- Page 1 8 in 1 HD 12MP Infrared game Camera SG-990V（850nM & 940nM） User’s Manual Welcome to buy SG-990V Infrared digital scouting camera. For making best use of all functions of the camera, please read this user’s manual carefully before using it.
-
Page 2: Table Of Contents
CONTENTS General Information……………………………….………….….….2 Application…………………………………………..………..………4 Camera Overview…………….….………………..…..….…...5 Quick Start Guide…..……………………………..…….….……….7 Menu Overview…………………………………….…….…….…...10 Camera Setup and Program…………………......12 Setting up the camera in the field……………………....…23 Appendix I: Default Setting…………….………..……..……..29 Appendix II: Technical Specification…………......30 Appendix III: Parts List..…………………………......31 FCC Compliance……………………......…………….32 - 1 -... -
Page 3: General Information
SG-990V has game call function, it built in a speaker to play animal or alarm sound to attract their companion in the region of camera surveillance. - Page 4 Furthermore, the camera can be used as a portable digital camera. Pictures or videos can be taken manually by pressing Shot button on the operation panel. Storing conditions Operating Enviroment:-22 to 122 deg F(-20 to 60 deg C). 20-85% relative humidity, non-condensing.
-
Page 5: Application
Application Trail animals trace or habit, camera be used as trail camera for hunting or monitoring animals by recording the traces of wild animals. Is camera trap for animals, or for wildlife camera Wildlife observation, Monitor plant, animals growing up ecological monitoring and researching Traffic/surrounding surveillance, Camping fun/exploring caves Security and surveillance: This camera can be used as automatic surveillance... -
Page 6: Camera Overview
Camera Overview Shell + Inside camera Shell Front View Shell Back View Pay attention to take long distance between the mounting point and speaker of camera so that the speaker sound is normal. - 5 -... - Page 7 Inside view White Flash Mode Button USB Port IR LED Shot Button Battery Compartment Switch Lens, Filter Up/Down/Right/Left/O TV Out Port Button PIR Sensor Menu Button DC In Port Low battery/No SD Replay Button Microphone Card Indicator Work Indicator 2.0Inch TFT Screen Battery Compartment Cover Switch(White Flash...
-
Page 8: Quick Start Guide
Quick Start Guide This guide is designed to get you up and running in a matter of moments. To get the most out of this Invisible IR Guard Camera tools, please read the manual thoroughly before operating. If you would like to modify any of the factory Default Settings, except for the Time &... - Page 9 Enter into the TEST Mode Preview the scene in LCD screen; Test PIR detection; Manual capturing (Press“Mode”to choose five modes); “Replay” Playback Picture and video（Press “DEL” to delete picture or video） “MENU” Setting camera; Manual Capturing keys： ★ Up/Down/Left/Right/OK Press“OK” to confirm your operation MENU In Test mode, press MENU to manually customizing the camera setting MODE...
- Page 10 Replay/Delete picture and video Press “Replay” to playback, Press “DEL” to delete picture and video The camera offers the user different options for viewing their images. A, Viewing files on computer via USB connection • Make sure the camera’s power switch is in the OFF position.
-
Page 11: Menu Overview
Menu Overview In “TEST” Mode, Press “Menu” button to set camera parameters - 10 -... - Page 12 SG-990V MENU Code MENU Settings Photo/Video/Time Mode lapse/Hybrid(Camera+Video)/Motion detection Set Clock MM/DD/YY HH/MM Digital Zoom OFF 2/3/4 times Image Size 12M/8M/5M/2M Picture No. 1-9 Image Burst (.JPG) Video Size Full HD1920 x 1080 / HD1280 x 720 (.AVI) Video Length...
-
Page 13: Camera Setup And Program
All parameters setting should be in “TEST” Mode. Power ON and Test Mode Switch camera to “TEST” position, Logo “Bestguarder” is showed on LCD screen! In “Test” mode, the shooting information will be display on the screen: Cautions* Please insert SD card and TF card (save alarm sound or animal voice) before power on. - Page 14 Set Camera Mode: • Slide the switch to “Test” position • Press the “MENU” button once • LCD display will show “MODE” on camera status screen • Press OK button to set “Mode” • Press UP/Down button to select mode and the option will be highlighted •...
- Page 15 • Press OK button to save the current setting • Press Menu button to cancel setting and exit Video Size--(FHD)1080/(HD)720 • Slide the switch to “Test” position • Press the “MENU” button once • Press UP/Down button to select “Video Size”...
- Page 16 TV Out Type—PAL/NTSC • Slide the switch to “Test” position • Press the “MENU” button once • Press UP/Down button to select “TV Out Type” and Press OK to enter • Press UP/Down button to select TV out type • Press OK button to save the current setting •...
