- Page 1 AS3200V2 Hardware Manual...
- Page 2 AS3200V2 Hardware Manual www.alnetsystems.com 2004-04-02...
- Page 3 AS3200V2 Hardware Manual Manual History Date Revision December 3, 2003 First Edition April 2, 2004 H/W Ver.2.00 Revision 2004-04-02 www.alnetsystems.com...
-
Page 4: Table Of Contents
ONNECTION WITH ERIPHERAL 4. ELECTRICAL SPECIFICATIONS.....................8 4.1 R ..................8 ECOMMENDED PERATING ONDITIONS 4.2 P ..................8 OWER UPPLY URRENT EQUIREMENTS 5. OPTION CARD..........................9 5.1 A ..........................9 5.1.1 AudExt3 CARD PICUTRE....................9 5.1.2 AudExt3 CARD COMPONENTS ..................9 6. AS3200V2 INSTALLATION GUIDE ..................10 www.alnetsystems.com 2004-04-02... -
Page 5: Product Overview
1. Product Overview 1.1 Overview AS3200V2 is a video capture card for PC based DVR and supports audio capture, digital input, digital output, and watchdog function as well as video capture. Video/audio data which is input through AS3200V2 is uncompressed raw data of which compression and recording should be done by software on PC. -
Page 6: Functional Description
AS 3200V2 Hardware Manual 2. Functional Description 2.1 Video - Video Input Number of Channel: 16 Input : Color Camera (NTSC, PAL), Black and White Camera Connections : 15pin DSUB Cable 2EA, 40pin connector(used to connect to real-time display card) Recommended Signal Range: 0.5V ~ 2V (p-p) - Video Capture Classification... -
Page 7: Watchdog
AS3200V2 Hardware Manual 2.3 Watchdog Watchdog works by relay switch and two connectors (J1, J2) are respectively a 2pin pinheader. J1 and J2 physically do the same operation; one is connected to reset connector of mother board and the other to reset connector of the case. Or the vice versa. -
Page 8: Hardware Installation
AS 3200V2 Hardware Manual 3. Hardware Installation 3.1 AS3200V2 Components 2. AIN 1-8(J3, J4) : 5Pin Molex Box Connector x 2 for Audio Signal 3. VIN 1-8(J6) : DSUB-15 Female Connector 4. VIN 9-16(J8) : DSUB-15 Female Connector 5. VOUT(J14) : External Video Out RCA Jack 6. -
Page 9: Capture Card Component Description
AS3200V2 Hardware Manual 3.2 Capture Card Component Description 2 AIN 1-8 5Pin Molex Box Connector(J3, J4) This is a connector for Audio Input 1-8 and connected to J2 and J3 of AudExt3 Card. (AudExt3 Card is option.) 3 VIN 1-8 DSUB-15 Female Connector(J6) This is a video input connector. - Page 10 This is a video signal input connector. It is connected to the VIN1-16 connector of real-time display card when user uses the real-time display card with AS3200V2. To prevent misconnection, the connector was grooved. 9 WATCHDOG 2Pin Pinheader * 2(J1, J2) Two watchdog 2pin pinheaders are respectively connected to reset connector of mother board and reset connector of system case.
-
Page 11: Connection With Peripheral
AS3200V2 Hardware Manual 3.3 Connection with Peripheral 2004-04-02 www.alnetsystems.com... -
Page 12: Electrical Specifications
AS 3200V2 Hardware Manual 4. Electrical Specifications 4.1 Recommended Operating Conditions Parameter Units Power supply +5V 4.75 5.25 Power supply +12V Power supply -12V Peak to Peak Amplitude Sync Amplitude Video % of Horizontal Lock Input ±7 Line Range Range Length Color Sub- carrier Lock-in... -
Page 13: Option Card
5.1.2 AudExt3 Card Components 1 AIN 1-4 5Pin Molex Box Connector(J2) This is used to transfer the input CH. 1 to 4 audio signals to AS3200V2. 2 AIN 5-8 5Pin Molex Box Connector(J3) This is used to transfer the input CH. 5 to 8 audio signals to AS3200V2. -
Page 14: As3200V2 Installation Guide
Option Components are optional. User can select DI/DO extension cards among the above. Cables are provided with the selected DI/DO ext cards. . Hardware Installation (1) As the below, connect AS3200V2 Capture Card to AudExt3 and ConExt1616. <AudExt3 and ConExt1616 Connected to AS3200V2> www.alnetsystems.com... - Page 15 AS3200V2 Hardware Manual (2) Insert AS3200V2 vertically into PCI slot from one side to the other and then insert AudExt3 and ConExt1616 in the same way. Check if the cards were well inserted into PCI slot. <AS3200V2, AudExt3 and ConExt1616 Inserted into PCI Slot>...
- Page 16 AS 3200V2 Hardware Manual III. Cable Connection (1) DSUB 15PIN Cable DSUB 15PIN cable is used for video input (J6, J8) of AS3200V2 capture card. Connect it as the below picture. VIN1~VIN8 Terminal(J6) -Video In 1~8 Channel VIN9~VIN16 Terminal(J8) -Video In 9~16 Channel (2) External Monitor Output Terminal (J14) External monitor output port (RCA jack) is connected to external monitor.
