OPERATIONS/PARTS MANUAL
WWP30E-5-10-208-G-L/R
Please fi ll in the following blanks and then keep this manual in a safe and convenient loca-
tion. When calling with either questions or replacement part needs, always refer to the Winch
Model, Part Number and Serial Number.
A0000466/A0000467
WINCH PART #:
MOTOR MFG.: _____________________
BRAKE SERIAL #: _________________
NAME: _________________________________________________________________
ADDRESS: ______________________________________________________________
CITY: _____________________________ STATE: ___________ ZIP: ____________
PHONE: ___________________________
Patterson Company
870 Riversea Road
Pittsburgh, PA 15233
Phone: 800-322-2018
FAX: 412-322-2785
FOR
PATTERSON'S
ELECTRIC WINCH.
DISTRIBUTOR INFORMATION
WINCH SERIAL #: _____________
MOTOR SERIAL #: __________________
DATE PURCHASED: ________________
FAX: _____________________________
DOC #
A0000466 / A0000467 Rev1
Advertisement
Summary of Contents for Patterson WWP30E-5-10-208-G-L/R
- Page 1 DOC # A0000466 / A0000467 Rev1 Patterson Company 870 Riversea Road Pittsburgh, PA 15233 Phone: 800-322-2018 FAX: 412-322-2785 OPERATIONS/PARTS MANUAL PATTERSON'S WWP30E-5-10-208-G-L/R ELECTRIC WINCH. Please fi ll in the following blanks and then keep this manual in a safe and convenient loca- tion.
- Page 2 IMPORTANT! Prior to installing and operating the winch, please read this manual thoroughly and carefully. Keep this manual and all other instructions accessible at all times. Although this manual will help you become familiarized with the operating pro- cedures for the winch, it is by no means a substitute for proper training and the safe use of winches, barge rigging and other marine equipment.
-
Page 3: Installation
WARNING! ONLY A QUALIFIED ELECTRICIAN SHOULD WIRE CONTROL BOX AND REMOTE STATION OF A LIFTING EYES ON EACH SIDE OF THE WINCH. WINCH. W. W. PATTERSON COMPANY IS NOT LIABLE NEVER LIFT THE WINCH BY THE GEARMOTOR FOR DAMAGE CAUSED BY UNAUTHORIZED OR UN-... - Page 4 1. INSTALLATION (Cont'd.)
- Page 5 1. INSTALLATION (Cont'd.) 1.6. Connect each of the three wires from the control box to one of the three usable groups of wires in the conduit WARNING! FAILURE TO REMOVEL THE BREATHER box. Please review the label inside the conduit box for the VALVE TRANSPORT FIXTURE MAY RESULT IN DAMAGE specifi...
- Page 6 2. ATTACHING THE WIRE ROPE 2.3. Slowly start to reel the rope onto the drum. Maintain enough tension on the rope to be sure the fi rst coil begins snugly against the side of the drum and each successive coil is snug against the previous coil. Check to make sure the rope is reeled in from the bottom of the drum.
- Page 7 To stop the winch, release the OUT/REVERSE button and 3.1. The W. W. Patterson electric winch is designed for the brake will engage. If the Locking Dog is engaged, easier operation and longer life.
- Page 8 5. LUBRICATION AND INSPECTION 6.1. All grease fi ttings should be lubricated regularly using a POLYUREA grease such as ALTRA 500 EP2. 6.2. All gear teeth should be coated regularly with heavy-duty gear grease. 6.3. Regularly, inspect the winch carefully and completely for worn gears and pawls, cracked welds and other dam- aged or worn parts.
