------------------------------------------------ 2.3 SOFTWARE INSTALLATION ------------------------------------------------------------------------------------ 2.4 IP SETTING AND LAN CONNECTION ------------------------------------------------------------------------ 2.5 CONNECT VIA INTERNET ---------------------------------------------------------------------------------------...

  • Page 5: Parts And Features

    PARTS AND FEATURES PARTS AND FEATURES 1.1 FEATURES 1.1 FEATURES Support MPEG4 compression format for real-time video stream Compression format (MPEG4 / JPEG) is selectable for different network bandwidth and applications Support video / audio recording Support alarm / motion trigger recording Adjustable motion detect sensitivity Whenever alarm system triggered, video streaming or pictures will be uploaded over FTP,...

  • Page 6: Specification

    1.3 SPECIFICATION 1.3 SPECIFICATION SPECIFICATION SPECIFICATION 1 channel for analog & digital products, Video Input 1.0 Vp-p 75 composite, BNC Audio Input 1 channel audio input Alarm Input 2 inputs / 1 output Watch dog RS-485 Port Network Interface Ethernet (10/100 Base-T) Image Compression MPEG4 / JPEG Video Adjustment...

  • Page 7: Panel

    1.4 PANEL 1.4 PANEL LAN: Connect Video Web Server to the Internet or LAN with cable or connect directly to PC with standard pass through cable. VIDEO INPUT (1 channel): Connect to video source, such as camera or DVR video output. AUDIO INPUT (1 channel): Connect to audio source, such as camera audio output.

  • Page 8: Installation And Connection

    INSTALLATION AND CONNECTION INSTALLATION AND CONNECTION 2.1 SYSTEM CONNECTION 2.1 SYSTEM CONNECTION Power: Connect to DC 12V regulated adapter. Power: Video and Audio Input: Connect video and audio outputs of camera or DVR…etc. Video and Audio Input: Take DVR as an example, after connection, set the baud rate and ID of the DVR. Make sure that the baud rate and ID as same as the settings of the VIDEO WEB SERVER.

  • Page 9: Connect Dvr To Video Web Server

    2.2 CONNECT DVR TO VIDEO WEB SERVER 2.2 CONNECT DVR TO VIDEO WEB SERVER DVR Baud Rate and ID Setting: DVR Baud Rate and ID Setting: Set the baud rate and ID of the DVR. Make sure that the baud rate and ID as same as the settings of the VIDEO WEB SERVER.

  • Page 10: Software Installation

    2.3 SOFTWARE INSTALLATION 2.3 SOFTWARE INSTALLATION Put the attached CD into a CD-ROM and it will start to install application program into PC. Click “ “ twice. Click “Finish” button to complete the setup. And users will see the icon “ “...
  • Page 11 Before changing this properties setting, please write down the original network setting in order to recover the original setting after “Section 3.2 VIDEO WEB SERVER SETTING”. Click on “Use the following IP address” , set IP address and subnet mask. The IP address should be like 192.168.1.XXX.
  • Page 12 When users see the following screen, means successfully logged in the program of the Video Web Server. Click “System Config” to set up. 2005 2005- May- 30 [MON] 09 :01 :56 30 [MON] 09 :01 :56 1200GB 1200GB Camera 01 Camera 01 Camera 02 Camera 02...
  • Page 13 Click on the Network, set server IP, gateway, and net mask which are provided from local ISP ( internet service provider ), web server, stream port, and IP type. Press “APPLY” to enable the change after the setting. Static IP: Static IP: Note: Dynamic IP:...

  • Page 14: Connect Via Internet

    2.5 CONNECT VIA INTERNET 2.5 CONNECT VIA INTERNET Change PC network setting to the original setting and link PC to the internet. ( Since the PC IP setting has been changed, now it must recover to the original setting for connecting to internet ). Click twice and enter “User Name”, “Password”, “Static IP”, and “Port”.

  • Page 15: Operation Guide

    OPERATION GUIDE OPERATION GUIDE 3.1 SOFTWARE OPERATION 3.1 SOFTWARE OPERATION After physical connection and network setting of the video web server. Please following the illustrations in this section for software operation. Click twice to enter Login page. Key in “User Name”, “ Password”, and “Server IP” (Static IP) or “Host name”(Dynamic IP).
  • Page 16 Introduction of Basic Operation: Video Web Server Control Panel Video Web Server Control Panel Image transfer rate per second Data transfer rate Video only / Audio only / Both d e f g h Video and Audio Connect / Disconnect Image adjusting : Brightness / Contrast / Saturation / Hue 2005...
  • Page 17 Digital Device Control Panel ~ PTZ Digital Device Control Panel ~ PTZ (For example, PTZ) Preset 1 ~ 16 AUTO n. o. p. q. Zoom Tele Zoom Wide Focus Near Focus Far Max Zoom In Max Zoom Out Menu / up / down / left / right Enter TURBO: To speed up menu selecting or the control of the PTZ camera under video web server,...