- Page 17 Time Lapse--10second-24hours (Time Lapse mode) This Parameter defines camera captures images at a preset time intervals regardless of whether there are motions get detected. This function is only taking picture, no video. *Default setting is 10s. • Slide the switch to “Test” position •...
- Page 18 date/time/Pressure/Temperature/Moon Phase/Camera name be stamped on the pictures and video or not. *Default setting is 0N The info strip below will appear at the bottom of the photo/video: 1- Time HH:MM:SS 2- Date DD/MM/YY 3- Pressure 4- Temperature(F/C) 5- Moon Phase 6- Camera name(11digits) - 17 -...
- Page 19 The Icon for Moon Phase Temperature—Fahrenheit/Celsius This parameter defines the temperature stamp on picture/video is Fahrenheit or Celsius. *Default setting is Celsius. Battery CALC--Percentage/Day This parameter defines battery power leave. When camera connect with external power, “EXT” will is displayed on the left down corner of LCD screen, Not calculated battery storage level at Percent/Days.
- Page 20 Camera Name--11digts The Camera Name is imprinted on the photos/Videos and provides a point of reference when camera are used. Character A to Z, 0 to 9 or space. *Default setting is 00000000000. Security Enable--ON/OFF This function is for user to set a password to protect the camera. Turn “ON” security Enable, key in security code.
- Page 21 imprint in the EXIF data of the photo taken. *Default setting is 000.000000. Alarm Mode—Single Once/Single Repeat/All repeat This Parameter defines camera play sound or Alarm voice a single once/Single Repeat/All Repeat. Cameras works as a game call, animal chaser or an alarm device. Sound saves in TF card, support as:MP3.
- Page 22 Alarm voice/Play sound: Camera capture photo and play sound is two separate systems. Sound file xx.MP3 should be save at Root directory of TF card, not create folder and not save to many MP3 file to avoid error and mixed play. 1, When the parameter “Alarm Cycle”...
- Page 23 Format—NO/YES This parameter allows deleting all files in SD card. Make sure you have downloaded and backed up all files you want to preserve first. Default Set—NO/YES To reset the camera setting to the default set. System This parameter allows user check camera FW version and upgrade FW.
-
Page 24: Setting Up The Camera In The Field
PART02.bin 3, Insert this SD card in camera, Camera Switch to “Test”, press “Menu” button and Up/Down button to select “System” 4, Press Up/Down button to select “FW UPDATE” then press OK button 5, Upgrading information is displayed on LCD screen. Keep camera power on until LCD screen shut down. - Page 25 • Double check battery before turning on the camera for use. • Make sure to insert the memory card after setting up the camera. • Make sure to turn the camera to ON mode (or take out of Test Mode) before you leave.
- Page 26 Mount the camera on the way of animal’s feeder point, rest area and excise filed based on animal’s Urine, Pugmark, Scrape, Claw mark, Scent–spraying, Prey remain, Rest site, Roar, tract trap, scat etc. (Example: Animal’s tract trap, urine etc) - 25 -...
- Page 27 - 26 -...
- Page 28 - 27 -...
- Page 29 Put a Hand-made cover on the top of camera to avoid sunshine directly. (Example: Hand-made plastic cover) - 28 -...
-
Page 30: Appendix I: Default Setting
Default Settings Appendix I: Code Parameter name Default Mode Camera Set Clock 01/012014 00:00 Digital Zoom Image Size Picture No. Video Size HD1280 x 720 Video Length Digital Zoom TV Out Type Power Manage Normal PIR Interval Time Lapse Timer Setting Star: 06H:00M End:18H:00M Time Stamp Temperature... -
Page 31: Appendix Ii: Technical Specification
Technical Specification Appendix II: Display Screen 2.0" Color viewer TFT LCD Image Sensor 12.0 Mega Pixels Resolution,2/5 / 8 / 12 Angle PIR:65° F=2.4; FOV=60° ;Max View 62°; Auto IR-Cut-Remove Lens (at night) 3W flash light Yes(On/Off) color picture and video day and night IR-Flash Yes（can choose 50% or 100%) / No Infrared Cut Filter... -
Page 32: Appendix Iii: Parts List
Stand-by Current < 0.3mA Stand-by Time Up to 6 Months(8*AA) 170mA (±300mA when 42-IR-LED lighted Power Consumption total:<460mA) Takes up to 40,000 pictures on 8*AA Alkaline batteries TV out (NTSC，PAL); USB; SD card holder;TF card Interface holder 12V DC external Operation Temperature -30°C - 60°C (Storage temperature: -40°C - 70°C) -
Page 33: Fcc Compliance
FCC Compliance This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