  • Page 18: Playback Operation

    3.2 PLAYBACK OPERATION 3.2 PLAYBACK OPERATION Please find a recording file in the PC and double click on it to playback. 2005 / May / 30 09 :01 :56 2005 / May / 30 09 :01 :56 CH 1 CH 1 ％...

  • Page 19: Advanced Setting

    3.3 ADVANCED SETTING 3.3 ADVANCED SETTING IP: 61.66.138.53 Press “System Config ” button to enter the “System Config” page. In this “System Config” page, users could select the different functions to set up. After setting, please press “APPLY” button to save the settings. System setting includes: Network, DDNS, SNTP, FTP, Mail, General, Peripheral, Account, File Path, Schedule Record, Trigger, Information, Log File, Event Record List.

  • Page 20: Ddns

    DDNS DDNS DDNS is a service for transforming dynamic IP to corresponding to a specific “Hostname”. Enable the DDNS function. Key in the “DDNS username” into “User Name”. Key in the “DDNS password” into “Password”. Key in the “Hostname” into “Domain”.

  • Page 21: Ftp

    When alarm is triggered, the video server will capture the instant picture and upload the captured image to the assigned FTP site. Note: To get alarm notification at FTP Note: site when there is a alarm trigger, users must enable the function of FTP notification in the “Trigger”...

  • Page 22: General

    General General 1) Users could set “Video System”, “Video Type”, “Resolution” and “Quality”. 2) Video System: * NTSC * PAL * AUTO 3) Video Type: * JPEG * MPEG4 4) Resolution: * MPEG 4 (D1), JPEG (D1), Frame Note1 : D1 represents 704 x 480 (NTSC) * MPEG4 (D1), JPEG (CIF), Frame CIF represents 352 x 240 (NTSC) * MPEG 4 (CIF), JPEG (CIF), Frame...

  • Page 23: Account

    Account Account a b c d e Set up the user’s account ( Max 10 accounts) , password, life time, and authority level ( Max 10 accounts on Max 10 accounts on line at the same time). line at the same time User’s level: SUPERVISOR SUPERVISOR...

  • Page 24: Schedule Record

    Schedule Record Schedule Record Users could preset timer schedule for recording. Click on “Add” button, and add time setting preference. Note: Note: The time of schedule record is depend on the time in the PC, not the time in the video web server. Trigger Trigger Alarm :...
  • Page 25 Total: When video type is MPEG4 ~ Uses could select the notification file to be 1-3 seconds. When video type is JPEG ~ Uses could select the notification file to be 1-10 pictures. Motion Setup: Motion Area: Motion Area Users could set motion detection areas here.

  • Page 26: Information

    Information Information Users could get all the online users’ information here (Name, IP Address, Authority Level, Media Type). Media Type: show the information including video type (JPEG / MPEG4) and medium type (Audio / Video / Audio and Video) Log File Log File Users could get all the information of log file.
  • Page 27 APPENDIX #1 APPENDIX #1 APPENDIX #1 – DVR PIN CONNECTION APPENDIX #1 – DVR PIN CONNECTION Connect the Sub-D plug of Video Web Server with DVR products.

  • Page 28: Ptz Pin Connection

    APPENDIX #2 APPENDIX #2 APPENDIX #2 – PTZ PIN CONNECTION APPENDIX #2 – PTZ PIN CONNECTION Connect the Sub-D plug of Video Web Server with our own brand PTZ products. RS-485-A RS-485-B Set the “Peripheral Control” in the system config of Video Web Server. NOTE: Set the ID as the PTZ ID value.

  • Page 29: Ie Browser

    APPENDIX #3 APPENDIX #3 APPENDIX #3 – IE BROWSER APPENDIX #3 – IE BROWSER Users could go access Video Web Server through the web page. Just type the IP address of video web server into the URL address box and press Enter. Then users will see the following pages.

  • Page 30: Ddns Apply

    APPENDIX #4 APPENDIX #4 APPENDIX #4 – DDNS APPLY APPENDIX #4 – DDNS APPLY Go to a website which provide free DDNS services. For example, “http://www.dyndns.org”. Create an account in DynDNS. Click on “Account”, then users could see the following page. Click on “Create Account”, then users could see the following page.
  • Page 31 After created account, users will receive an confirmation e-mail within a few minutes. To complete registration, please follow the directions that users will receive. Users must complete these steps within 48 hours to complete the registration. If users do not the confirmation e-mail within an hour or so, request a “password reset”...
